1-2. Customer Maintenance

Adjustment
Print head At print head replacement.
alignment
Print head When print quality is not
cleaning satisfying.
Print head When print quality is not
deep cleaning satisfying, and not improved
by print head cleaning.
Ink tank When an ink tank becomes
replacement empty. ("No ink error" via the
computer, or ink tank LED
flashing fast in red)
Paper feed When necessary
roller cleaning
CD / DVD print At CD / DVD printing, when
position
necessary
adjustment
Bottom plate When the back side of the
cleaning paper is smeared
ASF sub- roller When the paper fed from the
ASF is smeared due to ink
cleaning
mist attached to the ASF sub-
rollers.

1-3. Product Life

(1) Printer
Specified print volume (I) or the years of use (II), whichever comes first.
(I) Print volume : 18,000 pages
Black
Timing
To ensure accurate dot
placement.
To improve nozzle
conditions.
To improve nozzle
conditions.
To clean the paper feed
rollers.
To correct CD / DVD print
position.
To clean the platen ribs.
To clean the ASF sub-
rollers.
1,500 character pattern
Purpose
-----
8,300 pages
1-2
Tool
- Printer buttons
- Computer
(automatic
settings via the
printer driver)
- Printer buttons
- Computer (settings
via the printer
driver)
Computer (settings
via the printer
driver)
-----
Printer buttons
Computer
5 min.
(application
software)
- Plain paper
1 min.
- Computer (settings
via the printer
driver)
- Plain paper
1 min.
- Printer buttons
[See Part 2, 4. FAQ,
How to make and
set the ASF sub-
roller cleaning
sheet, for details]
Approx.
time
3 min.
1 min.
2 min.
1 min.
2 min.
