Custom Engraving Services
Custom Engraving Services for Architectural Adapter Plates
CustoM enGravinG serviCes
Extron is pleased to offer custom engraving services for MAAP - Mini Architectural Adapter
Plates, AAP - Architectural Adapter Plates, the CTL208CM eight-button serial control panel,
and the CM-5BB/CM-20BB five-button and 20-button control module AAPs. You can use the
engraving to clearly indicate signal type, input numbers or any other labeling required for
making signal connections clear and easy.
enGravinG sPeCifiCations
Standard Letter Size
MAAPs, AAPs, CM-5BB, and CM-10BB: 0.08" / 2 mm Tall
Standard Letter Size
CTL208CM: 0.1" / 2.5 mm Tall
Standard Font
Gothic - (a sans serif-style font) Engraving is all capital letters.
Engraving Color
• White AAPs & MAAPs: Black Engraving
• Black AAPs & MAAPs: White Engraving
• RAL9010 White AAPs & MAAPs: Black Engraving
Engraving Process
Letters, numbers, and symbols are laser engraved and then filled with color.

order inforMation

To order engraving for any of the AAPs, MAAPs, CTL208CM, CM-5BB, or the CM-10BB, copy
the Engraving Order Forms from the Extron Product Catalog or download PDF versions of these
forms from the Extron Web site at http://www.extron.com/engraving. Detailed instructions for
completing the forms are included in the catalog and in the PDF form.
Submit one Engraving Order Form for every unique plate design and every module model
ordered. If identical engraving is required on several modules, then submit only one order form
for each model number ordered. Be sure to include a purchase order that specifically authorizes
purchase of the Extron products as well as the engraving service charges.
fax subMission
Fax your completed engraving order form(s) and your purchase order to Extron at:
714.491.1517.
e-Mail subMission
You can download the PDF version of the order forms from www.extron.com/engraving.
Complete the form(s) electronically and submit them via e-mail to: engraving@extron.com
For assistance or if you have questions about our custom engraving services, please contact
an Extron Customer Support Representative.
Model
Set-up Engrave
Engraving
Europe Europe Dubai Dubai
+31.33.453.4040 / +800.3987.6673 +31.33.453.4040 / +800.3987.6673 +971.4.2991800 +971.4.2991800
+31.33.453.4050 FAX +31.33.453.4050 FAX +971.4.2991880 FAX +971.4.2991880 FAX
version desCriPtion
One-time charge
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Per unit charge
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Asia Asia
+65.6383.4400 / +800.7339.8766 +65.6383.4400 / +800.7339.8766
+65.6383.4664 FAX +65.6383.4664 FAX
enGravinG saMPles
