885305

CONTROL PANEL PARTS

For Models: KEBS277DBL4, KEBS277DWH4, KEBS277DAL4
(BLACK)
Illus.
Part
No.
No.
NOTE: The screws and nuts
required to attach a part are
listed immediately following
that part.
1
4451291 Black Model
4451292 White Model
4451293 Almond Model
2
4451033 Gasket,
4159465 Screw
3
4448871 Microcomputer
4449745 Screw
LITERATURE PARTS
LIT4450410 Installation
LIT4450571 Use & Care Guide
LIT4449066 Cookbook
LIT4454771 Tech Sheet (Oven)
LIT4449264 Easy Set Guide
(WHITE)
(ALMOND)
DESCRIPTION
Control Panel Assy.
W/Membrane Switch
Control Panel
Instructions
(Oven)
(T/C Oven)
3
