HP Surestore 6164 - Switch User Manual

Distributed fabrics user's guide
Hide thumbs Also See for Surestore 6164 - Switch:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Reference Manual, User Manual
user's guide
version 2.2
Distributed Fabrics
www.hp.com

Advertisement

Table of Contents
loading

Related Manuals for HP Surestore 6164 - Switch

Summary of Contents for HP Surestore 6164 - Switch

  • Page 1 user’s guide version 2.2 Distributed Fabrics www.hp.com...

  • Page 2: Safety Notices

    Safety notices fitness for a particular purpose. Hewlett-Packard shall not be liable for errors contained herein or for incidental or Any servicing, adjustment, maintenance, or repair must be consequential damages in connection with the furnishing, performed only by authorized service-trained personnel.

  • Page 3: Table Of Contents

    CONTENTS Revision History ..........5 Preface .
  • Page 4 Installing Extended Fabrics ..... . . 23 Installing Through Telnet ........23 Installing Through Web Tools .

  • Page 5: Revision History

    Revision History July 2001 First release.
  • Page 6 HP Distributed Fabrics User’s Guide...

  • Page 7: Preface

    PREFACE This document covers the installation, setup or configuration, and use of the Remote Switch and Extended Fabrics products. Remote Switch, in conjunction with a compatible fibre channel to an asynchronous transfer mode (ATM) gateway, enables two fabric switches to be connected over an ATM connection, with a distance of up to 10 km between each switch and the respective ATM gateway.

  • Page 8: Related Publications

    Chapter 4 Provides an overview of Extended Introducing Extended Fabrics Fabrics. Chapter 5 Provides instructions for installing Installing Extended Fabrics Extended Fabrics. Chapter 6 Provides information for using Extended Using Extended Fabrics Fabrics. Related Publications Related product information can be found in the following publications. Those publications with part numbers are provided as printed copies with your product.

  • Page 9: Getting Help

    Getting Help For support information, visit the HP web site located at: http://www.hp.com Getting Software Updates Firmware and software updates are found on the HP web site at: http://www.hp.com New switch firmware can be installed from the following host operating systems: •...
  • Page 10 HP Distributed Fabrics User’s Guide...

  • Page 11: Introducing Remote Switch

    INTRODUCING REMOTE SWITCH The Remote Switch feature, in conjunction with a compatible fibre channel to asynchronous transfer mode (ATM) gateway, enables two fabric switches to be connected over an ATM connection, with a distance of up to 10 km between each switch and the respective ATM gateway. The two switches are cascaded together to form a fabric that, from the viewpoint of the connected hosts and storage devices, interact the same as locally connected switches.
  • Page 12 • Distributed management - Access to the management facilities (Web Tools, Telnet, and SNMP) is available from either the local or remote switch. Interconnect for switch management is routed through the fibre channel connection; no additional network connection is required between sites.

  • Page 13: Installing Remote Switch

    INSTALLING REMOTE SWITCH A Remote Switch fabric requires two switches with Fabric OS version a2.4.1 or later installed; both the switches must have the same configuration and a separate license for each switch. The switch licenses are applied by your HP Account Support Engineer (ASE) or Customer Engineer (CE). You can also install a license through telnet or Web Tools.

  • Page 14: Installing Through Web Tools

    Example: admin> licenseShow 1A1AaAaaaAAAA1a: Release v2.2 Web license Zoning license SES license QuickLoop license If the Remote Switch license is not included in the list or is incorrect, continue with Step 3. 3. Enter the following on the command line: licenseAdd “key”...
  • Page 15 3. Enter a logon name and password with administrative privileges and press Enter. The Administration View displays. 4. Select the License Admin tab, enter the license key in the License Key: field, and click Add License. The Remote Switch feature is available as soon as the license key is added.
  • Page 16 HP Distributed Fabrics User’s Guide...

  • Page 17: Using Remote Switch

    USING REMOTE SWITCH You can configure switches for use with Remote Switch through Telnet or through Web Tools. For information about using Web Tools to configure a switch, see the Web Tools User’s Guide. The Remote Switch feature operates in conjunction with a fibre channel to ATM gateway.

  • Page 18: Setting Up A Remote Switch Fabric

    the gateway E_Port moves to pass-through mode and passes fibre channel traffic from the switch E_Port to the ATM network. Setting Up A Remote Switch Fabric A Remote Switch fabric requires two switches, with identical configurations. In addition to the normal switch configuration options, you must configure these parameters: •...

  • Page 19: Accessing Through The Telnet Interface

    Accessing Through the Telnet Interface You can use the Telnet command to accomplish the following: configure • Set the R_A_TOV and E_D_TOV values. • Set the data field size. • Set the Class F frame suppression flag. You must disable the switch prior to entering the command.
  • Page 20 HP Distributed Fabrics User’s Guide...

  • Page 21: Introducing Extended Fabrics

    INTRODUCING EXTENDED FABRICS Extended Fabrics allows you to use fibre channel technology to create a fabric interconnected at a distance of up to 100 kilometers. You can use Extended Fabrics to increase the allowable distance between two switches, or between a switch and an ATM gateway in a Remote Switch configuration.
  • Page 22 HP Distributed Fabrics User’s Guide...

  • Page 23: Installing Extended Fabrics

    INSTALLING EXTENDED FABRICS Extended Fabrics requires a switch with Fabric OS version a2.4.1 installed and a license for each switch in the fabric. An Extended Fabrics license is installed on each switch by your HP Account Support Engineer (ASE) or Customer Engineer (CE).

  • Page 24: Installing Through Web Tools

    Example: admin> licenseShow 1A1AaAaaaAAAA1a: Web license Zoning license QuickLoop license Fabric license Fabric Watch license If the Extended Fabrics license is not included in the list, or is incorrect, continue with Step 3. If the licence is correctly listed, it is already installed.
  • Page 25 3. Enter a logon name and password with administrative privileges and press Enter. The Administration View displays. 4. Select the License Admin tab, enter the license key in the License Key: field, and click Add License. The Extended Fabrics feature is available as soon as the license key is added.
  • Page 26 HP Distributed Fabrics User’s Guide...

  • Page 27: Using Extended Fabrics

    USING EXTENDED FABRICS You can configure ports to support long-distance links through Telnet or through Web Tools. For information about using Web Tools to configure ports, see the Web Tools User’s Guide. Configuring Extended Fabrics To use Extended Fabrics, you must configure each switch in the fabric to support a long-distance extended fabric.

  • Page 28: Accessing Through The Telnet Interface

    There are three possible levels for a port: • Level 0 Reconfigures the port as a regular switch port. The number of buffers reserved for the port supports up to 10 km links. • Level 1 Distances up to 50 km. A total of 27 full-size frame buffers are reserved for the port.
  • Page 29 When this command is invoked without the optional operand, you are prompted to enter the long-distance level number. The level value must be one of the following: Level Effect Reconfigures the port as a regular switch port. The number of buffers reserved for the port supports links up to 10 km.
  • Page 30 In order to have a long-distance port take effect, all switches in the fabric must be configured to run in long-distance fabric mode (the long-distance fabric mode bit must be “on,” or set to 1). Otherwise, the fabric will be segmented.

  • Page 31: Glossary

    GLOSSARY This glossary provides definitions for fibre channel and switch terminology. Alias Server A fabric software facility that supports multicast group management. AL_PA Arbitrated Loop Physical Address. An 8-bit value used to uniquely identify an individual port within a loop. A loop can have one or multiple AL_PAs. Arbitrated Loop Afibre channel transport structured as a loop.
  • Page 32 Credit When applied to a switch, the maximum number of receive buffers provided by an F_Port or FL_Port to its attached N_Port or NL_Port, respectively, such that the N_Port or NL_Port can transmit frames without over-running the F_Port or FL_Port. Defined The complete set of all zone objects that are defined in the fabric.
  • Page 33 FSPF Fibre-Channel Shortest Path First. A routing protocol used by fibre channel switches. G_Port A generic port that can operate as either an E_Port or an F_Port. A port is defined as a G_Port when it is not yet connected, or has not yet assumed a specific function in the fabric.
  • Page 34 POST Power on self-test. A series of self-tests that run each time the unit is booted or reset. R_A_TOV Resource Allocation Timeout Value. Used to time out operations that depend on the maximum possible time that a frame can be delayed in a fabric and still be delivered.
  • Page 35 Zone A set of hosts and devices attached to the same fabric and designated as belonging to the same zone. Any device connected to the fabric can be configured into one or more zones. Zone alias An alias for a set of port numbers or WWNs. Zone aliases can be used to simplify the entry of port numbers and WWNs.
  • Page 36 HP Distributed Fabrics User’s Guide...

  • Page 37: Index

    INDEX ATM gateway 17 line speed performance 21 long-distance fabric mode bit, setting 27 BB credit 18 buffers, frame 28 performance, Extended Fabrics 21 port levels 28 Class F frames 18 configuring ports for long-distance 28 quads, definition of 28 data field size 18 R_A_TOV 18 E_D_TOV 18...
  • Page 38 updates, software 9 installing Remote Switch by 14 HP Distributed Fabrics User’s Guide...
