KitchenAid KEBS277DAL4 Parts List page 5

27" built−in electric double oven thermal convection self−clean
Hide thumbs


Advertisement

Illus.
Part
No.
No.
DESCRIPTION
2
4448701 Element, Broil
4449154 Screw
3
3147563 Grill, Broiler
4
3147845 Pan, Broiler
5
3181534 Rack, Roasting
6
4448715 Rack, Oven
7
4448695 Element, Bake
885305
INTERNAL OVEN PARTS
For Models: KEBS277DBL4, KEBS277DWH4, KEBS277DAL4
(BLACK)
Illus.
Part
No.
No.
8
4448881 Nut, Hex
9
4448952 Convection Motor
10
4449154 Screw
11
4448882 Washer, Lock
13
4451355 Jack, Meat Probe
14
4448948 Probe, Meat
15
4448722 Tray, Bake
(WHITE)
(ALMOND)
Illus.
DESCRIPTION
No.
17
20
21
5
Part
No.
DESCRIPTION
4450039 Cover, Bake Tray
4449809 Screw
4448841 Element,
Convection
4449154 Screw
4448418 Cover, Fan
4449154 Screw
