HP Surestore 6164 - Switch Reference Manual

HP Surestore 6164 - Switch Reference Manual

Mib reference manual
Hide thumbs Also See for Surestore 6164 - Switch:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
reference manual
version 2.3
MIB
www.hp.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Surestore 6164 - Switch and is the answer not in the manual?

Questions and answers

Related Manuals for HP Surestore 6164 - Switch

Summary of Contents for HP Surestore 6164 - Switch

  • Page 1 reference manual version 2.3 www.hp.com...

  • Page 2: Safety Notices

    Safety notices fitness for a particular purpose. Hewlett-Packard shall not be liable for errors contained herein or for incidental or Any servicing, adjustment, maintenance, or repair must be consequential damages in connection with the furnishing, performed only by authorized service-trained personnel.

  • Page 3: Table Of Contents

    CONTENTS Revision History ..........7 Preface .
  • Page 4 TCP Group ..........67 TCP Connection Table .
  • Page 5 FC Fabric Element MIB Object Types ....185 FE-MIB File System Organization ......185 Definitions for FE-MIB .
  • Page 6 Fibre Channel Port Group ........291 Fibre Channel Port Table .

  • Page 7: Revision History

    Revision History July 2001 First release.
  • Page 8 MIB Reference Manual...

  • Page 9: Preface

    PREFACE About This Guide This guide provides the following information about Management Information Bases (MIBs): Chapter 1 Provides information about MIB-II MIB-II Object Types object types. Chapter 2 Provides information about Fibre Alliance MIB Object FCMGMT-MIB object types. Types Chapter 3 Provides information about FE-MIB FC Fabric Element MIB Object object types.

  • Page 10: Related Publications

    The tables within this document often contain a column labeled Note Description. This column contains information about those MIB objects that have been modified or in some way require explanation beyond the scope of the standard explanation. If no information is present in the Description column for a particular MIB object, the standard return values apply.

  • Page 11: Getting Help

    Getting Help For support information, visit the HP web site located at: http://www.hp.com Getting Software Updates Firmware and software updates are found on the HP web site at: http://www.hp.com New switch firmware can be installed from the following host operating systems: •...
  • Page 12 MIB Reference Manual...

  • Page 13: Mib-Ii Object Types

    MIB-II OBJECT TYPES This chapter provides descriptions and other information specific to MIB-II object types. The object types in MIB-II are organized into the following groupings: • “System Group” page 19 • “Interfaces Group” page 22 • “Address Translation Group” page 35 •...

  • Page 14: Mib-Ii File System Organization

    MIB-II File System Organization Figure 1 through Figure 4 depict the organization and structure of the MIB-II file system: Figure 1. MIB-II Overall Tree Structure MIB Reference Manual...
  • Page 15 Figure 2. Tree Structure for MIB-II system, interfaces, at, and ip Groups MIB-II Object Types...
  • Page 16 Figure 3. Tree Structure for MIB-II icmp, tcp, udp, and egp Groups MIB Reference Manual...
  • Page 17 Figure 4. Tree Structure for MIB-II SNMP Group MIB-II Object Types...

  • Page 18: Definitions For Mib-Ii

    Definitions for MIB-II The following definitions are used for MIB-II. Table 1. MIB-II Conventions Type Definition Value Declaration Description Display String Octet String of size 0 to 255 PhysAddress Octet String Imports The following objects are imported from RFC1155-SMI: • mgmt •...

  • Page 19: System Group

    System Group Implementation of the system group is mandatory for all systems. If an agent is not configured to have a value for any of these variables, a string of length 0 is returned. sysDescr Syntax Display String of size 0 to 255 Access Read-only Status...
  • Page 20 This value is allocated within the SMI enterprises subtree Note (1.3.6.1.4.1) and provides an easy and unambiguous means for determining what kind of box is being managed. For example, if vendor “Flintstones, Inc.” was assigned the subtree 1.3.6.1.4.1.4242, it could assign the identifier 1.3.6.1.4.1.4242.1.1 to its “Fred Router”.
  • Page 21 sysName Syntax Display String of size 0 to 255 Access Read-write Status Mandatory Description An administratively-assigned name for this managed node. By convention, this is the node’s fully-qualified domain name. Default value = pre-assigned name of the switch. Note sysLocation Syntax Display String of size 0 to 255 Access...

  • Page 22: Interfaces Group

    Status Mandatory Description A value that indicates the set of services that this entity primarily offers. The value is a sum. This sum initially takes the value zero. Then, for each layer (L) in the range 1 through 7, which this node performs transactions for, 2 raised to (L - 1) is added to the sum.

  • Page 23: Interfaces Table

    Status Mandatory Description The number of network interfaces (regardless of their current state) present on this system. When running FCIP, the return value is always 3. If not running Note FCIP, the value is 2. Interfaces Table The interfaces table contains information on the entity’s interfaces. Each interface is thought of as being attached to a subnetwork.
  • Page 24 Index ifIndex Table 2. IfEntry Objects and Object Types IfEntry Objects See Page Object Types ifIndex Integer ifDescr Display String ifType Integer ifMtu Integer ifSpeed Gauge ifPhysAddress PhysAddress ifAdminStatus Integer ifOperStatus Integer ifLastChange Time Ticks ifInOctets Counter ifInUcastPkts Counter ifInNUcastPkts Counter ifInDiscards Counter...
  • Page 25 ifIndex [ifTable] Syntax Integer Access Read-only Status Mandatory Description A unique value for each interface. The values range between 1 and the value of ifNumber. The value for Note each interface must remain constant at least from one re-initialization of the entity’s network management system to the next re-initialization.
  • Page 26 ifType [ifTable] Syntax Table 3. Value Declaration Description Interger 1 (other) None of the following 2 (regular1822) 3 (hdh1822) 4 (ddn-x25) 5 (rfc877-x25) 6 (ethernet-csmacd) 7 (iso88023-csmacd) 8 (iso88024-tokenBus) 9 (iso88025-tokenRing) 10 (iso88026-man) 11 (starLan) 12 (proteon-10Mbit) 13 (proteon-80Mbit) 14 (hyperchannel) 15 (fddi) 16 (lapb) 17 (sdlc)
  • Page 27 Table 3. (continued) Value Declaration Description Integer 24 (softwareLoopback) 25 (eon) CLNP over IP [11] 26 (ethernet-3Mbit) 27 (nsip) XNS over IP 28 (slip) Generic SLIP 29 (ultra) Ultra Technologies 30 (ds3) 31 (sip) SMDS 32 (frame-relay) Access Read-only Status Mandatory Description The type of interface, designated by the physical and link protocols...
  • Page 28 Status Mandatory Description The size (in octets) of the largest datagram that can be sent and received on the interface. For interfaces that are used to transmit network datagrams, the value Note is the size of the largest network datagram that can be sent on the interface. fei0 returns 1500.
  • Page 29 ifPhysAddress [ifTable] Syntax PhysAddress Access Read-only Status Mandatory Description The interface’s address at the protocol layer immediately below the network layer in the protocol stack. For interfaces that do not have such an address (for example, a serial Note line), this object should contain an octet string of zero length. fei0 returns MAC address of the Ethernet.
  • Page 30 The 3 (testing) state indicates that no operational packets can be Note passed. ifOperStatus [ifTable] Syntax Table 5. Value Declaration Description Integer 1 (up) Ready to pass packets 2 (down) Not ready to pass packets 3 (testing) In some test mode Access Read-only Status...
  • Page 31 ifInOctets [ifTable] Syntax Counter Access Read-only Status Mandatory Description The total number of octets received on the interface, including framing characters. ifInUcastPkts [ifTable] Syntax Counter Access Read-only Status Mandatory Description The number of subnetwork-unicast packets delivered to a higher-layer protocol. ifInNUcastPkts [ifTable] Syntax Counter...
  • Page 32 Status Mandatory Description The number of inbound packets that were chosen to be discarded, even though no errors had been detected to prevent the packets being deliverable to a higher-layer protocol. One possible reason for discarding such a packet could be to free up Note buffer space.
  • Page 33 Status Mandatory Description The total number of octets transmitted out of the interface, including framing characters. ifOutUcastPkts [ifTable] Syntax Counter Access Read-only Status Mandatory Description The total number of packets that were requested, by higher-level protocols, to be transmitted to a subnetwork-unicast address, including those that were discarded or not sent.
  • Page 34 Status Mandatory Description The number of outbound packets that were chosen to be discarded, even though no errors had been detected to prevent the packets being transmitted. One possible reason for discarding such a packet could be to free up Note buffer space.

  • Page 35: Address Translation Group

    Status Mandatory Description A reference to MIB definitions specific to the particular media being used to realize the interface. For example, if the interface is realized by an Ethernet, the value of this object refers to a document defining objects specific to Ethernet. If this information is not present, its value should be set to the Object Identifier 0 0, which is a syntactically valid object identifier, and any conferment implementation of ASN.1 and BER must be able to generate and recognize...
  • Page 36 Examples of such translation tables include the following: • For broadcast media where ARP is in use. • The translation table is equivalent to the ARP cache. • On an X.25 network where nonalgorithmic translation to X.121 addresses is required, the translation table contains the NetworkAddress to X.121 address equivalences.
  • Page 37 Index atIfIndex, atNetAddress Table 6. At Entry Objects and Object Types At Entry Objects See Page Object Types atIfIndex Integer atPhysAddress PhysAddress atNetAddress NetworkAddress atIfIndex Syntax Integer Access Read-write Status Deprecated Description The interface on which this entry’s equivalence is effective. The interface identified by a particular value of this index is the same interface as identified by the same value of ifIndex.

  • Page 38: Ip Group

    Setting this object to a null string (one of zero length) invalides the Note corresponding entry in the atTable object. That is, the string effectively disassociates the interface identified with said entry from the mapping identified with said entry. It is an implementation-specific matter as to whether the agent removes an invalidated entry from the table.
  • Page 39 Description The indication of whether this entity is acting as an IP gateway in respect to the forwarding of datagrams received by, but not addressed to, this entity. IP gateways forward datagrams. IP hosts do not (except those source-routed using via the host). For some managed nodes, this object can take on only a subset of the Note values possible.
  • Page 40 ipInHdrErrors Syntax Counter Access Read-only Status Mandatory Description The number of input datagrams discarded due to errors in their IP headers, including bad checksums, version number mismatch, other format errors, time-to-live exceeded, errors discovered in processing their IP options, and so on.
  • Page 41 Status Mandatory Description The number of input datagrams for which this entity is not their final IP destination, resulting in an attempt to find a route to forward them to that final destination. In entities that do not act as IP gateways, this counter includes only those packets that have been source-routed using this entity, and the source-route option processing has been successful.
  • Page 42 ipInDelivers Syntax Counter Access Read-only Status Mandatory Description The total number of input datagrams successfully delivered to IP user-protocols (including ICMP). ipOutRequests Syntax Counter Access Read-only Status Mandatory Description The total number of IP datagrams that local IP user-protocols (including ICMP) have supplied to IP in requests for transmission.
  • Page 43 ipOutNoRoutes Syntax Counter Access Read-only Status Mandatory Description The number of IP datagrams discarded because no route can be found to transmit them to their destination. This counter includes any packets counted in ipForwDatagrams that Note meet this “no-route” criterion. Note that this includes any datagrams that a host cannot route because all its default gateways are down.
  • Page 44 ipReasmOKs Syntax Counter Access Read-only Status Mandatory Description The number of IP datagrams successfully re-assembled. ipReasmFails Syntax Counter Access Read-only Status Mandatory Description The number of failures detected by the IP re-assembly algorithm (for any reason, timed out, errors, and so on). This is not necessarily a count of discarded IP fragments, because Note some algorithms (notably the algorithm in RFC 815) can lose track of the...

  • Page 45: Ip Address Table

    ipFragFails Syntax Counter Access Read-only Status Mandatory Description The number of IP datagrams that have been discarded because they need to be fragmented at this entity but cannot; for example, because their don’t fragment flag was set. ipFragCreates Syntax Counter Access Read-only Status...
  • Page 46 ipAddrEntry Syntax IpAddrEntry Access Not accessible Status Mandatory Description The addressing information for one of this entity’s IP addresses. Index ipAdEntAddr Table 7. IpAddrEntry Objects and Object Types IpAddrEntry Objects See Page Object Types ipAdEntAddr IpAddress ipAdEntIfIndex Integer ipAdEntNetMask IpAddress ipAdEntBcastAddr Integer ipAdEntReasmMaxSize...
  • Page 47 Status Mandatory Description The index value that uniquely identifies the interface to which this entry is applicable. The interface identified by a particular value of this index is the same interface as identified by the same value of ifIndex. ipAdEntNetMask Syntax IpAddress Access...

  • Page 48: Ip Routing Table

    Status Mandatory Description The size of the largest IP datagram that this entity can re-assemble from incoming IP fragmented datagrams received on this interface. IP Routing Table The IP routing table contains an entry for each route presently known to this entity.
  • Page 49 Table 8. IpRouteEntry Objects and Object Types (continued) IpRouteEntry Objects See Page Object Types ipRouteMetric1 Integer ipRouteMetric2 Integer ipRouteMetric3 Integer ipRouteMetric4 Integer ipRouteNextHop IpAddress ipRouteType Integer ipRouteProto Integer ipRouteAge Integer ipRouteMask IpAddress ipRouteMetric5 Integer ipRouteInfo Object Identifier ipRouteDest Syntax IpAddress Access Read-write Status...
  • Page 50 ipRouteIfIndex Syntax Integer Access Read-write Status Mandatory Description The index value that uniquely identifies the local interface through which the next hop of this route should be reached. The interface identified by a particular value of this index is the same Note interface as identified by the same value of ifIndex.
  • Page 51 Status Mandatory Description An alternate routing metric for this route. The semantics of this metric are determined by the routing protocol Note specified in the route’s ipRouteProto value. If this metric is not used, its value should be set to -1. ipRouteMetric3 Syntax Integer...
  • Page 52 ipRouteNextHop Syntax IpAddress Access Read-write Status Mandatory Description The IP address of the next hop of this route. (In the case of a route bound to an interface that is realized using a broadcast media, the value of this field is the agent’s IP address on that interface.) ipRouteType Syntax...
  • Page 53 removes an invalidated entry from the table. Accordingly, management stations must be prepared to receive tabular information from agents that corresponds to entries not currently in use. Proper interpretation of such entries requires examination of the relevant ipRouteType object. ipRouteProto Syntax Value Declaration...
  • Page 54 Access Read-only Status Mandatory Description The routing mechanism by which this route has been learned. Inclusion of values for gateway routing protocols is not intended to Note imply that hosts should support those protocols. ipRouteAge Syntax Integer Access Read-write Status Mandatory Description The number of seconds since this route was last updated or otherwise...
  • Page 55 ipRouteDest field belongs to a class A, B, or C network, and then using one of the following: mask network 255.0.0.0 class-A 255.255.0.0 class-B 255.255.255.0 class-C If the value of the ipRouteDest is 0.0.0.0 (a default route), the mask value is also 0.0.0.0.

  • Page 56: Ip Address Translation Table

    Status Mandatory Description A reference to MIB definitions specific to the particular routing protocol that is responsible for this route, as determined by the value specified in the route’s ipRouteProto value. If this information is not present, its value should be set to the Object Identifier { 0 0 }, which is a syntactically valid object identifier, and any conferment implementation of ASN.1 and BER must be able to generate and recognize this value.
  • Page 57 Description Each entry contains one IP address to physical address equivalence. Index ipNetToMediaIfIndex, ipNetToMediaNetAddress Table 9. IpNetToMediaEntry Objects and Object Types IpNetToMediaEntry Objects See Page Object Types ipNetToMediaIfIndex Integer ipNetToMediaPhysAddress PhysAddress ipNetToMediaNetAddress IpAddress ipNetToMediaType Integer ipNetToMediaIfIndex Syntax Integer Access Read-write Status Mandatory Description...
  • Page 58 ipNetToMediaNetAddress Syntax IpAddress Access Read-write Status Mandatory Description The IP address corresponding to the media-dependent physical address. ipNetToMediaType Syntax Value Declaration Description Integer 1 (other) None of the following 2 (invalid) An invalidated mapping 3 (dynamic) 4 (static) Access Read-write Status Mandatory Description...

  • Page 59: Additional Ip Objects

    Additional IP Objects ipRoutingDiscards Syntax Counter Access Read-only Status Mandatory Description The number of routing entries that are chosen to be discarded even though they are valid. One possible reason for discarding such an entry could be to free-up buffer space for other routing entries. ICMP Group Implementation of the ICMP group is mandatory for all systems.
  • Page 60 Status Mandatory Description The number of ICMP messages that the entity received but determined as having ICMP-specific errors (bad ICMP checksums, bad length, and so on.). icmpInDestUnreachs Syntax Counter Access Read-only Status Mandatory Description The number of ICMP destination unreachable messages received. icmpInTimeExcds Syntax Counter...
  • Page 61 icmpInSrcQuenchs Syntax Counter Access Read-only Status Mandatory Description The number of ICMP source quench messages received. icmpInRedirects Syntax Counter Access Read-only Status Mandatory Description The number of ICMP redirect messages received. icmpInEchos Syntax Counter Access Read-only Status Mandatory Description The number of ICMP echo (request) messages received. icmpInEchoReps Syntax Counter...
  • Page 62 Status Mandatory Description The number of ICMP echo reply messages received. icmpInTimestamps Syntax Counter Access Read-only Status Mandatory Description The number of ICMP timestamp (request) messages received. icmpInTimestampReps Syntax Counter Access Read-only Status Mandatory Description The number of ICMP timestamp reply messages received. icmpInAddrMasks Syntax Counter...
  • Page 63 icmpInAddrMaskReps Syntax Counter Access Read-only Status Mandatory Description The number of ICMP address mask reply messages received. icmpOutMsgs Syntax Counter Access Read-only Status Mandatory Description The total number of ICMP messages that this entity attempted to send. This counter includes all messages counted by icmpOutErrors. Note icmpOutErrors Syntax...
  • Page 64 icmpOutDestUnreachs Syntax Counter Access Read-only Status Mandatory Description The number of ICMP destination unreachable messages sent. icmpOutTimeExcds Syntax Counter Access Read-only Status Mandatory Description The number of ICMP time exceeded messages sent. icmpOutParmProbs Syntax Counter Access Read-only Status Mandatory Description The number of ICMP parameter problem messages sent.
  • Page 65 Status Mandatory Description The number of ICMP source quench messages sent. icmpOutRedirects Syntax Counter Access Read-only Status Mandatory Description The number of ICMP redirect messages sent. For a host, this object is always zero, because hosts do not send redirects. icmpOutEchos Syntax Counter...
  • Page 66 icmpOutTimestamps Syntax Counter Access Read-only Status Mandatory Description The number of ICMP timestamp (request) messages sent. icmpOutTimestampReps Syntax Counter Access Read-only Status Mandatory Description The number of ICMP timestamp reply messages sent. icmpOutAddrMasks Syntax Counter Access Read-only Status Mandatory Description The number of ICMP address mask request messages sent.

  • Page 67: Tcp Group

    icmpOutAddrMaskReps Syntax Counter Access Read-only Status Mandatory Description The number of ICMP address mask reply messages sent. TCP Group Implementation of the TCP group is mandatory for all systems that implement the TCP. Instances of object types that represent information about a Note particular TCP connection are transient;...
  • Page 68 tcpRtoMin Syntax Integer Access Read-only Status Mandatory Description The minimum value permitted by a TCP implementation for the retransmission time-out, measured in milliseconds. More refined semantics for objects of this type depend upon the Note algorithm used to determine the retransmission time-out. In particular, when the time-out algorithm is rsre (3), an object of this type has the semantics of the LBOUND quantity described in RFC 793.
  • Page 69 tcpMaxConn Syntax Integer Access Read-only Status Mandatory Description The limit on the total number of TCP connections the entity can support. In entities where the maximum number of connections is dynamic, this object should contain the value -1. tcpActiveOpens Syntax Counter Access Read-only...
  • Page 70 tcpAttemptFails Syntax Counter Access Read-only Status Mandatory Description The number of times TCP connections have made a direct transition to the closed state from either the synsent state or the synReceived state, plus the number of times TCP connections have made a direct transition to the listen state from the synReceived state.
  • Page 71 tcpInSegs Syntax Counter Access Read-only Status Mandatory Description The total number of segments received, including those received in error. This count includes segments received on currently established connections. tcpOutSegs Syntax Counter Access Read-only Status Mandatory Description The total number of segments sent, including those on current connections but excluding those containing only retransmitted octets.

  • Page 72: Tcp Connection Table

    TCP Connection Table The TCP connection table contains information about this entity’s existing TCP connections. tcpConnTable Syntax Sequence of TcpConnEntry Access Not accessible Status Mandatory Description A table containing TCP connection-specific information. tcpConnEntry Syntax TcpConnEntry Access Not accessible Status Mandatory Description Information about a particular current TCP connection.
  • Page 73 Table 10. TcpConnEntry Objects and Object Types TcpConnEntry Objects See Page Object Types tcpConnState Integer tcpConnLocalAddress IpAddress tcpConnLocalPort Integer of size 0 to 65535 tcpConnRemAddress IpAddress tcpConnRemPort Integer of size 0 to 65535 tcpConnState Syntax Value Declaration Description Integer 1 (closed) 2 (listen) 3 (synSent) 4 (synReceived)
  • Page 74 Access Read-write Status Mandatory Description The state of this TCP connection. The only value which can be set by a management station is Note deleteTCB(12). Accordingly, it is appropriate for an agent to return a badValue response if a management station attempts to set this object to any other value.

  • Page 75: Additional Tcp Objects

    Status Mandatory Description The local port number for this TCP connection. tcpConnRemAddress Syntax IpAddress Access Read-only Status Mandatory Description The remote IP address for this TCP connection. tcpConnRemPort Syntax Integer of size 0 to 65535 Access Read-only Status Mandatory Description The remote port number for this TCP connection.

  • Page 76: Udp Group

    tcpOutRsts Syntax Counter Access Read-only Status Mandatory Description The number of TCP segments sent containing the RST flag. UDP Group Implementation of the UDP group is mandatory for all systems that implement the UDP. udpInDatagrams Syntax Counter Access Read-only Status Mandatory Description The total number of UDP datagrams delivered to UDP users.

  • Page 77: Udp Listener Table

    udpInErrors Syntax Counter Access Read-only Status Mandatory Description The number of received UDP datagrams that could not be delivered for reasons other than the lack of an application at the destination port. udpOutDatagrams Syntax Counter Access Read-only Status Mandatory Description The total number of UDP datagrams sent from this entity.
  • Page 78 udpEntry Syntax UdpEntry Access Not accessible Status Mandatory Description Information about a particular current UDP listener. Index udpLocalAddress, udpLocalPort Table 11. UdpEntry Objects and Object Types UdpEntry Objects See Page Object Types udpLocalAddress IpAddress udpLocalPort Integer of size 0 to 65535 udpLocalAddress Syntax IpAddress...

  • Page 79: Egp Group

    Status Mandatory Description The local port number for this UDP listener. EGP Group Implementation of the EGP group is mandatory for all systems that implement the EGP. egpInMsgs Syntax Counter Access Read-only Status Mandatory Description The number of EGP messages received without error. egpInErrors Syntax Counter...

  • Page 80: Egp Neighbor Table

    Status Mandatory Description The total number of locally generated EGP messages. egpOutErrors Syntax Counter Access Read-only Status Mandatory Description The number of locally generated EGP messages not sent due to resource limitations within an EGP entity. EGP Neighbor Table The EGP neighbor table contains information about this entity’s EGP neighbors.
  • Page 81 Description Information about this entity’s relationship with a particular EGP neighbor. Index egpNeighAddr Table 12. EgpNeighEntry Object and Object Types EgpNeighEntry Objects See Page Object Types egpNeighState Integer egpNeighAddr IpAddress egpNeighAs Integer egpNeighInMsgs Counter egpNeighInErrs Counter egpNeighOutMsgs Counter egpNeighOutErrs Counter egpNeighInErrMsgs Counter egpNeighOutErrMsgs...
  • Page 82 Value Declaration Description Integer 4 (up) 5 (cease) Access Read-only Status Mandatory Description The EGP state of the local system with respect to this entry’s EGP neighbor. Each EGP state is represented by a value that is one greater than the numerical value associated with said state in RFC 904.
  • Page 83 egpNeighInMsgs Syntax Counter Access Read-only Status Mandatory Description The number of EGP messages received without error from this EGP peer. egpNeighInErrs Syntax Counter Access Read-only Status Mandatory Description The number of EGP messages received from this EGP peer in error (for example, bad EGP checksum).
  • Page 84 egpNeighOutErrs Syntax Counter Access Read-only Status Mandatory Description The number of locally generated EGP messages not sent to this EGP peer due to resource limitations within an EGP entity. egpNeighInErrMsgs Syntax Counter Access Read-only Status Mandatory Description The number of EGP-defined error messages received from this EGP peer. egpNeighOutErrMsgs Syntax Counter...
  • Page 85 Status Mandatory Description The number of EGP state transitions to the up state with this EGP peer. egpNeighStateDowns Syntax Counter Access Read-only Status Mandatory Description The number of EGP state transitions from the up state to any other state with this EGP peer. egpNeighIntervalHello Syntax Integer...
  • Page 86 egpNeighMode Syntax Value Declaration Description Integer 1 (active) 2 (passive) Access Read-only Status Mandatory Description The polling mode of this EGP entity, either passive or active. egpNeighEventTrigger Syntax Value Declaration Description Integer 1 (start) 2 (stop) Access Read-write Status Mandatory Description A control variable used to trigger operator-initiated start and stop events.

  • Page 87: Additional Egp Objects

    event causes an idle peer to begin neighbor acquisition, and a nonidle peer to re-initiate neighbor acquisition. A stop event causes a nonidle peer to return to the idle state until a start event occurs, either using egpNeighEventTrigger or another object. Additional EGP Objects egpAs Syntax...

  • Page 88: Snmp Group

    SNMP Group Implementation of the SNMP group is mandatory for all systems that support an SNMP protocol entity. Some of the objects defined below will be zero-valued in those SNMP implementations that are optimized to support only those functions specific to either a management agent or a management station.
  • Page 89 Status Mandatory Description The total number of SNMP messages that were delivered to the SNMP protocol entity, and were for an unsupported SNMP version. snmpInBadCommunityNames Syntax Counter Access Read-only Status Mandatory Description The total number of SNMP messages delivered to the SNMP protocol entity that used an SNMP community name not known to said entity.
  • Page 90 SNMP 7 is not used. Note snmpInTooBigs Syntax Counter Access Read-only Status Mandatory Description The total number of SNMP PDUs that were delivered to the SNMP protocol entity, and for which the value of the error-status field is tooBig. snmpInNoSuchNames Syntax Counter Access...
  • Page 91 snmpInReadOnlys Syntax Counter Access Read-only Status Mandatory Description The total number valid SNMP PDUs that were delivered to the SNMP protocol entity, and for which the value of the error-status field is readOnly. It is a protocol error to generate an SNMP PDU that contains the Note value “readOnly”...
  • Page 92 snmpInTotalSetVars Syntax Counter Access Read-only Status Mandatory Description The total number of MIB objects that have been altered successfully by the SNMP protocol entity as the result of receiving valid SNMP Set-Request PDUs. snmpInGetRequests Syntax Counter Access Read-only Status Mandatory Description The total number of SNMP Get-Request PDUs that have been accepted and processed by the SNMP protocol entity.
  • Page 93 snmpInSetRequests Syntax Counter Access Read-only Status Mandatory Description The total number of SNMP Set-Request PDUs that have been accepted and processed by the SNMP protocol entity. snmpInGetResponses Syntax Counter Access Read-only Status Mandatory Description The total number of SNMP Get-Response PDUs that have been accepted and processed by the SNMP protocol entity.
  • Page 94 Status Mandatory Description The total number of SNMP PDUs that were generated by the SNMP protocol entity, and for which the value of the error-status field is tooBig. snmpOutNoSuchNames Syntax Counter Access Read-only Status Mandatory Description The total number of SNMP PDUs that were generated by the SNMP protocol entity, and for which the value of the error-status is noSuchName.
  • Page 95 Status Mandatory Description The total number of SNMP PDUs that were generated by the SNMP protocol entity, and for which the value of the error-status field is genErr. snmpOutGetRequests Syntax Counter Access Read-only Status Mandatory Description The total number of SNMP Get-Request PDUs that have been generated by the SNMP protocol entity.
  • Page 96 snmpOutGetResponses Syntax Counter Access Read-only Status Mandatory Description The total number of SNMP Get-Response PDUs that have been generated by the SNMP protocol entity. snmpOutTraps Syntax Counter Access Read-only Status Mandatory Description The total number of SNMP Trap PDUs that have been generated by the SNMP protocol entity.
  • Page 97 It is strongly recommended that this object be stored in nonvolatile Note memory, so that the object remains constant between re-initializations of the network management system. egpNeighborLoss Enterprise SNMP Variables egpNeighAddr Description An egpNeighborLoss trap signifies that an EGP neighbor, for which the sending protocol entity was an EGP peer, has been marked down and the peer relationship no longer pertains.
  • Page 98 MIB Reference Manual...

  • Page 99: Fibre Alliance Mib Object Types

    FIBRE ALLIANCE MIB OBJECT TYPES This chapter contains descriptions and other information specific to Fibre Alliance MIB (FCMGMT-MIB) object type. The object types in FAMGMT-MIB are organized into the following groupings: • Connectivity • Trap Registration • Revision Number • Statistic Set FAMGMT-MIB File System Organization Figure 5 through Figure 7 depict the organization and structure of the FAMGMT file system.
  • Page 100 Figure 6 Figure 7 Figure 7 Figure 5. FAMGMT Overall Tree Structure MIB Reference Manual...
  • Page 101 Figure 6. Tree Structure for connSet Tables Fibre Alliance MIB Object Types...
  • Page 102 Figure 7. Tree Structure for trapReg Table and statSet Tables MIB Reference Manual...

  • Page 103: Definitions For Famgmt-Mib

    Definitions for FAMGMT-MIB The following definitions are used for FAMGMT-MIB. Table 13. FAMGMT-MIB Definitions Type Definition Value Declaration Description FcNameId Octet String of size 8 FcGlobalId Octet String of size 16 FcEventSeverity Integer 1 (unknown) 2 (emergency) Emergency status. 3 (alert) Alert status.

  • Page 104: Connectivity Group

    Table 13. FAMGMT-MIB Definitions (continued) Type Definition Value Declaration Description 5 (gateway) Unit that converts not only the interface but also encapsulates the frame into another protocol. The assumption is that there are always two gateways connected together. For example, FC <-> ATM. 6 (converter) Unit that converts from one interface to another.
  • Page 105 Status Mandatory Description The number of connectivity units present on this system (represented by this agent). Can be a count of the boards in a chassis, or the number of full boxes in a rack. The connectivity unit is mapped to a switch. Note uNumber.0 is always set to 1.
  • Page 106 The expected value for systemURL.0 is: Note “http://{a.b.c.d}” where {a.b.c.d} is the IP address of the switch. “” (null) statusChangeTime Syntax Time Ticks Access Read-only Status Deprecated Description The sysuptime timestamp (in centiseconds) at which the last status change occurred for any members of the set. In other words, this is the latest timestamp that connUnitStatus or connUnitPortStatus has changed.

  • Page 107: Connectivity Unit Table

    connUnitTableChangeTime Syntax Time Ticks Access Read-only Status Deprecated Description The sysuptime timestamp (in centiseconds) at which the connUnitTable was updated (an entry was either added or deleted). The time is set at initialization of the connectivity table (connUnitTable) The connectivity unit table contains general information on the Note system’s units.
  • Page 108 Description A connectivity unit entry containing objects for a particular unit. Index connUnitId Table 14. connUnitEntry Objects and Object Types connUnitEntry Objects See Page Object Types connUnitId Octet String connUnitGlobalId FcGlobalId connUnitType FcUnitType connUnitNumports Integer connUnitState Integer connUnitStatus Integer connUnitProduct Display String connUnitSn Display String...
  • Page 109 Table 14. connUnitEntry Objects and Object Types (continued) connUnitEntry Objects See Page Object Types connUnitContact Display String connUnitLocation Display String connUnitEventFilter FcEventSeverity connUnitNumEvents Integer connUnitMaxEvents Integer connUnitEventCurrID Integer connUnitId [connUnitTable] Syntax Octet String of size 16 Access Read-only Status Mandatory Description The unique identification for this connectivity unit among those within this proxy domain.
  • Page 110 The HP FC 6164 implementation treats this ID as a very large Note (128-bit) integer, starting from 1. Therefore, in order to specify a particular instance of any columnar variable in the connUnitEntry (such as connUnitType), specify the instance identifier as a 16-octet value. For example: connUnitType.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.1 where the object instance identifier consists of 16 octets,...
  • Page 111 The following characteristics are strongly recommended: When a nonzero value is provided, it should be persistent across agent and unit resets. • This value should be globally unique. • This value should be one of these FC-PH/PH3 formats: – IEEE (NAA=1) –...
  • Page 112 The HP FC 6164 implementation maps the switch WWN to the top Note 8 bytes of this variable and sets the remaining lower 8 bytes to 0. For example, if the switch WWN is 10:00:00:60:69:10:02:18, SNMP-GET connUnitGlobalId.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.1 returns 10 00 00 60 69 10 02 18 00 00 00 00 00 00 00 00. connUnitType [connUnitTable] Syntax FcUnitType...
  • Page 113 connUnitState [connUnitTable] Syntax Value Declaration Description Integer 1 (unknown) 2 (online) Set the state to online 3 (offline) Set the state to offline Access Read-only Status Mandatory Description Overall state of the connectivity unit. Mapped as follows: Note switchState(ONLINE) 2 (online) switchState(not ONLINE) 3 (offline) (offline, testing, faulty)
  • Page 114 Status Mandatory Description Overall status of the connectivity unit. switchStatus maps directly as follows: Note connUnitStatus switchStatus 1 (unknown) Unknown 2 (unused) Unmonitored 3 (ok) Healthy/ok 4 (warning) Marginal/Warning 5 (failed) Down/Failed connUnitProduct [connUnitTable] Syntax Display String of size 0 to 79 Access Read-only Status...
  • Page 115 Status Mandatory Description The serial number for this connectivity unit. Set to the SSN, which by default is the WWN, but is changeable Note through Telnet. connUnitUpTime [connUnitTable] Syntax Time Ticks Access Read-only Status Mandatory Description The number of centiseconds since the last unit initialization. Set when connUnitTable is initialized.
  • Page 116 Same as systemURL. The expected value for connUnitURL.0 is: Note “http://{a.b.c.d}” where {a.b.c.d} is the IP address of the switch. “” (null) connUnitDomainId [connUnitTable] Syntax Octet String of size 3 Access Read-only Status Mandatory Description The 24-bit fibre channel address ID of this connectivity unit, right justified with leading zeros if required.
  • Page 117 Access Read-only Status Mandatory Description A value of “yes” means this is the proxy master unit for a set of managed units. For example, this could be the only unit with a management card in it for a set of units. A standalone unit should return “yes” for this object. Set to 2 (no).
  • Page 118 Status Mandatory Description Number of sensors in the connUnitSensorTable. The number of sensors includes the following: Note SW2010/40/50 SW2400 Note SW2800: 13 (5 temp + 6 fans + 2 power supplies) connUnitStatusChangeTime [connUnitTable] Syntax Time Ticks Access Read-only Status Deprecated Description The sysuptime timestamp (in centiseconds) at which the last status change occurred for any members of the set.
  • Page 119 Status Deprecated Description The sysuptime timestamp (in centiseconds) at which the last configuration change occurred for any members of the set. In other words, this is the latest timestamp of Flash memory update. This represents a union of change information for connUnitConfigurationChangeTime. This is the same as configurationChangeTime.
  • Page 120 connUnitModuleId [connUnitTable] Syntax Octet String of size 16 Access Read-only Status Mandatory Description This is a unique ID, persistent between boots, that can be used to group a set of connUnits together into a module. This ID creates a connUnit with a connUnitType of “module”...
  • Page 121 connUnitInfo Syntax Display String Access Read-write Status Mandatory Description A display string containing information about this connectivity unit. This object value should be persistent between boots. Set to null and read-only. Note connUnitControl [connUnitTable] Syntax Value Declaration Description Integer 1 (unknown) 2 (invalid) 3 (resetConnUnitColdStart) Reboot;...
  • Page 122 Value Declaration Description Integer 6 (onlineConnUnit) Enable switch; the addressed unit puts itself into an implementation-dependant online state. In general, if a unit is in an online state, it is capable of performing meaningful fibre channel work. Access Read-write Status Mandatory Description Controls the addressed connUnit.
  • Page 123 Status Mandatory Description Contact information for this connectivity unit. Set to sysContact. Note connUnitLocation [connUnitTable] Syntax Display String of size 0 to 79 Access Read-write Status Mandatory Description Location information for this connectivity unit. Set to sysLocation. Note connUnitEventFilter [connUnitTable] Syntax FcEventSeverity Access...
  • Page 124 connUnitNumEvents Syntax Integer Access Read-only Status Mandatory Description Number of events currently in connUnitEventTable. Returns the number of events that are currently in the buffer. Note connUnitMaxEvents [connUnitTable] Syntax Integer Access Read-only Status Mandatory Description Maximum number of events that can be defined in connUnitEventTable. Maximum buffer is 2147483647 Note connUnitEventCurrID [connUnitTable]...

  • Page 125: Elements

    Connectivity Unit Table of Revisions for Hardware/Software Elements connUnitRevsTable Syntax Sequence of connUnitRevsEntry Access Not accessible Status Mandatory Description Table of the revisions supported by connectivity units managed by this agent. This table lists the versions of hardware and software elements in the Note switch.
  • Page 126 Table 15. connUnitRevsEntry Objects and Object Types connUnitRevsEntry Objects See Page Object Types connUnitRevsUnitId Octet String connUnitRevsIndex Integer connUnitRevsRevId Display String connUnitRevsDescription Display String connUnitRevsUnitId [connUnitRevsTable] Syntax Octet String of size 16 Access Read-only Status Mandatory Description The connUnitId of the connectivity unit that contains this revision table. connUnitRevsIndex [connUnitRevsTable] Syntax Integer of size 1 to 2147483647...

  • Page 127: Connectivity Unit Sensor Table

    connUnitRevsRevId [connUnitRevsTable] Display String Syntax Access Read-only Status Mandatory Description A vendor-specific string identifying a revision of a component of the connUnit indexed by connUnitRevsUnitId. Index 1 returns the switchType from the Telnet command Note switchShow. Index 2 returns the Fabric OS version from the Telnet command version, for example, v2.2.
  • Page 128 Status Mandatory Description Table of the sensors supported by each connectivity unit managed by this agent. connUnitSensorEntry [connUnitSensorTable] Syntax connUnitSensorEntry Access Not accessible Status Mandatory Description Each entry contains the information for a specific sensor. Index connUnitSensorUnitId, connUnitSensorIndex Table 16. connUnitSensorEntry Objects and Object Types connUnitSensorEntry Objects See Page Object Types...
  • Page 129 connUnitSensorUnitId [connUnitSensorTable] Syntax Octet String of size 16 Access Read-only Status Mandatory Description The connUnitId of the connectivity unit that contains this sensor table. Set to connUnitId. Note connUnitSensorIndex [connUnitSensorTable] Syntax Integer of size 1 to 2147483647 Access Read-only Status Mandatory Description A unique value among all connUnitSensorEntrys with the same value of...
  • Page 130 Each contains the name of the sensor in textual format. (For Note example, Temp #1, Fan #2, and so on.) connUnitSensorStatus [connUnitSensorTable] Syntax Value Declaration Description Integer 1 (unknown) 2 (other) 3 (ok) The sensor indicates ok. 4 (warning) The sensor indicates a warning. 5 (failed) The sensor indicates failure.
  • Page 131 Each contains textual information about the sensor name. Note Returns the serial ID if this is for the power supply. Otherwise, it returns null. connUnitSensorMessage [connUnitSensorTable] Syntax Display String Access Read-only Status Mandatory Description This describes the status of the sensor as a message and can provide more resolution on the sensor indication.
  • Page 132 Value Declaration Description Integer 8 (board) 9 (receiver) Access Read-only Status Mandatory Description The type of component being monitored by this sensor. The following mapping is for each sensor, where applicable: Note swSensorType connUnitSensorType 1 (temperature) 8 (board) 2 (fan) 4 (fan) 3 (power supply) 5 (power supply)

  • Page 133: Connectivity Unit Port Table

    Value Declaration Description Integer 8 (frequency) 9 (power) Access Read-only Status Mandatory Description The characteristics being monitored by this sensor. The following mapping is for each sensor, where applicable: Note swSensorType connUnitSensorCharacteristic 1 (temperature) 3 (temperature) 2 (fan) 7 (airflow) 3 (power supply) 9 (power) Connectivity Unit Port Table...
  • Page 134 connUnitPortEntry [connUnitPortTable] Syntax connUnitPortEntry Access Not accessible Status Mandatory Description Each entry contains the information for a specific port. connUnitPortUnitId, connUnitPortIndex Index Table 17. connUnitPortEntry Objects and Object Type connUnitPortEntry Objects See Page Object Types connUnitPortUnitId Octet String connUnitPortIndex Integer connUnitPortType Integer connUnitPortFCClassCap...
  • Page 135 Table 17. connUnitPortEntry Objects and Object Type (continued) connUnitPortEntry Objects See Page Object Types connUnitPortName Display String connUnitPortPhysicalNumber Integer connUnitPortStatObject Object Identifier connUnitPortUnitId [connUnitPortTable] Syntax Octet String of size 16 Access Read-only Status Mandatory Description The connUnitId of the connectivity unit that contains this port. Same value as connUnitId.
  • Page 136 connUnitPortType [connUnitPortTable] Syntax Integer Value Declaration Description Integer 1 (unknown) 2 (other) 3 (not-present) 4 (hub-port) 5 (n-port) End port for fabric 6 (l-port) End port for loop 7 (fl-port) Public loop 8 (f-port) Fabric port 9 (e-port) Fabric expansion port 10 (g-port 1) Generic fabric port 11 (domain-ctl)
  • Page 137 Mapped as: Note U-Port 10 (g-port) F-Port 8 (f-port) FL-Port 7 (fl-port) E-Port 9 (e-port) connUnitPortFCClassCap [connUnitPortTable] Syntax Octet String of size 2 Access Read-only Status Mandatory Description Bit mask that specifies the classes of service capability of this port. If this is not applicable, return all bits set to zero.
  • Page 138 For an F or FL port, this value is 0x000C. For a G or E port, this Note value is 0x000D. connUnitPortFCClassOp [connUnitPortTable] Syntax Octet String of size 2 Access Read-only Status Mandatory Description Bit mask that specifies the classes of service that are currently operational. If this is not applicable, return all bits set to zero.
  • Page 139 For an E, F, or FL port, the value is online. For a U port, the value is Note offline (disabled, testing, faulted). connUnitPortStatus [connUnitPortTable] Syntax Value Declaration Description Integer 1 (unknown) Needs attention 2 (unused) 3 (ok) 4 (warning) 5 (failure) 6 (not participating) 7 (initializing)
  • Page 140 connUnitPortTransmitterType [connUnitPortTable] Syntax Value Declaration Description Integer 1 (unknown) 2 (other) 3 (unused) 4 (shortwave) 5 (longwave) 7 (scsi) 8 (longwaveNoOFC) 9 (shortwaveNoOFC) 10 (longwaveLED) Access Read-only Status Mandatory Description The technology of the port transceiver. For an external FC port, this value should be 9 (shortwaveNoOFC) Note or 8 (longwaveNoOFC).
  • Page 141 connUnitPortModuleType [connUnitPortTable] Syntax Value Declaration Description Integer 1 (unknown) 2 (other) 3 (GBIC) 4 (embedded) Fixed (oneXnine) 5 (glm) 6 (gbicSerialId) 7 (gbicNoSerialId) 8 (gbicNotInstalled) 9 (smallFormFactor) Access Read-only Status Mandatory Description The module type of the port connector. For an external FC port with GBIC, this value should be 6 Note (gbicSerialId) or 7 (gbicNoSerialId).
  • Page 142 Status Mandatory Description The worldwide Name (WWN) of the port if applicable, otherwise returns an empty string. This is in IEEE Extended format, and the extension contains the internal port number of each port. The internal port number is 1 less than the port index. For example, Note if the switch has WWN 10:00:00:60:69:10:02:18, port numbers 0 and 6 have WWN 20:00:00:60:69:10:02:18 and 20:06:00:60:69:10:02:18,...
  • Page 143 connUnitPortSn [connUnitPortTable] Syntax Display String of size 0 to 79 Access Read-only Status Mandatory Description The serial number of the unit (for example, for a GBIC). If this is not applicable, returns an empty string. If GBIC is the serial ID, this returns the GBIC part number. Note Otherwise it returns a null value.
  • Page 144 If GBIC is the serial ID, this returns the GBIC vendor name. Note Otherwise it returns a null value. connUnitPortSpeed [connUnitPortTable] Syntax Integer Access Read-only Status Mandatory Description The speed of the port in kilobytes per second. The valid values for each of the HP FC 6164 switches is 10 Note connUnitPortControl [connUnitPortTable] Syntax...
  • Page 145 Access Read-write (or possibly write-only) Status Mandatory Description Controls the addressed connUnit port. Valid commands are: • resetConnUnitPort: If the addressed connUnit allows this operation to be performed to this port, the addressed port performs a vendor-specific reset operation. Examples of these operations are: –...
  • Page 146 • offlineConnUnitPort: If the addressed connUnit allows this operation to be performed to this port, the addressed port performs a vendor-specific offline operation. Examples of these operations are: – Disabling a ports transceiver – Link Failure protocol – Request (NONPARTICIPATING) command to the Loop Port state machine •...
  • Page 147 onlineConnUnitPort - portEnable (U). resetConnUnitPortCounters - clear the port stats counter. When rebooted, this defaults to 1 (unknown) connUnitPortName [connUnitPortTable] Syntax Display String Access Read-write Status Mandatory Description A string describing the addressed port. For an external FC port, this enables the port for the embedded port, Note thus enabling the switch.
  • Page 148 Status Mandatory Description This is the internal port number by which this port is known. In many implementations, this should be the same as connUnitPortIndex. Some implementations can have an internal port representation that is not compatible with the rules for table indices. In that case, provide the internal representation of this port in this object.

  • Page 149: Connectivity Unit Event Table

    Connectivity Unit Event Table connUnitEventTable Syntax Sequence of connUnitEventEntry Access Not accessible Status Mandatory Description The table of connectivity unit events. Errors, warnings, and information should be reported in this table. connUnitEventEntry [connUnitEventTable] Syntax connUnitEventEntry Access Not accessible Status Mandatory Description Each entry contains information on a specific event for the given connectivity unit.
  • Page 150 Table 18. connUnitEventEntry Objects and Object Types (continued) connUnitEventEntry Objects See Page Object Types connUnitEventSeverity FcEventSeverity connUnitEventType Integer connUnitEventObject Object Identifier connUnitEventDescr Display String connUnitEventUnitId [connUnitEventTable] Syntax Octet String of size 16 Access Read-only Status Mandatory Description The connUnitId of the connectivity unit that contains this event table. Same as connUnitId.
  • Page 151 the read interval is too long, there can be events that cannot be contained in the agent’s internal event buffer. For example, an agent can read events 50 through 75. At the next read interval, connUnitEventCurrID is 189. If the management app tries to read event index 76, and the agent’s internal buffer is 100 entries max, event index 76 is no longer available.
  • Page 152 connUnitREventTime [connUnitEventTable] Syntax Display String of size 15 Access Read-only Status Mandatory Description This is the real time when the event has occurred, and has the following format: DDMMYYYY HHMMSS where: DD = day number MM = month number YYYY = year number HH = hour number MM = minute number SS = seconds number...
  • Page 153 connUnitEventSeverity [connUnitEventTable] Syntax FcEventSeverity Access Read-only Status Mandatory Description The event severity level. Severity is explained in the front of this chapter. See Note FcEventSeverity in Table connUnitEventType [connUnitEventTable] Syntax Value Declaration Description Integer 1 (unknown) 2 (other) 3 (status) 4 (configuration) 5 (topology) Access...
  • Page 154 connUnitEventObject [connUnitEventTable] Syntax Object Identifier Access Read-only Status Mandatory Description This is used with connUnitEventType to identify to which object the event refers. It can be the OID of a connectivity unit or of another object, for example connUnitPortStatus[...]. Always set to null. Note connUnitEventDescr [connUnitEventTable] Syntax...

  • Page 155: Connectivity Unit Link Table

    information must include either a nonzero connUnitNodeId, or a nonzero connUnitPortWwn, for each end of the link. If the agent is able to discover links that do not directly attach to members of its agency, and the agent’s discovery algorithm gives some assurance that the links are recently valid, it can include these links.
  • Page 156 Status Mandatory Description A list of links know to this agent from this connectivity unit to other connectivity units. X = switch data, Y = other end. Note connUnitLinkEntry [connUnitLinkTable] Syntax connUnitLinkEntry Access Not accessible Status Mandatory Description An entry describing a particular link to another. Index connUnitLinkUnitId, connUnitLinkIndex Table 19.
  • Page 157 Table 19. connUnitLinkTable Objects and Object Types (continued) connUnitLinkTable Objects See Page Object Types connUnitLinkAgentPortY Integer connUnitLinkUnitTypeY FcUnitType connUnitLinkConnIdY Octet String connUnitLinkUnitId [connUnitLinkTable] Syntax Octet String of size 16 Access Read-only Status Mandatory Description The connUnitId of the connectivity unit that contains this link table. Set to WWN of the local switch.
  • Page 158 Indices 1 through 16 are reserved for ISL Note Indices 17 and higher are reserved for end devices, and are calculated based on portID of the end devices. connUnitLinkNodeIdX [connUnitLinkTable] Syntax Octet String of size 64 Access Read-only Status Mandatory Description The node WWN of the unit at one end of the link.
  • Page 159 connUnitLinkPortWwnX [connUnitLinkTable] Syntax Octet String of size 16 Access Read-only Status Mandatory Description The port WWN of the unit specified by connUnitLinkNodeIdX, if known; otherwise 16 octets of binary 0. WWN of the port to which the device is connected. Note connUnitLinkNodeIdY [connUnitLinkTable] Syntax...
  • Page 160 Status Mandatory Description The port number on the unit specified by connUnitLinkNodeIdY if known, otherwise -1. If the value is nonnegative, it is equal to connUnitPortPhysicalNumber. ISL: Physical port number of the remote port. Note Device: -1. connUnitLinkPortWwnY [connUnitLinkTable] Syntax Octet String of size 16 Access Read-only...
  • Page 161 ISL: IP address (v6). Note Device: 0 (null). connUnitLinkAgentAddressTypeY [connUnitLinkTable] Syntax Integer Access Read-only Status Mandatory Description If connUnitLinkAgentAddressY is nonzero, it is a protocol address. ConnUnitLinkAgentAddressTypeY is the “address family number” assigned by IANA to identify the address format. (For example, 1 is Ipv4, 2 is Ipv6).
  • Page 162 connUnitLinkUnitTypeY [connUnitLinkTable] Syntax FcUnitType Access Read-only Status Mandatory Description Type of the FC connectivity unit as defined in connUnitType. ISL: Switch device. Note End devices: (End device types based on an FCP inquiry) Storage System Storage Sub-system Unknown Other Direct Access Medium Changer Unknown Anything else...

  • Page 163: Snmp Trap Registration Group

    Status Mandatory Description This is the fibre channel ID of this port. If the connectivity unit is a switch, this is expected to be a Big Endian value of 24 bits. If this is loop, it is the ALPA that is connected. If this is an E port, it contains only the domain ID. If not any of those, unknown or cascaded loop, return all bits set to 1.

  • Page 164: Snmp Trap Registration Table

    Number of valid entries. Note SNMP Trap Registration Table trapRegTable Syntax Sequence of trapRegEntry Access Not accessible Status Mandatory Description A table containing a row for each IP address/port number to which traps are sent. trapRegEntry [trapRegTable] Syntax trapRegEntry Access Not accessible Status Mandatory...
  • Page 165 trapRegIpAddress [trapRegTable] Syntax IpAddress Access Read-only Status Mandatory Description The IP address of a client registered for traps. trapRegPort [trapRegTable] Syntax Integer of size 1 to 2147483647 Access Read-only Status Mandatory Description The UDP port to send traps to for this host. Normally this is the standard trap port(162).
  • Page 166 This severity applies to all entries. See FcEventSeverity in Table Note trapRegRowState [trapRegTable] Syntax Value Declaration Description Integer 1 (rowDestroy) Remove row from table. 2 (rowInactive) Row exists, but TRAPs disabled. 3 (rowActive) Row exists and is enabled for sending traps.

  • Page 167: Revision Number

    Table 21. TrapRegRowState for Read-Write (continued) TrapRegRowState Read Write rowActive Indicates that this row If the row does not exists, and that traps are exist, and the agent enabled to be sent to the allows writes to the trap target. table, then a new row is created.

  • Page 168: Statistics Group

    The value is stored as an ASCII value. The following is the current value of this object. 0 = “0” 1 = “2” 2 = “2” 3 = “0” This defines a revision of 02.20. Set to 0220. Note Statistics Group Following is a statistics table for each port type class.
  • Page 169 Status Mandatory Description A list of statistics for the hub port type. connUnitPortStatHubEntry [connUnitPortStatHubTable] Syntax connUnitPortStatHubEntry Access Not accessible Status Mandatory Description An entry describing port statistics. connUnitPortStatHubUnitId, connUnitPortStatHubIndex Index Table 22. connUnitPortStatHubEntry Objects and Object Types connUnitPortStatHubEntry Objects See Page Object Types connUnitPortStatHubUnitId Octet String...
  • Page 170 Status Mandatory Description The connUnitId of the connectivity unit that contains this port statistic table. connUnitPortStatHubIndex [connUnitPortStatHubTable] Syntax Integer of size 0 to 2147483647 Access Read-only Status Mandatory Description A unique value among all entries in this table, between 0 and connUnitNumPort.

  • Page 171: Connectivity Unit Port Statistics Fabric Table

    connUnitPortStatHubCountRxFrame [connUnitPortStatHubTable] Syntax Octet String of size 8 Access Read-only Status Mandatory Description The number of frames that have been received by this port. connUnitPortStatHubCountTxOctets [connUnitPortStatHubTable] Syntax Octet String of size 8 Access Read-only Status Mandatory Description The number of octets that have been transmitted by this port. connUnitPortStatHubCountRxOctets [connUnitPortStatHubTable] Syntax Octet String of size 8...
  • Page 172 Status Mandatory Description A list of statistics for the fabric port types. connUnitPortStatFabricEntry [connUnitPortStatFabricTable] Syntax connUnitPortStatFabricEntry Access Not accessible Status Mandatory Description An entry describing port statistics. connUnitPortStatFabricUnitId, connUnitPortStatFabricIndex Index Table 23. connUnitPortStatFabricEntry Objects and Object Types connUnitPortStatFabricEntry Objects See Page Object Types connUnitPortStatFabricUnitId Octet String...
  • Page 173 Status Mandatory Description The connUnitId of the connectivity unit that contains this port statistic table. connUnitPortStatFabricIndex [connUnitPortStatFabricTable] Syntax Integer of size 0 to 2147483647 Access Read-only Status Mandatory Description A unique value among all entries in this table, between 0 and connUnitNumPort.
  • Page 174 Status Mandatory Description The number of frames that have been transmitted by this port. Returns swFCPortTxFrames. Note connUnitPortStatFabricCountRxFrame [connUnitPortStatFabricTable] Syntax Octet String of size 8 Access Read-only Status Mandatory Description The number of frames that have been received by this port. Returns swFCPortRxFrames.

  • Page 175: Connectivity Unit Port Statistics Scsi Table

    Status Mandatory Description The number of octets that have been received by this port. Returns four times the value of swFCPortRxWords. Note Connectivity Unit Port Statistics SCSI Table The HP FC 6164 does not support SCSI statistics; this section is not Note applicable.
  • Page 176 connUnitPortStatSCSIUnitId, connUnitPortStatSCSIIndex Index Table 24. connUnitPortStatSCSIEntry Objects and Object Types connUnitPortStatSCSIEntry Objects See Page Object Types connUnitPortStatSCSIUnitId Octet String connUnitPortStatSCSIIndex Integer connUnitPortStatSCSICountError Octet String connUnitPortStatSCSICountTxIO Octet String connUnitPortStatSCSICountRxIO Octet String connUnitPortStatSCSICountTxBytes Octet String connUnitPortStatSCSICountRxBytes Octet String connUnitPortStatSCSIUnitId [connUnitPortStatSCSITable] Syntax Octet String of size 16 Access Read-only Status...
  • Page 177 connUnitPortStatSCSICountError [connUnitPortStatSCSITable] Syntax Octet String of size 8 Access Read-only Status Mandatory Description A count of the errors that have occurred on this port. connUnitPortStatSCSICountTxIO [connUnitPortStatSCSITable] Syntax Octet String of size 8 Access Read-only Status Mandatory Description The number of I/Os that have been transmitted by this port. connUnitPortStatSCSICountRxIO [connUnitPortStatSCSITable] Syntax Octet String of size 8...

  • Page 178: Connectivity Unit Port Statistics Lan/Wan Table

    Status Mandatory Description The number of bytes that have been transmitted by this port. connUnitPortStatSCSICountRxBytes [connUnitPortStatSCSITable] Syntax Octet String of size 8 Access Read-only Status Mandatory Description The number of bytes that have been received by this port. Connectivity Unit Port Statistics LAN/WAN Table The HP FC 6164 does not support LAN/WAN statistics;...
  • Page 179 Status Mandatory Description An entry describing port statistics. connUnitPortStatLANUnitId, connUnitPortStatLANIndex Index Table 25. connUnitPortStatLANEntry Objects and Object Types connUnitPortStatLANEntry Objects See Page Object Types connUnitPortStatLANUnitId Octet String connUnitPortStatLANIndex Integer connUnitPortStatLANCountError Octet String connUnitPortStatLANCountTxPacket Octet String connUnitPortStatLANCountRxPacket Octet String connUnitPortStatLANCountTxBytes Octet String connUnitPortStatLANCountRxBytes Octet String connUnitPortStatLANUnitId [connUnitPortStatLANTable]...
  • Page 180 Status Mandatory Description A unique value among all entries in this table, between 0 and connUnitNumPort. connUnitPortStatLANCountError [connUnitPortStatLANTable] Syntax Octet String of size 8 Access Read-only Status Mandatory Description A count of the errors that have occurred on this port. connUnitPortStatLANCountTxPacket [connUnitPortStatLANTable] Syntax Octet String of size 8...

  • Page 181: Related Traps

    connUnitPortStatLANCountTxBytes [connUnitPortStatLANTable] Syntax Octet String of size 8 Access Read-only Status Mandatory Description The number of bytes that have been transmitted by this port. connUnitPortStatLANCountRxBytes [connUnitPortStatLANTable] Syntax Octet String of size 8 Access Read-only Status Mandatory Description The number of bytes that have been received by this port. Related Traps connUnitStatusChange Enterprise...
  • Page 182 connUnitDeletedTrap Enterprise fcmgmt Variables connUnitId Description A connUnit has been deleted from this agent. Recommended severity level (for filtering): warning. Not implemented. Note connUnitEventTrap Enterprise fcmgmt Variables connUnitEventId, connUnitEventType, connUnitEventObject, connUnitEventDescr Description An event has been generated by the connectivity unit. Recommended severity level (for filtering): info.
  • Page 183 connUnitPortStatusChange fcmgmt Enterprise Variables connUnitPortStatus, connUnitPortState Overall status of the connectivity unit changed. Recommended severity Description level (for filtering): alert. Fibre Alliance MIB Object Types...
  • Page 184 MIB Reference Manual...

  • Page 185: Fc Fabric Element Mib Object Types

    FC FABRIC ELEMENT MIB OBJECT TYPES This chapter contains information that is specific to FC Fabric Element MIB (FE-MIB) object types. The object types in FE-MIB are organized into five groupings: • Configuration • Operation • Error • Accounting • Capability FE-MIB File System Organization Figure 8 through...
  • Page 186 Figure 8. FE-MIB Overall Tree Structure MIB Reference Manual...
  • Page 187 Figure 9. Tree Structure for fcFeConfig and fcFeOpTables FC Fabric Element MIB Object Types...
  • Page 188 Figure 10. Tree Structure for fcFeError, fcFeAcct, and fcFeCap Tables MIB Reference Manual...

  • Page 189: Definitions For Fe-Mib

    Definitions for FE-MIB Table 26 lists the definitions that are used for FE-MIB. Table 26. MIB-II Conventions Type Definition Value Declaration Description Display String Octet String of size 0 to MilliSeconds Integer from 0 2147383647 MicroSeconds Integer from 0 2147383647 FcNameId Octet String Name_Identifier hex...
  • Page 190 Table 26. MIB-II Conventions (continued) Type Definition Value Declaration Description FabricName Octet String IEEE48 of size 8 FcNameId - The Local Name Identifier of a Fabric. Each Fabric provides a unique Fabric Name. FabricName Octet String IEEE48 of size 8 FcNameId - The IEEE extended Name Identifier...
  • Page 191 Table 26. MIB-II Conventions (continued) Type Definition Value Declaration Description FcCosCap Integer from 1 bit 0 (Class F) to 127 bit 1 (Class 1) bit 2 (Class 2) bit 3 (Class 3) bit 4 (Class 4) bit 5 (Class 5) bit 6 (Class 6) bit 7 (Reserved for future) Fc0BaudRate...
  • Page 192 Table 26. MIB-II Conventions (continued) Type Definition Value Declaration Description Fc0BaudRateCap Integer from 0 bit 0 (other) to 127 bit 1 (oneEighth) bit 2 (quarter) bit 3 (half) bit 4 (full) bit 5 (double) bit 6 (quadruple) bit 7 (Reserved for future) MIB Reference Manual...
  • Page 193 Table 26. MIB-II Conventions (continued) Type Definition Value Declaration Description Fc0MediaCap Integer from 0 bit 0 (unknown) to 65535 bit 1 (single mode fibre [sm]) bit 2 (multi-mode fibre 50 micron [m5]) bit 3 (multi-mode fibre 62.5 micron [m6]) bit 4 (video cable [tv]) bit 5 (miniature cable [mi]) bit 6 (shielded twisted pair [stp])
  • Page 194 Table 26. MIB-II Conventions (continued) Type Definition Value Declaration Description Fc0Medium Integer 1 (unknown) 2 (sm) 4 (m5) 8 (m6) 16 (tv) 32 (mi) 64 (stp) 128 (tw) 256 (lv) Fc0TxType Integer 1 (unknown) 2 (longWaveLaser [LL]) 3 (shortWaveLaser [SL]) 4 (longWaveLED [LE]) 5 (electrical [EL]) 6 (shortWaveLaser-noOFC...
  • Page 195 Table 26. MIB-II Conventions (continued) Type Definition Value Declaration Description Fc0Distance Integer The FC-0 distance range associated with a port transmitter 1 (unknown) 2 (long) 3 (intermediate) 4 (short) FcFeModuleCapacity Integer from 1 to 256 FcFeFxPortCapacity Integer from 1 to 256 FcFeModuleIndex Integer from 1 to 256...

  • Page 196: Configuration Group

    Configuration Group The configuration group consists of scalar objects and tables, and contains the configuration and service parameters of the Fabric Element and the FxPorts. This group represents a set of parameters associated with the Fabric Element or an FxPort to support its NxPorts. Implementation of this group is mandatory.

  • Page 197: Fc Fabric Element Module Table

    fcFeModuleCapacity Syntax FcFeModuleCapacity Access Read-only Status Mandatory Description The maximum number of modules in the Fabric Element, regardless of their current state. Note SW2010/40/50: 1 SW2400: 1 SW2800: 1 fc Fabric Element Module Table This table contains one entry for each module. fcFeModuleTable Syntax Sequence of FcFeModuleEntry...
  • Page 198 Status Mandatory Description An entry containing the configuration parameters of a module. Index fcFeModuleIndex Table 27. fcFeModuleEntry Objects and Object Types fcFeModuleEntry Objects See Page Object Types fcFeModuleIndex FcFeModuleIndex fcFeModuleDescr Display String fcFeModuleObjectID Object Identifier fcFeModuleOperStatus Integer fcFeModuleLastChange Time Ticks fcFeModuleFxPortCapacity FcFeFxPortCapacity fcFeModuleName...
  • Page 199 Status Mandatory Description A textual description of the module. This value should include the full name and version identification of the module, and should contain printable ASCII characters. See sysDescr in Chapter 1, “MIB-II Object Types”. Note fcFeModuleObjectID [fcFeModuleTable] Syntax Object Identifier Access Read-only...
  • Page 200 fcFeModuleOperStatus [fcFeModuleTable] Syntax Value Declaration Description Integer 1 (online) The module is functioning properly. 2 (offline) The module is not available. 3 (testing) The module is under testing. 4 (faulty) The module is defective. Access Read-only Status Mandatory Description Indicates the operational status of the module. fcFeModuleLastChange [fcFeModuleTable] Syntax Time Ticks...

  • Page 201: Fxport Configuration Table

    Status Mandatory Description The number of FxPorts that can be contained within the module. Within each module, the ports are uniquely numbered in the range from 1 to fcFeModuleFxPortCapacity inclusive. However, the numbers are not required to be contiguous. Note SW2010/40/50: 8 SW2400: 8 SW2800: 16...
  • Page 202 Status Mandatory Description A table that contains, one entry for each FxPort in the Fabric Element, and configuration and service parameters of the FxPorts. fcFxConfEntry [fcFxConfTable] Syntax FcFxConfEntry Access Not accessible Status Mandatory Description An entry containing the configuration and service parameters of an FxPort. Index FcFxConfModuleIndex, fcFxConfFxPortIndex Table 28.
  • Page 203 Table 28. FcFxConfEntry Objects and Object Types (continued) FcFxConfEntry Objects See Page Object Types fcFxPortStackedConnMode FcStackedConnMode fcFxPortClass2SeqDeliv Integer fcFxPortClass3SeqDeliv Integer Other FxPort Parameters fcFxPortHoldTime MicroSeconds fcFxPortBaudRate Fc0BaudRate fcFxPortMedium Fc0Medium fcFxPortTxType Fc0TxType fcFxPortDistance Fc0Distance fcFxConfModuleIndex [fcFxConfTable] Syntax FcFeModuleIndex Access Read-only Status Mandatory Description Identifies the module containing the FxPort for which this entry contains...

  • Page 204: Fxport Common Service Parameters

    fcFxPortName [fcFxConfTable] Syntax FcPortName Access Read-only Status Mandatory Description The name identifier of this FxPort. Each FxPort has a unique port name within the address space of the fabric. The return value is the WWN of the port. Note FxPort Common Service Parameters fcFxPortFcphVersionHigh [fcFxConfTable] Syntax FcphVersion...
  • Page 205 fcFxPortBbCredit [fcFxConfTable] Syntax FcBbCredit Access Read-only Status Mandatory Description The total number of receive buffers available for holding a Class 1 connect-request, and Class 2 or 3 frames from the attached NxPort. This enables buffer-to-buffer flow control in the direction from the attached NxPort (if applicable) to FxPort.

  • Page 206: Fxport Classes Of Service Parameters

    fcFxPortEdtov [fcFxConfTable] Syntax MilliSeconds Access Read-only Status Mandatory Description The E_D_TOV value configured for the FxPort. The Error_Detect_Timeout value is used as the timeout value for detecting an error condition. FxPort Classes of Service Parameters fcFxPortCosSupported [fcFxConfTable] Syntax FcCosCap Access Read-only Status Mandatory...
  • Page 207 Status Mandatory Description A flag indicating whether the FxPort supports an intermixed dedicated connection. fcFxPortStackedConnMode [fcFxConfTable] Syntax FcStackedConnMode Access Read-only Status Mandatory Description A value indicating the mode of stacked connect supported by the FxPort. fcFxPortClass2SeqDeliv [fcFxConfTable] Syntax Value Declaration Description Integer 1 (yes)

  • Page 208: Other Fxport Parameters

    fcFxPortClass3SeqDeliv [fcFxConfTable] Syntax Value Declaration Description Integer 1 (yes) Class 3 sequential delivery is supported by the FxPort. 2 (no) Class 3 sequential delivery is not supported by the FxPort. Access Read-only Status Mandatory Description A flag indicating whether Class 3 sequential delivery is supported by the FxPort.
  • Page 209 Status Deprecated Description The FC-0 baud rate of the FxPort. Valid values include the following: Note SW2010/40/50: 16 (full) SW2400: 16 (full) W2800: 16 (full) fcFxPortMedium [fcFxConfTable] Syntax Fc0Medium Access Read-only Status Deprecated Description The FC-0 medium of the FxPort. fcFxPortTxType [fcFxConfTable] Syntax Fc0TxType...

  • Page 210: Operation Group

    Status Deprecated Description The FC-0 distance range of the FxPort transmitter. Operation Group The operation group consists of tables that contain operational status and established service parameters for the Fabric Element and the attached NxPorts. Implementation of this group is mandatory. FxPort Operation Table This table contains one entry for each FxPort, the operational status, and parameters of the FxPorts.
  • Page 211 Description An entry containing operational status and parameters of an FxPort. Index fcFxPortOperModuleIndex, fcFxPortOperFxPortIndex Table 29. fcFxPortOperEntry Objects and Object Types fcFXPortOperEntry Objects See Page Object Types fcFxPortOperModuleIndex FcFeModuleIndex fcFxPortOperFxPortIndex FcFeFxPortIndex fcFxPortID FcAddressId fcFPortAttachedPortName FcPortName fcFPortConnectedPort FcAddressId fcFxPortBbCreditAvailable Gauge fcFxPortOperMode FcFxPortMode fcFxPortAdminMode FcFxPortMode...
  • Page 212 fcFxPortOperFxPortIndex [fcFxPortOperTable] Syntax FcFeFxPortIndex Access Read-only Status Mandatory Description Identifies the FxPort within the module. This number ranges from 1 to the value of fcFeModulePortCapacity for the associated module. The value remains constant for the identified FxPort until the module is re-initialized. fcFxPortID [fcFxPortOperTable] Syntax FcAddressId...
  • Page 213 fcFPortConnectedPort [fcFxPortOperTable] Syntax FcAddressId Access Read-only Status Deprecated Description The address identifier of the destination FxPort with which this FxPort is currently engaged in a either a Class 1 or loop connection. If the value of this object is ‘000000’H, this FxPort is not engaged in a connection. This variable has been deprecated and can be implemented for backward compatibility.

  • Page 214: F_Port Fabric Login Table

    fcFxPortAdminMode [fcFxPortOperTable] Syntax FcFxPortMode Access Read-only (instead of read-write) Status Mandatory Description The desired operational mode of the FxPort. F_Port Fabric Login Table This table contains one entry for each F_Port in the Fabric Element, and the service parameters that have been established from the most recent Fabric Login, whether implicit or explicit.
  • Page 215 fcFxPortPhysEntry [fcFxPortPhysTable] Syntax FcFxPortPhysEntry Access Not accessible Status Mandatory Description An entry containing physical level status and parameters of an FxPort. Index fcFxPortPhysModuleIndex, fcFxPortPhysFxPortIndex Table 30. fcFxPortPhysEntry Objects and Object Types fcFxPortPhysEntry Objects See Page Object Types fcFxPortPhysModuleIndex FcFeModuleIndex fcFxPortPhysFxPortIndex FcFeFxPortIndex fcFxPortPhysAdminStatus Integer...
  • Page 216 fcFxPortPhysFxPortIndex [fcFxPortPhysTable] Syntax FcFeFxPortIndex Access Read-only Status Mandatory Description Identifies the FxPort within the module. This number ranges from 1 to the value of fcFeModulePortCapacity for the associated module. The value remains constant for the identified FxPort until the module is re-initialized. fcFxPortPhysAdminStatus [fcFxPortPhysTable] Syntax Value...
  • Page 217 fcFxPortPhysOperStatus [fcFxPortPhysTable] Syntax Value Declaration Description Integer 1 (online) Login can proceed. 2 (offline) Login cannot proceed. 3 (testing) Port is under test. 4 (link-failure) Failure after online/testing. Other values can be used to indicate diagnostics for a failed test. Note Access Read-only...

  • Page 218: Fxport Fabric Login Table

    fcFxPortPhysRttov [fcFxPortPhysTable] Syntax MilliSeconds Access Read-only Status Mandatory Description The Receiver_Transmitter_Timeout value of the FxPort. This is used by the receiver logic to detect loss of synchronization. FxPort Fabric Login Table This table contains one entry for each FxPort in the Fabric Element, and the service parameters that have been established from the most recent Fabric Login, whether implicit or explicit.
  • Page 219 Description An entry containing service parameters established from a successful Fabric Login. Index fcFxlogiModuleIndex, fcFxlogiFxPortIndex, fcFxlogiNxPortIndex Table 31. FcFxlogiEntry Objects and Object Types FcFxlogiEntry Objects See Page Object Types fcFxlogiModuleIndex FcFeModuleIndex fcFxlogiFxPortIndex FcFeFxPortIndex fcFxlogiNxPortIndex FcFeNxPortIndex fcFxPortFcphVersionAgreed FcphVersion fcFxPortNxPortBbCredit FcBbCredit fcFxPortNxPortRxDataFieldSize FcRxDataFieldSize fcFxPortCosSuppAgreed FcCosCap...
  • Page 220 fcFxlogiFxPortIndex [fcFxlogiTable] Syntax FcFeFxPortIndex Access Read-only Status Mandatory Description Identifies the FxPort within the module. This number ranges from 1 to the value of fcFeModulePortCapacity for the associated module. The value remains constant for the identified FxPort until the module is re-initialized. fcFxlogiNxPortIndex [fcFxlogiTable] Syntax FcFeNxPortIndex...
  • Page 221 fcFxPortNxPortBbCredit [fcFxlogiTable] Syntax FcBbCredit Access Read-only Status Mandatory Description The total number of buffers available for holding a Class 1 connect-request, and Class 2 or Class 3 frames to be transmitted to the attached NxPort. This enables buffer-to-buffer flow control in the direction from FxPort to NxPort.
  • Page 222 fcFxPortIntermixSuppAgreed [fcFxlogiTable] Syntax Value Declaration Description Integer 1 (yes) The attached NxPort has requested the FxPort for the support of intermix, and the FxPort has granted the request. 2 (no) The attached NxPort has not requested the FxPort for the support of intermix. Access Read-only Status...
  • Page 223 fcFxPortClass2SeqDelivAgreed [fcFxlogiTable] Syntax Value Declaration Description Integer 1 (yes) The FxPort has agreed to support Class 2 sequential delivery from the Fabric Login. 2 (no) The FxPort has not agreed to support Class 2 sequential delivery from the Fabric Login. Access Read-only Status...
  • Page 224 fcFxPortNxPortName [fcFxlogiTable] Syntax FcPortName Access Read-only Status Mandatory Description The port name of the attached NxPort, if applicable. If the value of this object is ‘0000000000000000’H, this FxPort has no NxPort attached to it. fcFxPortConnectedNxPort [fcFxlogiTable] Syntax FcAddressId Access Read-only Status Mandatory Description...

  • Page 225: Error Group

    Error Group The error consists of tables that contain information about the various types of errors detected. The management station can use the information in this group to determine the quality of the link between the FxPort and its attached NxPort. Implementation of this group is optional.
  • Page 226 Description An entry containing the error counters of an FxPort. Index fcFxPortErrorModuleIndex, fcFxPortErrorFxPortIndex Table 32. FcFxPortErrorEntry Objects and Object Types FcFxPortErrorEntry Objects See Page Object Types fcFxPortErrorModuleIndex FcFeModuleIndex fcFxPortErrorFxPortIndex FcFeFxPortIndex fcFxPortLinkFailures Counter fcFxPortSyncLosses Counter fcFxPortSigLosses Counter fcFxPortPrimSeqProtoErrors Counter fcFxPortInvalidTxWords Counter fcFxPortInvalidCrcs Counter fcFxPortDelimiterErrors...
  • Page 227 fcFxPortErrorFxPortIndex [fcFxPortErrorTable] Syntax FcFeFxPortIndex Access Read-only Status Mandatory Description Identifies the FxPort within the module. This number ranges from 1 to the value of fcFeModulePortCapacity for the associated module. The value remains constant for the identified FxPort until the module is re-initialized. fcFxPortLinkFailures [fcFxPortErrorTable] Syntax Counter...
  • Page 228 Status Mandatory Description The number of loss of signal errors detected by the FxPort. fcFxPortPrimSeqProtoErrors [fcFxPortErrorTable] Syntax Counter Access Read-only Status Mandatory Description The number of primitive sequence protocol errors detected by the FxPort. fcFxPortInvalidTxWords [fcFxPortErrorTable] Syntax Counter Access Read-only Status Mandatory Description...
  • Page 229 fcFxPortDelimiterErrors [fcFxPortErrorTable] Syntax Counter Access Read-only Status Mandatory Description The number of delimiter errors detected by this FxPort. fcFxPortAddressIdErrors [fcFxPortErrorTable] Syntax Counter Access Read-only Status Mandatory Description The number of address identifier errors detected by this FxPort. fcFxPortLinkResetIns [fcFxPortErrorTable] Syntax Counter Access Read-only...

  • Page 230: Accounting Group

    Status Mandatory Description The number of link reset protocol errors issued by this FxPort to the attached NxPort. fcFxPortOlsIns [fcFxPortErrorTable] Syntax Counter Access Read-only Status Mandatory Description The number of offline sequence errors received by this FxPort. fcFxPortOlsOuts [fcFxPortErrorTable] Syntax Counter Access Read-only...

  • Page 231: Class 1 Accounting Table

    The HP FC 6164 switches do not support Class 1 class of service. Note Class 1 Accounting Table This table contains one entry for each FxPort in the Fabric Element, and counters for certain types of events that have occurred in the FxPorts since the management agent has re-initialized.
  • Page 232 Table 33. FcFxPortC1AcctEntry Objects and Object Types FcFxPortC1AcctEntry Objects See Page Object Types fcFxPortC1AcctModuleIndex FcFeModuleIndex fcFxPortC1AcctFxPortIndex FcFeFxPortIndex fcFxPortC1InConnections Counter fcFxPortC1OutConnections Counter fcFxPortC1FbsyFrames Counter fcFxPortC1FrjtFrames Counter fcFxPortC1ConnTime Counter fcFxPortC1InFrames Counter fcFxPortC1OutFrames Counter fcFxPortC1InOctets Counter fcFxPortC1OutOctets Counter fcFxPortC1Discards Counter fcFxPortC1AcctModuleIndex [fcFxPortC1AcctTable] Syntax FcFeModuleIndex Access Read-only...
  • Page 233 Status Mandatory Description Identifies the FxPort within the module. This number ranges from 1 to the value of fcFeModulePortCapacity for the associated module. The value remains constant for the identified FxPort until the module is re-initialized. fcFxPortC1InConnections [fcFxPortC1AcctTable] Syntax Counter Access Read-only Status...
  • Page 234 fcFxPortC1FrjtFrames [fcFxPortC1AcctTable] Syntax Counter Access Read-only Status Mandatory Description The number of F_RJT frames generated by this FxPort against the Class 1 connect-request. fcFxPortC1ConnTime [fcFxPortC1AcctTable] Syntax Counter Access Read-only Status Mandatory Description The cumulative time that this FxPort has been engaged in a Class 1 connection.
  • Page 235 fcFxPortC1OutFrames [fcFxPortC1AcctTable] Syntax Counter Access Read-only Status Mandatory Description The number of Class 1 frames (other than a Class 1 connect-request) delivered through this FxPort to its attached NxPort. fcFxPortC1InOctets [fcFxPortC1AcctTable] Syntax Counter Access Read-only Status Mandatory Description The number of Class 1 frame octets, including the frame delimiters, received by this FxPort from its attached NxPort.

  • Page 236: Class 2 Accounting Table

    Status Mandatory Description The number of Class 1 frames discarded by this FxPort. Class 2 Accounting Table This table contains one entry for each FxPort in the Fabric Element, and counters for certain types of events that have occurred in the FxPorts since the management agent has re-initialized.
  • Page 237 Table 34. FcFxPortC2AcctEntry Objects and Object Types FcFxPortC2AcctEntry Objects See Page Object Types fcFxPortC2AcctModuleIndex FcFeModuleIndex fcFxPortC2AcctFxPortIndex FcFeFxPortIndex fcFxPortC2InFrames Counter fcFxPortC2OutFrames Counter fcFxPortC2InOctets Counter fcFxPortC2OutOctets Counter fcFxPortC2Discards Counter fcFxPortC2FbsyFrames Counter fcFxPortC2FrjtFrames Counter fcFxPortC2AcctModuleIndex [fcFxPortC2AcctTable] Syntax FcFeModuleIndex Access Read-only Status Mandatory Description Identifies the module containing the FxPort for which this entry contains information.
  • Page 238 Status Mandatory Description Identifies the FxPort within the module. This number ranges from 1 to the value of fcFeModulePortCapacity for the associated module. The value remains constant for the identified FxPort until the module is re-initialized. fcFxPortC2InFrames [fcFxPortC2AcctTable] Syntax Counter Access Read-only Status...
  • Page 239 fcFxPortC2OutOctets [fcFxPortC2AcctTable] Syntax Counter Access Read-only Status Mandatory Description The number of Class 2 frame octets, including the frame delimiters, delivered through this FxPort to its attached NxPort. fcFxPortC2Discards [fcFxPortC2AcctTable] Syntax Counter Access Read-only Status Mandatory Description The number of Class 2 frames discarded by this FxPort. fcFxPortC2FbsyFrames [fcFxPortC2AcctTable] Syntax Counter...

  • Page 240: Class 3 Accounting Table

    Status Mandatory Description The number of F_RJT frames generated by this FxPort against Class 2 frames. Class 3 Accounting Table This table contains one entry for each FxPort in the Fabric Element, and counters for certain types of events that have occurred in the FxPorts since the management agent has re-initialized.
  • Page 241 Table 35. FcFxPortC3AcctEntry Objects and Object Types FcFxPortC3AcctEntry Objects See Page Object Types fcFxPortC3AcctModuleIndex FcFeModuleIndex fcFxPortC3AcctFxPortIndex FcFeFxPortIndex fcFxPortC3InFrames Counter fcFxPortC3OutFrames Counter fcFxPortC3InOctets Counter fcFxPortC3OutOctets Counter fcFxPortC3Discards Counter fcFxPortC3AcctModuleIndex [fcFxPortC3AcctTable] Syntax FcFeModuleIndex Access Read-only Status Mandatory Description Identifies the module containing the FxPort for which this entry contains information.
  • Page 242 fcFxPortC3InFrames [fcFxPortC3AcctTable] Syntax Counter Access Read-only Status Mandatory Description The number of Class 3 frames received by this FxPort from its attached NxPort. fcFxPortC3OutFrames [fcFxPortC3AcctTable] Syntax Counter Access Read-only Status Mandatory Description The number of Class 3 frames delivered through this FxPort to its attached NxPort.

  • Page 243: Capability Group

    Status Mandatory Description The number of Class 3 frame octets, including the frame delimiters, delivered through this FxPort to its attached NxPort. fcFxPortC3Discards [fcFxPortC3AcctTable] Syntax Counter Access Read-only Status Mandatory Description The number of Class 3 frames discarded by this FxPort. Capability Group The capability group consists of a table describing information about what each FxPort is inherently capable of operating or supporting.
  • Page 244 fcFxPortCapEntry [fcFxPortCapTable] Syntax FcFxPortCapEntry Access Not accessible Status Mandatory Description An entry containing the capabilities of a FxPort. Index fcFxPortCapModuleIndex, fcFxPortCapFxPortIndex Table 36. FcFxPortCapEntry Objects and Object Types FcFxPortCapEntry Objects See Page Object Types fcFxPortCapModuleIndex FcFeModuleIndex fcFxPortCapFxPortIndex FcFeFxPortIndex fcFxPortCapFcphVersionHigh FcphVersion fcFxPortCapFcphVersionLow FcphVersion fcFxPortCapBbCreditMax...
  • Page 245 fcFxPortCapModuleIndex Syntax FcFeModuleIndex Access Read-only Status Mandatory Description Identifies the module containing the FxPort for which this entry contains information. fcFxPortCapFxPortIndex [fcFxPortCapTable] Syntax FcFeFxPortIndex Access Read-only Status Mandatory Description Identifies the FxPort within the module. This number ranges from 1 to the value of fcFeModulePortCapacity for the associated module.
  • Page 246 fcFxPortCapFcphVersionLow [fcFxPortCapTable] Syntax FcphVersion Access Read-only Status Mandatory Description The lowest or earliest version of FC-PH that the FxPort is capable of supporting. fcFxPortCapBbCreditMax [fcFxPortCapTable] Syntax FcBbCredit Access Read-only Status Mandatory Description The maximum number of receive buffers available for holding a Class 1 connect-request, and Class 2 or Class 3 frames from the attached NxPort.
  • Page 247 Status Mandatory Description The maximum size in bytes of the Data Field in a frame that the FxPort is capable of receiving from its attached NxPort. fcFxPortCapRxDataFieldSizeMin [fcFxPortCapTable] Syntax FcRxDataFieldSize Access Read-only Status Mandatory Description The minimum size in bytes of the Data Field in a frame that the FxPort is capable of receiving from its attached NxPort.
  • Page 248 fcFxPortCapIntermix [fcFxPortCapTable] Syntax Value Declaration Description Integer 1 (yes) The FxPort is capable of supporting the intermixing of Class 2 and Class 3 frames during a Class 1 connection. 2 (no) The FxPort is not capable of supporting the intermixing of Class 2 and Class 3 frames during a Class 1 connection.
  • Page 249 fcFxPortCapClass2SeqDeliv [fcFxPortCapTable] Syntax Value Declaration Description Integer 1 (yes) The FxPort is capable of supporting Class 2 sequential delivery. 2 (no) The FxPort is not capable of supporting Class 2 sequential delivery. Access Read-only Status Mandatory Description A flag indicating whether the FxPort is capable of supporting Class 2 sequential delivery.
  • Page 250 fcFxPortCapHoldTimeMax [fcFxPortCapTable] Syntax MicroSeconds Access Read-only Status Mandatory Description The maximum holding time (in microseconds) that the FxPort is capable of supporting. fcFxPortCapHoldTimeMin [fcFxPortCapTable] Syntax MicroSeconds Access Read-only Status Mandatory Description The minimum holding time (in microseconds) that the FxPort is capable of supporting.
  • Page 251 fcFxPortCapMedia [fcFxPortCapTable] Syntax Fc0MediaCap Access Read-only Status Deprecated Description A value indicating the set of media that the FxPort is capable of supporting. This variable has been deprecated and can be implemented for backward compatibility. FC Fabric Element MIB Object Types...
  • Page 252 MIB Reference Manual...

  • Page 253: Fc Switch Mib Object Types

    FC SWITCH MIB OBJECT TYPES This chapter contains information that is specific to FC Switch MIB (SW-MIB) object types. Table 37. FC Switch Organizational Listing bcsi enterprises (1588) Product Lines or Generic Product Information bcsi (1) = Reserved commDev bcsi (2) = Communication devices fibrechannel commDev (1) fcSwitch...
  • Page 254 The object types in SW-MIB are organized into the following groupings: • swSystem • swFabric • swActCfg • swFCport • swNs • swEvent • swFwSystem • swEndDevice MIB Reference Manual...

  • Page 255: Sw-Mib File System Organization

    SW-MIB File System Organization Figure 11 through Figure 13 depict the organization and structure of the SW-MIB file system. Figure 11. SW-MIB Overall Tree Structure FC Switch MIB Object Types...
  • Page 256 Figure 12. Tree Structure for swSystem, swFabric, swAgtCfg, swFCPort, and swNs Groups MIB Reference Manual...
  • Page 257 Figure 13. Tree Structure for swEvent, swFwSystem, and swEndDevice Groups FC Switch MIB Object Types...

  • Page 258: Definitions For Sw-Mib

    Definitions for SW-MIB Table 38 lists the definitions that are used for SW-MIB. Table 38. SW-MIB Definitions Type Definition Value Declaration Description Display String Octet String FcWwn Octet String of size 8 SwDomainIndex Integer of size 0 to 239 SwNbIndex Integer of size 0 to 2048 SwSensorIndex...
  • Page 259 Table 38. SW-MIB Definitions (continued) Type Definition Value Declaration Description SwFwClassesAreas Integer 1 (swFwEnvTemp) 2 (swFwEnvFan) 3 (swFwEnvPs) 4 (swFwGbicTemp) 5 (swFwGbicRxp) 6 (swFwGbicTxp) 7 (swFwGbicCurrent) 8 (swFwPortLink) 9 (swFwPortSync) 10 (swFwPortSignal) 11 (swFwPortPe) 12 (swFwPortWords) 13 (swFwPortCrcs) 14 (swFwPortRXPerf) 15 (swFwPortTXPerf) 16 (swFwPortState) 17 (swFwFabricEd)
  • Page 260 Table 38. SW-MIB Definitions (continued) Type Definition Value Declaration Description SwFwClassesAreas Integer 20 (swFwFabricSc) (continued) 21 (swFwFabricZc) 22 (swFwFabricFq) 23 (swFwFabricFl) 24 (swFwFabricGs) 25 (swFwEPortLink) 26 (swFwEPortSync) 27 (swFwEPortSignal) 28 (swFwEPortPe) 29 (swFwEPortWords) 30 (swFwEPortCrcs) 31 (swFwEPortRXPerf) 32 (swFwEPortTXPerf) 33 (swFwEPortState) 34 (swFwFCUPortLink) 35 (swFwFCUPortSync) MIB Reference Manual...
  • Page 261 Table 38. SW-MIB Definitions (continued) Type Definition Value Declaration Description SwFwClassesAreas Integer 36 (swFwFCUPortSignal) (continued) 37 (swFwFCUPortPe) 38 (swFwFCUPortWords) 39 (swFwFCUPortCrcs) 40 (swFwFCUPortRXPerf) 41 (swFwFCUPortTXPerf) 42 (swFwFCUPortState) 43 (swFwFOPPortLink) 44 (swFwFOPPortSync) 45 (swFwFOPPortSignal) 46 (swFwFOPPortPe) 47 (swFwFOPPortWords) 48 (swFwFOPPortCrcs) 49 (swFwFOPPortRXPerf) 50 (swFwFOPPortTXPerf) 51 (swFwFOPPortState) SwFwWriteVals...
  • Page 262 Table 38. SW-MIB Definitions (continued) Type Definition Value Declaration Description SwFwTimebase Integer 1 (swFwTbNone) 2 (swFwTbSec) 3 (swFwTbMin) 4 (swFwTbHour) 5 (swFwTbDay) SwFwStatus Integer 1 (disabled) 2 (enabled) SwFwEvent Integer 1 (started) 2 (changed) 3 (exceeded) 4 (below) 5 (above) 6 (inBetween) SwFwBehavior Integer...

  • Page 263: System Group

    System Group swCurrentDate Syntax Display String of size 0 to 64 Access Read-only Status Mandatory Description The current date and time. The return string is displayed using the following format: Note ddd MMM DD hh:mm:ss yyyy Where: ddd = Day MMM = Month DD = Date hh = Hour...
  • Page 264 The return string is displayed using the following format: Note ddd MMM DD hh:mm:ss yyyy Where: ddd = Day MMM = Month DD = Date hh = Hour mm = Minute ss = Seconds yyyy = Year For example: Thu Aug 17 15:16:09 2000. swFWLastUpdated Syntax Display String of size 0 to 64...
  • Page 265 mm = Minute ss = Seconds yyyy = Year For example: Thu Aug 17 15:16:09 2000. swFlashLastUpdated Syntax Display String Access Read-only Status Mandatory Description The date and time when the firmware was last downloaded or the configuration file was last changed. The return string is displayed using the following format: Note ddd MMM DD hh:mm:ss yyyy...
  • Page 266 swBootPromLastUpdated Syntax Display String of size 0 to 64 Access Read-only Status Mandatory Description The date and time when the BootPROM was last updated. The return string is displayed using the following format: Note ddd MMM DD hh:mm:ss yyyy Where: ddd = Day MMM = Month DD = Date...
  • Page 267 The return value is displayed using the following format: Note vM.m.f Where: v = The deployment indicator M = Major version m = Minor version f = Software maintenance version For example: v2.2.1 (indicating FOS version 2.2.1). swOperStatus Syntax Value Declaration Description Integer...
  • Page 268 swAdmStatus Syntax Value Declaration Description Integer 1 (online) Set the switch to be accessible by an external fibre channel port. 2 (offline) Set the switch to be inaccessible. 3 (testing) Set the switch to run the built-in test. 4 (faulty) Set the switch to a “soft”...
  • Page 269 swTelnetShellAdmStatus Syntax Value Declaration Description Integer 0 (unknown) The status of the current Telnet shell task is unknown. 1 (terminated) The current Telnet shell task is deleted. Access Read-write Status Mandatory Description The desired administrative status of the Telnet shell. By setting it to 1 (terminated), the current Telnet shell task is deleted.

  • Page 270: Flash Administration

    Flash Administration The next five objects are related to firmware or configuration file management. The underlying method in the transfer of the firmware or configuration file is based on either FTP or remote shell. If a password is provided, FTP is used. If no password is provided, remote shell is used. Use one of the two following methods to manage the firmware or switch configuration file in the switch Flash: 1.
  • Page 271 Status Mandatory Description The operational status of the Flash. swFlashDLAdmStatus Syntax Value Declaration Description Integer 1 (swCurrent) The Flash contains the current firmware image or configuration file. 2 (swFwUpgrad) The firmware in the Flash is to be upgraded from the host specified. 3 (swCfUpload) The switch configuration file is to be uploaded to the host specified.
  • Page 272 FlashDLHost Syntax Display String of size 0 to 64 Access Read-write Status Mandatory Description The name or IP address (in dot notation) of the host to download or upload a relevant file to the Flash. swFlashDLUser Syntax Display String of size 0 to 64 Access Read-write Status...
  • Page 273 Status Mandatory Description The password to be used for FTP transfer of files in the download or upload operation. swBeaconOperStatus Syntax Value Declaration Description Integer 1 (on) The LEDs on the front panel of the switch run alternately from left to right, and right to left.

  • Page 274: Operating Environment Sensor Table (Temperature, Fan, Power Supply, And Others)

    Access Read-write Status Mandatory Description The desired status of the switch beacon. When the beacon is set to on, the LEDs on the front panel of the switch run alternately from left to right, and right to left. The color is yellow. When the beacon is set to off, each LED is in its regular status, indicating color and state.
  • Page 275 Status Mandatory Description The number of sensors inside the switch is shown as follows: • W2010/40/50: 13 • SW2400: 13 • SW2800: 13 swSensorTable Syntax Sequence of swSensorEntry Access Not accessible Status Mandatory Description The table of sensor entries. swSensorEntry [swSensorTable] Syntax SwSensorEntry Access...
  • Page 276 Table 39. SwSensorEntry Objects and Object Types SwSensorEntry Objects See Page Object Types swSensorIndex Index swSensorType Integer swSensorStatus Integer swSensorValue Integer swSensorInfo Display String of size 0 to 255 swSensorIndex [swSensorTable] Syntax SwSensorIndex Access Read-only Status Mandatory Description The index of the sensor. Values for the index range from 1 to 13.
  • Page 277 Status Mandatory Description The type of sensor. swSensorStatus [swSensorTable] Syntax Value Declaration Description Integer 1 (unknown) The status of the sensor is unknown. 2 (faulty) The status of the sensor is in a faulty state. 3 (below-min) The sensor value is below the minimal threshold.
  • Page 278 See the following list for valid values: Note – For temperature, valid values include 3 (below-min), 4 (nominal), and 5 (above-max). – For fan, valid values include 3 (below-min), 4 (nominal), and 6 (absent). – For power supply, valid values include 2 (faulty), 4 (nominal), and 6 (absent).
  • Page 279 Status Mandatory Description Additional displayable information on the sensor. In V2.x, it contains the sensor type and number in textual format. For example, Temp 3 or Fan 6. For swSensorIndex 1 through 5, valid return values include: Note – Temp #1 –...

  • Page 280: Fabric Group

    swTrackChangesInfo Syntax Display String of size 0 to 256 Access Read-only Status Mandatory Description Track changes string. For trap only. If there are no events to track, the default return value is “No event Note so far.” If there are events to track, the following are valid return values: –...

  • Page 281: Immediate Neighborhood Isl Family Table

    swPrincipalSwitch Syntax Value Declaration Description Integer 1 (yes) This is the principal switch for FC-SW. 2 (no) This is not the principal switch for FC-SW. Access Read-only Status Mandatory Description Indicates whether the switch is the principal switch as per FC-SW. Immediate Neighborhood ISL Family Table swNumNbs Syntax...
  • Page 282 swNbEntry [swNbTable] Syntax SwNbEntry Access Not accessible Status Mandatory Description An entry containing each neighbor ISL parameters. Index swNbIndex Table 40. SwNbEntry Objects and Object Types SwNbEntry Objects See Page Object Types swNbIndex SwNbIndex swNbMyPort Integer swNbRemDomain SwDomainIndex swNbRemPort Integer swNbBaudRate Integer swNbIslState...
  • Page 283 swNbMyPort [swNbTable] Syntax Value Declaration Description Integer 1 (portNum-0) 2 (portNum-1) 3 (portNum-2) 4 (portNum-3) 5 (portNum-4) 6 (portNum-5) 7 (portNum-6) 8 (portNum-7) 9 (portNum-8) 10 (portNum-9) 11 (portNum-10) 12 (portNum-11) 13 (portNum-12) 14 (portNum-13) 15 (portNum-14) 16 (portNum-15) Access Read-only Status Mandatory...
  • Page 284 The physical port number of the local switch, plus one. Valid values Note include the following: SW2010/40/50: portNum-0 to portNum-7 SW2400: portNum-0 to portNum-7 SW2800: portNum-0 to portNum-15 swNbRemDomain [swNbTable] Syntax SwDomainIndex Access Read-only Status Mandatory Description This is the fibre channel domain on the other end of the ISL. This is the domain ID of the remote switch.Valid values are 1to 239 Note as defined by FCS-SW.
  • Page 285 Value Declaration Description Integer 9 (portNum-8) 10 (portNum-9) 11 (portNum-10) 12 (portNum-11) 13 (portNum-12) 14 (portNum-13) 15 (portNum-14) 16 (portNum-15) Access Read-only Status Mandatory Description This is the port index on the other end of the ISL. The physical port number of the remote switch, plus one. Valid Note values include the following: SW2010/40/50: portNum-0 to portNum-7...
  • Page 286 swNbBaudRate [swNbTable] Syntax Value Declaration Description Integer 1 (other) None of below 2 (oneEighth) 155 Mbaud 4 (quarter) 266 Mbaud 8 (half) 532 Mbaud 16 (full) 1 Gbaud 32 (double) 2 Gbaud 64 (quadruple) 4 Gbaud Access Read-only Status Mandatory Description The baud rate of the ISL.
  • Page 287 Syntax Value Declaration Description Integer 0 (sw-down) 2 (sw-init) 2 (sw-internal2) 3 (sw-internal3) 4 (sw-internal4) 5 (sw-active) Access Read-only Status Mandatory Description swNbIslCost [swNbTable] The current state of the ISL. Syntax Integer Access Read-write Status Mandatory Description The current link cost of the ISL. In other words, the cost of a link to control the routing algorithm.

  • Page 288: Sw Agent Configuration Group

    Status Mandatory Description The WWN of the remote port. SW Agent Configuration Group SNMP Agent Configuration Table swAgtCmtyTable Syntax Sequence of SwAgtCmtyEntry Access Not accessible Status Mandatory Description A table that contains one entry for each community, and the access control and parameters of the community.
  • Page 289 Description An entry containing the community parameters. Index swAgtCmtyIdx Table 41. SwAgtCmtyEntry Objects and Object Types SwAgtCmtyEntry Objects See Page Object Types swAgtCmtyIdx Integer of size 1 to 6 swAgtCmtyStr Display String of size 0 to swAgtTrapRcp NetworkAddress swAgtCmtyIdx [swAgtCmtyTable] Syntax Integer of size 1 to 6 Access...
  • Page 290 Default values for communities are as follows: Note – Secret COde – OrigEquipMfr – private – public – common – FibreChannel Change the community setting using the agtcfgSet Telnet command. swAgtTrapRcp [swAgtCmtyTable] Syntax NetworkAddress Access Read-write Status Mandatory Description This is the trap recipient associated with the community. If a new value is set successfully, it takes effect immediately.

  • Page 291: Fibre Channel Port Group

    Fibre Channel Port Group The fibre channel port group contains information about the physical state, operational status, performance, and error statistics of each fibre channel port on the switch. A fibre channel port is one which supports the fibre channel protocol. For example, F_Port, E_Port, U_Port, FL_Port. swFCPortCapacity Syntax Integer...
  • Page 292 swFCPortEntry [swFCPortTable] Syntax SwFCPortEntry Access Not accessible Status Mandatory Description An entry containing the configuration and service parameters of the switch port. Index swFCPortIndex Table 42. SwFCPortEntry Objects and Object Types SwFCPortEntry Objects See Page Object Types swFCPortIndex Integer swFCPortType Integer swFCPortPhyState Integer...
  • Page 293 Table 42. SwFCPortEntry Objects and Object Types (continued) SwFCPortEntry Objects See Page Object Types swFCPortTooManyRdys Counter swFCPortNoTxCredits Counter swFCPortRxEncInFrs Counter swFCPortRxCrcs Counter swFCPortRxTruncs Counter swFCPortRxTooLongs Counter swFCPortRxBadEofs Counter swFCPortRxEncOutFrs Counter swFCPortRxBadOs Counter swFCPortC3Discards Counter swFCPortMcastTimedOuts Counter swFCPortTxMcasts Counter LIP statistics swFCPortLipIns Counter, swFCPortLipOuts...
  • Page 294 swFCPortIndex [swFCPortTable] Syntax Value Declaration Description Integer 1 (portNum-0) 2 (portNum-1) 3 (portNum-2) 4 (portNum-3) 5 (portNum-4) 6 (portNum-5) 7 (portNum-6) 8 (portNum-7) 9 (portNum-8) 10 (portNum-9) 11 (portNum-10) 12 (portNum-11) 13 (portNum-12) 14 (portNum-13) 15 (portNum-14) 16 (portNum-15) Access Read-only Status Mandatory...
  • Page 295 The physical port number of the switch, plus one. Valid values Note include the following: SW2010/40/50: portNum-0 to portNum-7 SW2400: portNum-0 to portNum-7 SW2800: portNum-0 to portNum-15 swFCPortType [swFCPortTable] Syntax Value Declaration Description Integer 1 (stitch) 2 (flannel) 3 (loom) Access Read-only Status...
  • Page 296 swFCPortPhyState [swFCPortTable] Syntax Value Declaration Description Integer 1 (noCard) No card is present in this switch slot. 2 (noGbic) No GBIC module is in this port. 3 (laserFault) The module is signaling a laser fault (defective GBIC). 4 (noLight) The module is not receiving light. 5 (noSync) The module is receiving light but is out of sync.
  • Page 297 swFCPortOpStatus [swFCPortTable] Syntax Value Declaration Description Integer 0 (unknown) The port module is physically absent. 1 (online) User frames can be passed. 2 (offline) No user frames can be passed. 3 (testing) No user frames can be passed. 4 (faulty) The port module is physically faulty.
  • Page 298 The 3 (testing) state indicates that no user frames can be passed. As the result of either explicit management action or per configuration information accessible by the switch, swFCPortAdmStatus is then changed to either the 1 (online) or 3 (testing) state, or remains in the 2 (offline) state. swFCPortLinkState [swFCPortTable] Syntax Value...
  • Page 299 swFCPortTxType [swFCPortTable] Syntax Value Declaration Description Integer 1 (unknown) Cannot determined to the port driver. 2 (lw) Long wave laser 3 (sw) Short wave laser 3 (ld) Long wave LED Access Read-only Status Mandatory Description Indicates the media transmitter type of the port. swFCPortTxWords [swFCPortTable] Syntax Counter...
  • Page 300 swFCPortTxFrames [swFCPortTable] Syntax Counter Access Read-only Status Mandatory Description Counts the number of fibre channel frames that the port has transmitted. swFCPortRxFrames [swFCPortTable] Syntax Counter Access Read-only Status Mandatory Description Counts the number of fibre channel frames that the port has received. swFCPortRxC2Frames [swFCPortTable] Syntax Counter...
  • Page 301 Status Mandatory Description Counts the number of Class 3 frames that the port has received. swFCPortRxLCs [swFCPortTable] Syntax Counter Access Read-only Status Mandatory Description Counts the number of link control frames that the port has received. swFCPortRxMcasts [swFCPortTable] Syntax Counter Access Read-only Status...
  • Page 302 swFCPortNoTxCredits [swFCPortTable] Syntax Counter Access Read-only Status Mandatory Description Counts the number of times when the transmit credit has reached zero. swFCPortRxEncInFrs [swFCPortTable] Syntax Counter Access Read-only Status Mandatory Description Counts the number of encoding errors or disparity errors inside frames received.
  • Page 303 Status Mandatory Description Counts the number of truncated frames that the port has received. swFCPortRxTooLongs [swFCPortTable] Syntax Counter Access Read-only Status Mandatory Description Counts the number of received frames that are too long. swFCPortRxBadEofs [swFCPortTable] Syntax Counter Access Read-only Status Mandatory Description Counts the number of received frames that have a bad EOF delimiter.
  • Page 304 swFCPortRxBadOs [swFCPortTable] Syntax Counter Access Read-only Status Mandatory Description Counts the number of invalid ordered sets received. swFCPortC3Discards [swFCPortTable] Syntax Counter Access Read-only Status Mandatory Description Counts the number of Class 3 frames that the port has discarded. swFCPortMcastTimedOuts [swFCPortTable] Syntax Counter Access...
  • Page 305 Status Mandatory Description Counts the number of multicast frames that has been transmitted. swFCPortLipIns [swFCPortTable] Syntax Counter Access Read-only Status Mandatory Description Counts the number of loop initializations that has been initiated by loop devices attached. swFCPortLipOuts [swFCPortTable] Syntax Counter Access Read-only Status...

  • Page 306: Name Server Database Group

    swFCPortWwn [swFCPortTable] Syntax Octet String of size 8 Access Read-only Status Mandatory Description The WWN of the fibre channel port. The contents of an instance are in the IEEE extended format as specified in FC-PH. Name Server Database Group swNsLocalNumEntry Syntax Integer Access...
  • Page 307 swNsLocalEntry [swNsLocalTable] Syntax SwNsEntry Access Not accessible Status Mandatory Description An entry from the local name server database. Index swNsEntryIndex Table 43. SwNsEntry Objects and Object Types SwNsEntry Objects See Page Object Types swNsEntryIndex Integer swNsPortID Octet String of size 4 swNsPortType Integer swNsPortName...
  • Page 308 Status Mandatory Description The index of the name server database entry. swNsPortID [swNsLocalTable] Syntax Octet String of size 4 Access Read-only Status Mandatory Description The fibre channel port address ID of the entry. swNsPortType [swNsLocalTable] Syntax Value Declaration Description Integer 0 (unknown) The type is defined in FC-GS-2.
  • Page 309 Status Mandatory Description The fibre channel WWN of the port entry. swNsPortSymb [swNsLocalTable] Syntax Octet String of size 0 to 255 Access Read-only Status Mandatory Description The contents of a symbolic name of the port entry. In FC-GS-2, a symbolic name consists of a byte array of 1 to 256 bytes, and the first byte of the array specifies the length of its contents.
  • Page 310 Status Mandatory Description The contents of a symbolic name of the node associated with the entry. In FC-GS-2, a symbolic name consists of a byte array of 1 to 256 bytes, and the first byte of the array specifies the length of its contents. This object variable corresponds to the contents of the symbolic name, with the first byte removed.
  • Page 311 swNsCos [swNsLocalTable] Syntax Value Declaration Description Integer 0 (class-unknown) 1 (class-F) 2 (class-1) 3 (class-F-1) 4 (class-2) 5 (class-F-2) 6 (class-1-2) 7 (class-F-1-2) 8 (class-3) 9 (class-F-3) 10 (class-1-3) 11 (class-F-1-3) 12 (class-2-3) 13 (class-F-2-3) 14 (class-1-2-3) 15 (class-F-1-2-3) Access Read-only Status Mandatory...

  • Page 312: Event Group

    swNsFc4 [swNsLocalTable] Syntax Octet String of size 32 Access Read-only Status Mandatory Description The FC-4s supported by the port as defined in FC-GS-2. Event Group (To Map the errLog) Logically, the swEventTable is separate from the error log because it Note is essentially a view of the error log within a particular time window.
  • Page 313 Status Mandatory Description Specifies the swEventTrap level in conjunction with an event’s severity level. When an event occurs, if its severity level is at or below the specified numeric value, the agent sends the associated swEventTrap to the configured recipients. For example, if this variable is set to 3 (warning), all error logs of severity 1 (critical), 2 (error), and 3 (warning) are sent as an SNMP trap of swEventTrap as shown in...
  • Page 314 Status Mandatory Description An entry in the event table. Index swEventIndex Table 44. swEventIndex Objects and Object Types swEventIndex Objects See Page Object Types swEventIndex Integer swEventTimeInfo Display String swEventLevel Integer swEventRepeat CountInteger swEventDescr Display String swEventIndex [swEventTable] Syntax Integer Access Read-only Status...
  • Page 315 The return string is displayed using the following format: Note ddd MMM DD hh:mm:ss yyyy Where: ddd = Day MMM = Month DD = Date hh = Hour mm = Minute ss = Seconds yyyy = Year For example: Thu Aug 17 15:16:09 2000. swEventLevel [swEventTable] Syntax Value...
  • Page 316 swEventRepeatCount [swEventTable] Syntax Integer Access Read-only Status Mandatory Description If the most recent event is the same as the previous event, this number is incremented by one, and is the count of consecutive times this particular event has occurred. swEventDescr [swEventTable] Syntax Display String Access...

  • Page 317: Fabric Watch Group

    Fabric Watch Group The Fabric Watch subsystem consists of two tables. SwFwClassAreaEntry contains control information for a particular class/area’s thresholds. These thresholds are contained in SwFwThresholdEntry. This is the first of the elements declared for Fabric Watch; one scalar Note and two tables.
  • Page 318 Status Mandatory Description The table of classes and areas. swFwClassAreaEntry [swFwClassAreaTable] Syntax SwFwClassAreaEntry Access Not accessible Status Mandatory Description An entry of the classes and areas. Index swFwClassAreaIndex Table 45. SwFwClassAreaEntry Objects and Object Types SwFwClassAreaEntry Objects See Page Object Types swFwClassAreaIndex SwFwClassesAreas swFwWriteThVals...
  • Page 319 Table 45. SwFwClassAreaEntry Objects and Object Types (continued) SwFwClassAreaEntry Objects See Page Object Types swFwWriteActVals SwFwWriteVals swFwDefaultChangedActs SwFwActs swFwDefaultExceededActs SwFwActs swFwDefaultBelowActs SwFwActs swFwDefaultAboveActs SwFwActs swFwCustChangedActs SwFwActs swFwCustExceededActs SwFwActs swFwCustBelowActs SwFwActs swFwCustAboveActs SwFwActs swFwValidActs SwFwActs swFwActLevel SwFwLevel swFwClassAreaIndex [swFwClassAreaTable] Syntax SwFwClassesAreas Access Read-only Status...
  • Page 320 For a read operation, the return value is always swFwCancelWrite. Note The following custom configuration variables can be modified: – swFwCustUnit – swFwCustTimebase – swFwCustLow – swFwCustHigh – swFwCustBufSize Changes to these custom configuration variables can be saved by setting this variable to swFwApplyWrite, and they can be removed by setting this variable to swFwCancelWrite.
  • Page 321 Status Mandatory Description A default polling period for the Fabric Watch classArea combination. For example: • swFwTbMin = port (class), link loss (area) • swFwTbNone = environment (class), temperature (area) swFwDefaultLow [swFwClassAreaTable] Syntax Integer Access Read-only Status Mandatory Description A default low-threshold value. swFwDefaultHigh [swFwClassAreaTable] Syntax Integer...
  • Page 322 swFwCustUnit [swFwClassAreaTable] Syntax Display String of size 0 to 256 Access Read-write Status Mandatory Description A customizable unit string name, used to identify the unit of measure for a Fabric Watch classArea combination. For example: • C = environment (class), temperature (area) •...
  • Page 323 Status Mandatory Description A customizable low-threshold value for a Fabric Watch ClassArea combination. swFwCustHigh [swFwClassAreaTable] Syntax Integer Access Read-write Status Mandatory Description A customizable high-threshold value for a Fabric Watch ClassArea combination. swFwCustBufSize [swFwClassAreaTable] Syntax Integer Access Read-write Status Mandatory Description A customizable buffer size value for a Fabric Watch ClassArea combination.
  • Page 324 For a read operation, the return value is either 2 (swFwDefault) or 3 Note (swFwCustom). 1 (swFwReserved) is obsolete. If the write operation sets the variable to 2 (swFwDefault), the following default configuration variables are used for the Fabric Watch classArea combination: –...
  • Page 325 For a read operation, the return value is always swFwCancelWrite. Note The following custom alarm variables can be modified: – swFwCustChangedActs – swFwCustExceededActs – swFwCustBelowActs – swFwCustAboveActs – swFwCustInBetweenActs Changes to these custom alarm variables can be saved by setting this variable to swFwApplyWrite.
  • Page 326 swFwDefaultBelowActs [swFwClassAreaTable] Syntax SwFwActs Access Read-only Status Mandatory Description Default action matrix for below event. swFwDefaultAboveActs [swFwClassAreaTable] Syntax SwFwActs Access Read-only Status Mandatory Description Default action matrix for above event. swFwDefaultInBetweenActs [swFwClassAreaTable] Syntax SwFwActs Access Read-only Status Mandatory Description Default action matrix for in-between event. swFwCustChangedActs [swFwClassAreaTable] Syntax SwFwActs...
  • Page 327 Status Mandatory Description Custom action matrix for changed event. swFwCustExceededActs [swFwClassAreaTable] Syntax SwFwActs Access Read-write Status Mandatory Description Custom action matrix for an exceeded event. swFwCustBelowActs [swFwClassAreaTable] Syntax SwFwActs Access Read-write Status Mandatory Description Custom action matrix for below event. swFwCustAboveActs [swFwClassAreaTable] Syntax SwFwActs...
  • Page 328 swFwCustInBetweenActs [swFwClassAreaTable] Syntax SwFwActs Access Read-write Status Mandatory Description Custom action matrix for in-between event. swFwValidActs [swFwClassAreaTable] Syntax SwFwActs Access Read-only Status Mandatory Description Matrix of valid acts for ClassArea. swFwActLevel [swFwClassAreaTable] Syntax SwFwLevels Access Read-write Status Mandatory Description swFwActLevel is used to point to the current level for classArea values, and is either default or customizable.
  • Page 329 For a read operation, the return value is either 2 (swFwDefault) or 3 Note (swFwCustom). 1 (swFwReserved) is obsolete. If the write operation sets the variable to 2 (swFwDefault), the following default action matrix variables are used for the Fabric Watch classArea combination: –...
  • Page 330 swFwThresholdEntry [swFwThresholdTable] Syntax SwFwThresholdEntry Access Not accessible Status Mandatory Description An entry of an individual threshold. Index swFwClassAreaIndex, swFwThresholdIndex Table 46. SwFwThresholdEntry Objects and Object Types SwFwThresholdEntry Objects See Page Object Types swFwThresholdIndex Integer swFwStatus SwFwStatus swFwName Display String of size 0 to 32 swFwLabel Display String of size 0 to 32 swFwCurVal...
  • Page 331 Status Mandatory Description Represents the element index of a threshold. For environment class, the indexes are from 2 through (number of Note environment sensors+1). For example, the indexes for environment class temperature area are: – envTemp001: index of 2 – envTemp002: index of 3 –...
  • Page 332 swFwStatus [swFwThresholdTable] Syntax SwFwStatus Access Read-write Status Mandatory Description Indicates whether a threshold is enabled or disabled. swFwName [swFwThresholdTable] Syntax Display String of size 0 to 32 Access Read-only Status Mandatory Description Name of the threshold. For examples, see the following table. Table 47.
  • Page 333 Table 47. swFwName Threshold Names (continued) eportSignal007 E_Port Loss of Signal 7 eportState007 E_Port State Changes 7 eportSync007 E_Port Loss of Sync 7 eportTXPerf007 E_Port TX Performance 7 eportWords007 E_Port Invalid Words 7 fabricDI000 Fabric Domain ID fabricED000 Fabric E_Port Down fabricFL000 Fabric Fabric Login fabricFQ000...
  • Page 334 Table 47. swFwName Threshold Names (continued) portSignal000 Port Loss of Signal 0 portState000 Port State Changes 0 portSync000 Port Loss of Sync 0 portTXPerf000 Port TX Performance 0 portWords000 Port Invalid Words 0 fopportCRCs013 FOP Port Invalid CRCs 13 fopportLink013 FOP Port Link Failures 13 fopportProtoErr0 FOP Port Protocol Errors 13...
  • Page 335 swFwCurVal [swFwThresholdTable] Syntax Integer Access Read-only Status Mandatory Description Current counter of the threshold. swFwLastEvent [swFwThresholdTable] Syntax SwFwEvent Access Read-only Status Mandatory Description Last event type of the threshold. swFwLastEventVal [swFwThresholdTable] Syntax Integer Access Read-only Status Mandatory Description Last event value of the threshold. swFwLastEventTime [swFwThresholdTable] Syntax Display String of size 0 to 32...
  • Page 336 Status Mandatory Description Last event time of the threshold. This value is in the same format as in swCurrentDate. Note swFwLastState [swFwThresholdTable] Syntax SwFwState Access Read-only Status Mandatory Description Last event state of the threshold. swFwBehaviorType [swFwThresholdTable] Syntax SwFwBehavior Access Read-write Status Mandatory...

  • Page 337: End Device Rls Table

    End Device Rls Table swEndDeviceRlsTable Syntax Sequence of SwEndDeviceRlsEntry Access Not accessible Status Mandatory Description The table of rls of individual end devices. swEndDeviceRlsEntry [swEndDeviceRlsTable] Syntax SwEndDeviceRlsEntry Access Not accessible Status Mandatory Description An entry of an individual end devices rls. Index swEndDevicePort, swEndDeviceAlpa Table 48.
  • Page 338 Because switches start with port 0, the SNMP port number should be Note physical port number + 1. In turn, that means that SNMP port 3 translates to port 2. swEndDevicePort [swEndDeviceRlsTable] Syntax Integer Access Not accessible Status Mandatory Description This object represents the port of the local switch to which the end device is connected.
  • Page 339 swEndDeviceLinkFailure [swEndDeviceRlsTable] Syntax Integer Access Read-only Status Mandatory Description Link failure count for the end device. swEndDeviceSyncLoss [swEndDeviceRlsTable] Syntax Integer Access Read-only Status Mandatory Description Synchronization loss count for the end device. swEndDeviceSigLoss [swEndDeviceRlsTable] Syntax Integer Access Read-only Status Mandatory Description Signal loss count for the end device.

  • Page 340: Sw Trap Types

    Status Mandatory Description Protocol error count for the end device. swEndDeviceInvalidWord [swEndDeviceRlsTable] Syntax Integer Access Read-only Status Mandatory Description Invalid word count for the end device. swEndDeviceInvalidCRC [swEndDeviceRlsTable] Syntax Integer Access Read-only Status Mandatory Description Invalid CRC count for the end device. sw Trap Types This section contains information that is specific to sw trap types, and includes the following subsections:...

  • Page 341: Sw Traps

    sw Traps swFault Enterprise Variables swDiagResult Description A 1 (swFault) is generated whenever the diagnostics detect a fault with the switch. #TYPE Switch is faulty. #SUMMARY Faulty reason: %d #ARGUMENTS #SEVERITY Critical #TIMEINDEX #STATE Non-operational swSensorScn (Obsoleted by swFabricWatchTrap) Enterprise Variables swSensorStatus, swSensorIndex, swSensorType, swSensorValue, swSensorInfo...
  • Page 342 Note that the sensor information contains the type of sensor and its number in textual format. #TYPE A sensor (temperature, fan, or other) changed its operational state. #SUMMARY %s: is currently in state %d #ARGUMENTS 4, 0 #SEVERITY Informational #TIMEINDEX #STATE Operational swFCPortScn...

  • Page 343: Traps For Fabric Watch Subsystems

    swEventTrap Enterprise Variables swEventIndex, swEventTimeInfo, swEventLevel, swEventRepeatCount, swEventDescr Description This trap is generated when an event level is at or below swEventTrapLevel. #TYPE A firmware event has been logged. #SUMMARY Event %d: %s (severity level %d) - %s #ARGUMENTS 0, 1, 2, 4 #SEVERITY Informational #TIMEINDEX...

  • Page 344: Traps For Track Changes Subsystems

    swFwLastEventTime, on page 335 swFwLastState, on page 336 Description Trap to be sent by Fabric Watch to notify of an event. #TYPE Fabric Watch has generated an event. #SUMMARY Threshold %s Class/Area %d at index %d has generated event %d with %d on %s.This event is #ARGUMENTS 2, 0, 1, 6, 4, 5, 7 #SEVERITY...

  • Page 345: Mib Functional Groupings

    MIB FUNCTIONAL GROUPINGS Overview This appendix provides a function-based listing of MIB objects. For information about the correlation of various objects to a particular function. Switch Variables MIB variables that assist in monitoring or modifying the status or state of switches are in the following tables or group: •...

  • Page 346: Sensor Variables

    Sensor Variables MIB variables that assist in monitoring or modifying the status or state of fans, power supply, and temperature are in the following tables: • “Connectivity Unit Sensor Table” page 127 • “Operating Environment Sensor Table (Temperature, Fan, Power Supply, and Others)”...

  • Page 347: Event Variables

    Event Variables MIB variables that assist in monitoring or modifying events are in the following table or group: • “Connectivity Unit Event Table” page 149 • “Event Group (To Map the errLog)” page 312 ISL and End Device Variables MIB variables that assist in monitoring or modifying ISL and end-devices are in the following tables or groups: ISL Variables •...
  • Page 348 MIB Reference Manual...

  • Page 349: Glossary

    GLOSSARY 8b/10b encoding Encoding scheme that converts each 8-bit data byte into a 10-bit transmission character. Used to balance ones and zeros in high speed transports. Address identifier Value used to identify source or destination of a frame. AL_PA Arbitrated Loop Physical Address. Unique 8-bit value assigned during loop initialization to each port in an arbitrated loop.
  • Page 350 Asynchronous Transfer Mode. Transport for transmitting data over LANs or WANs that transmit fixed-length units of data. Provides any-to-any connectivity and allows nodes to transmit simultaneously. AW_TOV Arbitration Wait Timeout Value. The minimum time an arbitrating L_Port waits for a response before beginning loop initialization. Bandwidth The total transmission capacity of a link, cable, or system.
  • Page 351 Class 3 A connectionless frame switching service between two ports, without notification of delivery or nondelivery. Can also be used to provide a multicast connection between originator and recipients, with notification of delivery or nondelivery. Class 4 Connection-oriented service that provides a virtual circuit between two ports, including notification of delivery or non-delivery.
  • Page 352 CT_IU Common Transport Information Unit. An information unit that conforms to the Fibre Channel Common Transport (FC_CT) protocol. Current fill word The fill word currently selected by the LPSM (loop port state machine). See also Fill word. Cut-through Switching technique that allows selection of a transmission route for a frame as soon as destination address is received.
  • Page 353 End-to-end flow Governs flow of Class 1 and 2 frames between N_Ports. See also control Buffer-to-buffer flow control, EE_Credit. Error As applies to fibre channel, a missing or corrupted frame, time-out, loss of synchronization, or loss of signal. See also Loop failure. Exchange As applies to fibre channel, a communication session between N_Ports involving the transmission of one or more related sequences, in one or both...
  • Page 354 FC-SW-2 The Fibre Channel Switch Fabric standard, second generation. Specifies tools and algorithms for interconnection and initialization of fibre channel switches. Fibre channel Protocol service that supports communication between fibre channel service transport providers. See also FSP. FIFO First In, First Out. May refer to a data buffer that follows the first in, first out rule.
  • Page 355 Fibre Channel Service Protocol. The common protocol used for all fabric services, transparent to fabric type or topology. See also FS. FSPF Fabric Shortest Path First. Routing protocol for fibre channel switches. Full-duplex Mode of communication that allows a port to simultaneously transmit and receive frames.
  • Page 356 Fibre channel wiring concentrator that collapses loop topology into physical star topology. Nodes are automatically added when active and removed when inactive. Idle Continuous transmission of an ordered set when no data is being transmitted to maintain an active fibre channel link and synchronization. See also Fill word.
  • Page 357 Link services Protocol for link-related actions. Loop Initialization Primitive. The signal used to begin initialization in a loop. Indicates either loop failure or resetting of a node. See also Loop initialization. LIS_HOLD_TIME The maximum period of time for a node to forward a loop initialization sequence.
  • Page 358 Multimode Fibre-optic cabling specification allowing up to 500 m between devices. N_Port Node Port. Port that can attach to a fibre channel port. See also NL_Port, Nx_Port. Network Address Authority. An identifier that indicates the format of a network address. Name server Service of storing names, addresses, and attributes for up to 15 minutes, provided by a switch to other entities in fabric.
  • Page 359 Participating mode Mode in which an L_Port in a loop has valid AL_PA and can arbitrate, send frames, and retransmit received transmissions. See also Nonparticipating mode. Path selection The selection of a transmission path through the fabric. Switches use the FSPF protocol.
  • Page 360 R_A_TOV Resource Allocation Timeout Value. Maximum time a frame can be delayed in the fabric and still be delivered. See also E_D_TOV. RAID Redundant Array of Independent Disks. Collection of disk drives that appear as a single volume to the server, and are fault-tolerant through mirroring or parity checking.
  • Page 361 Switch A combination of hardware and firmware that routes frames according to fibre channel protocol. Switches can have G_Ports, E_Ports, F_Ports, and FL_Ports. Switch Domain_ID Unique identifier for a switch, used in routing frames. Usually automatically assigned by the switch, but can be manually assigned by administrator. Switch name Arbitrary name assigned to switch by administrator.
  • Page 362 Tunneling Technique for enabling source and destination hosts to communicate when on same type of network, but connected by a different type of network. U_Port Universal Port. Switch port that can operate as G_Port, E_Port, F_Port, or FL_Port. A port is defined as a U_Port if not connected, or if it has not assumed a specific function in the fabric.
