Installing the Wheel Chocks

WARNING This jukebox rolls easily and could cause injury or damage if allowed to move
unintentionally.
Four wheel chocks are provided to stabilize the jukebox in position. Install the
wheel chocks after the jukebox is moved to its operating position and all cables
are in place.
Figure 1-5 Installing the Wheel Chocks
1. After all cables and panels are mounted, roll the unit to its final position.
2. Spread the chock apart slightly and slide it around the bottom of the wheel as
3. Repeat Step 2 for the remaining three wheels.
NOTE
This is the last step in the physical installation.
Chapter 1
shown on the left side of the figure above.
Setting Up the Jukebox
Installing the Wheel Chocks
1-19
