PEERLESS PRS 274 Technical Data Sheet

TECHNICAL DATA SHEET -
The PRS Series Projector Mount is the most low profile mount
available today and offers the easiest installation. It ships completely
pre-assembled and offers unmatched versatility. It can be mounted to
any common ceiling structure and is offered in multiple colors to
complement any setting. It was specifically designed to save time and
money when mounting projectors.

Features:

• +5°/-20° Pitch, +/-10° Roll, 360° Yaw (when attached to an extension
column), +/-15° Yaw (when flush mounted), which enables the image
to be perfectly aligned with the screen
• Mount completely pre-assembled to save you time
• Independent roll, pitch, and yaw adjustments provide easy image
alignment
• Can be mounted directly to a single wood beam or concrete slab
without disassembling the mount and without reinforcing the ceiling
• Can attach to 1 1/2" extension column, 3/4" extension column, or 3/8"
threaded rod
™
• Armor Lock security screws pre-installed for a secure installation in
minutes
• Quickly release the projector for maintenance with the simple turn of a
knob
• Built in cord management access hole provides complete access to
route cords through extension column to keep cords hidden
• 4 adjustment points allow a quick, simple installation
• Final security lock down is optional to use
• Easily and quickly attaches to projector-specific adapter plate
• Offered in black, white, and silver to complement any setting
• Low profile allows the projector to be close to the ceiling
• Offers the fastest installation to reduce installation time and costs
The PRS Series Projector Mount shall be a Peerless model
+
25°(+5°/-20°) pitch, 20°( 10°) roll, 360° yaw (when attached to an extension column), and +/-15° yaw (when flush mounted). It shall have a 25
lb load capacity. It shall have a quick release spring loaded screw for easy removal and installation of the projector. It shall be constructed of
aluminum alloy finished in black, white, or silver. Assembly and installation shall be done according to instructions provided by the manufacturer.
Peerless Industries, Inc.
3215 W. North Ave. Melrose Park, IL 60160
708-865-8870 800-865-2112 Fax 708-865-2941
www.peerlessmounts.com
PRS Series Projector Mount for
InFocus
MODELS: PRS 274, PRS 274-S, PRS 274-W
A R C H I T E C T S S P E C I F I C A T I O N S
and shall be located where indicated on the plans. It shall feature
Peerless is a registered trademark and Armor Lock and Armor Lock Plus are trademarks of Peerless Industries, Inc.
All other brand and product names are trademarks or registered trademarks of their respective owners.
™
LP-820 Projector
GENERIC
ADAPTER PLATE

Accessories:

• Ceiling Plates (various models available)
• Cord Wrap (ACC 852, ACC 852S, ACC
852W)
• Fixed and Adjustable length Extension
Columns, 1 1/2" NPT ("EXT" or "ADJ"

models)

• Fixed length Extension Columns, 3/4" NPT
("FLP" models)
• Armor Lock Plus ™
(ACC 020)
• Armor Lock Plus security cable (ACC 021)
• Side to Side Adjuster (ACC 830)
Dimensions:
For product dimensions, see page 2.
ISSUED: 02-27-06 SHEET NO: 056-9579-1
© 2005 Peerless Industries, Inc. All rights reserved.
page 1 of 2
R
PRS SERIES
PROJECTOR
MOUNT
security cable with Lock
