Extron electronics VCM 100 AAP Setup Manual

The Extron VCM 100 AAP and VCM 100 MAAP are remote volume/mute controllers
designed to work with Extron products (such as the MPA 122 mini power amplifier).
Mounted into standard Extron AAP or MAAP mounting frames, the VCM 100 AAP and
VCM 100 MAAP each have a 10k ohm potentiometer volume control knob and mute
button.
The Mute button toggles between mute and un-mute, turning bright red to indicate
mute, and dim green to indicate un-mute.

Remote connector pin configuration

As shown below right, Pin 1 is a 10 VDC reference voltage. Pin 2 is volume and mute
control with DC voltage; the range is 0 to 10 V, where 0 V is mute and 10 V provides
maximum volume. Pin 3 is ground.
All nominal levels are at ±10%.

Audio level setting procedure

To set the system level to not exceed the maximum
volume in using the VCM 100, do the following:
1. Reduce the power amplifier volume to minimum.
2. Turn the Volume knob on the VCM 100 to the
maximum position.
3. Slowly turn up the power amplifier volume to the
maximum undistorted sound level allowed for the
application.
As shown below, the Extron VCM 100 AAP and VCM 100 MAAP serve to remotely control
volume and mute with Extron products (such as the
MPA 122 Mini Power Amplifier).
Extron Electronics, USA
1230 South Lewis Street
Anaheim, CA 92805
USA
714.491.1500
www.extron.com Fax 714.491.1517

VCM 100 AAP and MAAP

Extron
2 2
MPA 122
A 1
M P S
U T
T P
O U m s
O h
4 /8
U S U S Mini Power Amplifier
C T E
R
S M O
U T
R E
IN P
L
E
U T
1 0 V
L /M
V O
R
L
L
R
W E
P O
R
Extron
STP 22
Cable
Audio
Output
Projector
Extron Electronics, Europe
Beeldschermweg 6C
3821 AH Amersfoort
The Netherlands
+31.33.453.4040
Fax +31.33.453.4050
REMOTE
1 2 3
10V
VOL/MUTE
T E
M U
M E
L U
V O
A P
0 A
1 0
M
V C
Extron
VCM 100 AAP
Volume/Mute Controller
(mounted in an Extron
AAP 100 Frame)
Extron Electronics, Asia
135 Joo Seng Road, #04-01
PM Industrial Building
Singapore 368363
+65.6383.4400
Fax +65.6383.4664
Red
Extron
Black
STP 22
Ground
Cable
VOLUME
MUTE
VCM 100 MAAP
68-1032-01
Rev. A
03 05
