Fabric profile
Related API and classes
Table 5
TABLE 5
Property name
InstanceID [Key]
TypeOfSet[]
ElementName
RedundancyStatus
LoadBalanceAlgorithm
OtherTypeOfSet[]
OtherLoadBalanceAlgorithm
Table 6
TABLE 6
Property name
Antecedent
Dependent
Table 7
TABLE 7
Property name
Collection
Member
42
represents the group of switch ports forming a trunk.
Brocade_Trunk: CIM_RedundancySet
Type
string
uint16
string
uint16
uint16
string
String
explains the properties of Brocade_TrunkInSwitch: CIM_HostedCollection class.
Brocade_TrunkInSwitch: CIM_HostedCollection
Type
Brocade_Switch REF
Brocade_Trunk REF
explains the properties of Brocade_SwitchFCPortInTrunk: CIM_MemberOfCollection class.
Brocade_SwitchFCPortInTrunk: CIM_MemberOfCollection
Type
Brocade_Trunk REF
Brocade_SwitchFCPort REF
Description
InstanceID opaquely and uniquely identifies an instance of this
class.
The format of this key is as follows.
SOURCESWITCHWWN=<value>;
SOURCESWITCHTYPE=<value>:
DESTINATIONWWN=<value>;
SOURCESWITCHPORTWWN=<value>;
DESTPORTWWN=<value>;
CLASSNAME=Brocade_Trunk;
DESTINATIONTYPE=<value>;
SOURCE_WWN is the master switch WWN of one end.
SOURCE_PORT_WWN is the master port WWN of the trunk
members in a trunk group.
DEST_WWN is the WWN of the other end, which is a switch in case
of an ISL trunk and AG in case of an trunk.
DEST_PORT_WWN is the port WWN of the other end.
SOURCE_TYPE is the type of the source (Switch=0, Device=1)
DEST_TYPE is the type of the other end (Switch=0, Device=1)
TypeOfSet provides information on the type of redundancy.
A user-friendly name for the object.
RedundancyStatus provides information on the state of the
RedundancySet.
The current load balance algorithm.
When the corresponding array entry in TypeOfSet[] is "Other", this
entry provides a string describing the type of set.
When LoadBalanceAlgorithm is "Other", this property describes
the algorithm.
Brocade Network Advisor SMI Agent Developer's Guide
Description
Represents the switch objects that
has the trunk.
Represents the trunk object.
Description
Represents the trunk object.
Represents the member of the
trunk.
