PEERLESS PRS-EXC Technical Data Sheet

TECHNICAL DATA SHEET
The PRS-EXC is the lowest profile universal projector mount
available today. In a kit with the adjustable EXC ceiling column, it
offers a quick and easy installation in addition to unmatched
versatility. This convenienct kit allows for ceiling mount only.

Features:

• Tilt: +20°/-5°, Roll: ±10°, Swivel: 360° (when
attached to an extension column), ±30° swivel
(when flush mounted), which enables the image
to be perfectly aligned with the screen
• For projectors up to 25 lbs
• Independent roll, pitch, and yaw adjustments
provide easy image alignment
• Can be mounted directly to a single wood beam/
stud or concrete slab without disassembling the
mount and without reinforcing the ceiling
• Ceiling mount only
• Quick release mechanism to easily remove
projector for maintenance
• Cable management allows cables to be routed
through projector mount out of sight
®
• Includes Spider Universal adapter plate
• Available in black, silver, and white
Dimensions:
For product dimensions, see page 2.

Accessories:

• Suspended Ceiling Kits (CMJ series)
• Ceiling plates (various models available)
• Extension Columns (various models available)
• Cord Management Adapter (ACC 800)
• Extension collar connector (ACC 109)
• Projector Wall Arm (PWA-14)
• Truss Ceiling Adapter (ACC 557)
The Universal Projector Ceiling Mount shall be a Peerless model ____________ and shall be located where indicated on the plans. It
shall feature Tilt: +20°/-5°, Roll: ±10°, Swivel: 360° (when attached to an extension column), ±30° swivel (when flush mounted), which
enables the image to be perfectly aligned with the screen. It shall have a 25 lb load capacity. It shall have a quick release spring loaded
screw for easy removal and installation of the projector. It shall be constructed of aluminum alloy finished in black, white, or silver. Assembly
and installation shall be done according to instructions provided by the manufacturer.
Peerless Industries, Inc.
3215 W. North Ave. Melrose Park, IL 60160
708-865-8870 800-865-2112 Fax 708-865-2941
www.peerlessmounts.com
MODELS: PRS-EXC, PRS-EXC-S, PRS-EXC-W
PRS Precision Gear Projector Mount Kit
with EXC Ceiling mount
• Unistrut Adapter (ACC 550)
• I-beam Clamps (ACC 558, ACC 559)
• Cathedral Ceiling Plate (ACC 912)
• Anti-vibration Plate (ACC 840, ACC 845)
• Side-side Adjuster (ACC 830)
• Cord Wrap (ACC 852, ACC 852S, ACC 852W)
• Escutcheon ring (ACC 640)
A R C H I T E C T S S P E C I F I C A T I O N S
All other brand and product names are trademarks or registered trademarks of their respective owners.
ISSUED: 06-05-08 SHEET NO: 056-9632-1
© 2007, Peerless Industries, Inc. All rights reserved.
page 1 of 3
