Audio Connectors

Figure 18 shows the locations of the audio connectors. Tables 42 through 45 list the pinouts of the

audio connectors.

D
The audio connectors include the following:
Back panel connectors: Line In, Line Out, Mic In
CD-ROM audio (ATAPI)
Telephony (ATAPI-style)
A B
1 1
4 4
1
A ATAPI CD-ROM
B ATAPI-style telephony
C MIDI/Joystick
D External speaker
Figure 18. Audio Connectors
C
1 2
16
15
Technical Reference
OM07118
91
