Summary of Contents for Perle S-1110P
- Page 1 Perle PoE/PoE+ 10/100/1000 Ethernet Media Converters Installation Guide S-1110P S-1110PP S-1110DP S-1110DPP S-1110P-XT S-1110PP-XT P/N 5500317-13...
- Page 2 Overview This document contains instructions necessary for the installation and operation of the Perle Standalone PoE/PoE+ 10/100/1000 rate converting Media Converters (S-1110P). These products have the ability to convert 10/100/1000Base-T cable connections (copper) to 100/1000Base-X connections (fiber). The Perle media converters function as a PoE switch, and support a variety of port configurations, including single or dual UTP and fiber ports.
- Page 3 S-1110DPP-S2xx40 40 km/25 mi. S-1110DP-S1SC40U 1310/1490 nm S-1110DPP-S1SC40U 40 km/25 mi. S-1110DP-S1SC40D 1490/1310 nm S-1110DPP-S1SC40D 40 km/25 mi. S-1110DP-S2xx70 SC/ST 1550 nm S-1110DPP-S2xx70 70 km/43.5 mi. S-1110DP-S1SC80U 1510/1590 nm S-1110DPP-S1SC80U 80 km/50 mi. Perle PoE/PoE+ Ethernet Media Converter Installation Guide...
- Page 4 Dual copper / PoE / Dual Connector Mode Wavelength (xx) Distance (TX/RX) Dual copper / PoE+/ Dual S-1110DP-DSFP Note 1. S-1110DPP-DSFP Note 1 Note 1: Fiber characteristics will depend on the SFP fiber module selected. Perle PoE/PoE+ Ethernet Media Converter Installation Guide...
-
Page 5: Extended Temperature Models
Note 1. S-1110PP-SFP-XT Note 1 Note 1: Fiber characteristics will depend on the SFP fiber module selected. Please visit Perle’s website for the most up to date Installation guides models and specifications. http://www.perle.com/ Perle PoE/PoE+ Ethernet Media Converter Installation Guide... -
Page 6: Installation
Installation The default DIP switch settings (all switches in the UP position) will work for most installations. These are the steps required to configure the Perle S-1110P Ethernet media converter: 1. Insert SFP Module (SFP Model only). 2. Set the Auto-MDIX jumper setting (optional). - Page 7 Up to 30 Watts on a single UTP port model and up to 25.5 Watts per port on a dual UTP port model PoE+ models will also support 802.3af PDs (Type 1) and PoE+ PDs (Type 2) Perle PoE/PoE+ Ethernet Media Converter Installation Guide...
- Page 8 To access the Powering Options Jumper settings, unscrew the six side screws on the case and remove the cover plate. Locate the Power Option jumper set and strap the option pins as detailed below. Perle PoE/PoE+ Ethernet Media Converter Installation Guide...
-
Page 9: Dip Switches
Note: All switch changes take effect immediately. Switch changes will cycle power to the PD only if the PD Reset switch is set to On or you make changes to the PSE Power switches. Perle PoE/PoE+ Ethernet Media Converter Installation Guide... -
Page 10: Dip Switch Settings
Mode Up (default) Standard Mode Down Smart Link Pass-Through Standard Mode: In this mode, link on the fiber and copper sides can be brought up and down independently of each other. A loss Perle PoE/PoE+ Ethernet Media Converter Installation Guide... - Page 11 Note: This feature only takes effect if Fiber Negotiation has been turned off. Disabled: The media converter will not monitor for or generate Fiber Fault Alert. Perle PoE/PoE+ Ethernet Media Converter Installation Guide...
- Page 12 Duplex setting for copper port 1. Full Duplex: In the Up switch position; the media converter will be set to Full Duplex mode. Half Duplex: The media converter will be set to Half Duplex mode. Perle PoE/PoE+ Ethernet Media Converter Installation Guide...
- Page 13 This will ensure that the most optimal connection parameters will be in effect. If connecting to another Perle Media Converter, this parameter should be set to Auto. The Media Converter Module will advertise 1000Mbps, Full and Half Duplex, no Pause.
- Page 14 The data link will be disabled; however power to the powered devices will be maintained. This mode will override all other switch settings. Note: On media converters with two fiber ports, both ports can be in loopback mode at the same time. Perle PoE/PoE+ Ethernet Media Converter Installation Guide...
- Page 15 Disabled: When disabled, the loss of fiber link has no effect on PSE power to the PD device. Enabled: When enabled, if the media converter detects loss of link on any fiber port it will turn off PSE output power to the PD device Perle PoE/PoE+ Ethernet Media Converter Installation Guide...
- Page 16 1 will occur. Enabled: Fiber port 1 will be designated as the Primary fiber port. If a loss of link occurs on fiber port 1 which causes a switch over to Perle PoE/PoE+ Ethernet Media Converter Installation Guide...
- Page 17 RX wavelength at the other end and the RX wavelength matches the TX wavelength at the other end. 2. Connect the fiber cable from one media converter to the other media converter/switch/fiber device. Perle PoE/PoE+ Ethernet Media Converter Installation Guide...
-
Page 18: Installing The Copper Cable
Installing the Copper Cable 1. Locate 10/100/1000Base-T compliant copper cables with the appropriate connectors. 2. Connect the RJ-45 cable between the Perle media converter and the device. Note: The Perle media converter supports Auto-MDIX which allows connection of a straight-through or cross-over Ethernet cable. - Page 19 4. Plug the other end of the power cord into an appropriate power outlet. Powering up the Perle Media Converter 1. Connect the Perle supplied power adapter to the media converter. 2. Connect the power adapter to a power source. 3. Check that the PWR LED light is lit.
- Page 20 7. Check that the PWR LED light is lit. 8. For extra power cable strain relief, attach the strain clip to the case as shown below, and thread the power cable through the clip in either one or two loops. Perle PoE/PoE+ Ethernet Media Converter Installation Guide...
-
Page 21: Operation
Operation Status LED The Perle PoE/PoE+10/100/1000 Rate converting Media converters have status LEDs located on the front panel of the unit. On – Power is applied to the unit Blinking (slow) – Loopback mode (one or both fiber interfaces are in loopback mode) Blinking (fast) Power On failure. - Page 22 3 second stop interval between the error condition code. PSE-1 / 2 LED 1 blink PD Capacitance too high 2 blinks PD Resistance too low or short circuit 3 blinks PD Resistance too high Perle PoE/PoE+ Ethernet Media Converter Installation Guide...
-
Page 23: Other Features
Integrated Pause signalling is an IEEE feature that temporarily suspends data transmission between two devices in the event that one of the devices becomes overwhelmed with data. The Perle media converter can generate and respond to Pause messages. If Auto negotiation is set to On, the media converter will advertise symmetrical and asymmetrical pause. -
Page 24: Troubleshooting
Troubleshooting General 1. Ensure power is supplied to the media converter. Only the Perle provided power supply may be used. 2. Ensure the remote device’s fiber connection type is compatible with the media converter. If using a simplex fiber connection, ensure that you have both an Upstream (U) and Downstream (D) media converter. - Page 25 PD’s), the Power Option Jumpers must be set accordingly. Also ensure the correct pin out for the device. 4. For proper detection of different classes of devices, the dip switches must be set correctly. Perle PoE/PoE+ Ethernet Media Converter Installation Guide...
-
Page 26: Technical Specifications
2 SFP / 2 copper ports 317,119 hours 191,244 hours 76,026 hours 1 SFP / 2 copper ports 323,861 hours 193,675 hours 76,407 hours SC/ST – 2 copper ports 292,529 hours 182,017 hours 74,524 hours Perle PoE/PoE+ Ethernet Media Converter Installation Guide... -
Page 27: Fiber Optic Specifications
Min: -3 Min: -34 S-1110PP-S1SC120D RX: 1590 Max: 2 Max:.-9 S-1110P-S2xx160 TX: 1550 Min: 2 Min: -34 S-1110PP-S2xx160 RX: 1550 Max: 5 Max:.-9 S-1110P-SFP (XT) Note 1 Note 1 Note 1 Note S-1110PP-SFP (XT) Perle PoE/PoE+ Ethernet Media Converter Installation Guide... - Page 28 RX:1310 Max: -3 Max: Min: -2 Min: -23 S-1110DP -S2SC70 TX: 1550 RX:1550 S-1110DPP -S2SC70 Max: 5 Max: -3 Min: Min: -23 TX: 1550 S-1110DP -S2ST70 S-1110DPP -S2ST70 RX:1550 Max: 5 Max: -3 Perle PoE/PoE+ Ethernet Media Converter Installation Guide...
- Page 29 Ethernet Copper Cabling Requirements: Category 5 UTP or STP 24-22 AWG Straight through or Ethernet crossover Note: Please refer the product page on the Perle website for the most up to date models and specifications. http://www.perle.com/ Perle PoE/PoE+ Ethernet Media Converter...
-
Page 30: Compliance Information
Warranty / Registration Perle’s standard Lifetime Warranty provides customers with return to factory repairs for Perle products that fail under the conditions of the warranty coverage. Details can be found at: http://www.perle.com/support_services/warranty.shtml...
