Canon PIXMA iP5200 Service Manual page 55

Remaining ink amount
detection
Paper type detection
Print head alignment
*1: Only for CD / DVD printing supported regions
<Print head>
Type
Print head
Ink color
Ink tank
Weight (Net)
Supply method
Part number
<Supported ink tanks>
Model Destination
Overseas
PIXMA iP5200
models
O: Usable X: Not usable
Note:
The ink tanks BCI-9BK and BCI-7e series available in Japanese market are not compatible with the
PIXMA iP5200 overseas models.
Be sure to use the appropriate ink tanks in servicing.
center.)
Available (automatic detection by optical method and dot count, enabled at default)
Not available
Available (automatic or manual alignment via driver utilities, or the Resume/Cancel
button in Camera Direct Printing, automatic alignment at default)
Single head with 5 removable ink tanks (each color)
Black: 512 nozzles (600dpi), 30pl (pigment-based black)
Color: 512 nozzles x 6 (1,200dpi), 1pl / 5pl (cyan, magenta), 5pl (black, yellow)
Pigment-based black, Dye-based black, cyan, magenta, yellow
PGI-5BK (pigment-based), CLI-8BK/C/M/Y (dye-based)
Print head, approx. 60g
As a service part (not including ink tanks)
QY6-0061-000
Pigment-
based
PIG-5BK
O
BCI-9BK
X
<PIXMA iP5200 Specifications>
CLI-8BK CLI-8C
O O
BCI-7eBK BCI-7eC
X X
3-10
Dye-based
CLI-8M
O
BCI-7eM
X
CLI-8Y
O
BCI-7eY
X
