PIXMA iP5200 Specifications
<Printer>
Type
Paper feeding method Auto sheet feed (ASF, cassette, automatic duplex printing, CD / DVD printing
Resolution
Throughput (target
value)
Printing direction
Print width
Interface
ASF stacking capacity Plain paper: Max. 13mm (Approx. 150 sheets of 64g/m
Paper weight
Detection functions
Acoustic noise
(Highest print quality)
Environmental
requirements
Power supply
External dimensions
Weight
Related standards
(Printer, Adapter)
Serial number location On the carriage flexible cable holder (visible on the right of the carriage after the
Desktop serial color bubble jet printer
9,600 x 2,400dpi (Max.)
- 4 x 6, borderless printing: Approx. 36 sec. (standard mode, PP-101, Full Page
SCID No. 2)
- Camera Direct Printing: Approx. 1 minute and 19 sec. (4 x 6, borderless printing,
PP-101, default settings)
For reference:
Black (Fine Black)
Color (Fine Color)
Bi-directional, uni-directional
Max. 203.2mm (216mm in borderless printing)
USB 2.0 Hi-Speed
2
64 to 105g/m
Access cover open, Presence of print head / ink tanks, Opening / Closing of front
door, Remaining ink amount (optical / dot count), Printing position, Paper presence,
Paper end sensor, Waste ink amount, Internal temperature, Pick-up roller, Paper
feed roller position, Carriage position, Head-to-paper distance, Supported camera
direct printing device, Presence of CD / DVD
- Highest print quality settings: Approx. 34.7dB
- Quiet mode: Approx. 34.3dB
During operation
Non operation
Power supply voltage,
frequency
AC 100 to 120V, 50/60Hz
AC 220 to 240V, 50/60Hz
Printer:
With the paper support and output tray retracted:
Approx. 444 (W) x 309 (D) x 160 (H )mm
Approx. 17.7 (W) x 12.3 (D) x 6.4 (H) inches
Approx. 7.3kg, not including print head and optional units
Electromagnetic radiance:
FCC, IC, CE Mark, Taiwan EMC, C-tick, CCC (Chinese EMC), Korea MIC, Gost-
R
Electrical safety:
UL, C-UL, CB Report, CE Mark, GS, Gost-R, FT, SASO, CCC(Safety), SPRING,
Korea EK, IRAM (Argentine Safety)
Environmental regulations:
RoHS (EU), WEEE (EU), Korea Package Recycle Law, Green Point (Germany),
Energy Star
printer is turned on, the access cover is opened, and the carriage moves to the
Fast Standard
30ppm 15.0ppm
24ppm 11.7ppm
Temperature 5C to 35C (41F to 95F)
10%RH to 90%RH (no
Humidity
condensation)
Temperature 0C to 40C (32F to 104F)
Humidity 5%RH to 95%RH (no condensation)
Power
consumption
Approx. 17W
Approx. 17W
3-9
2
paper)
Standby Power-off
Approx. 0.8W Approx. 0.4W
Approx. 0.8W Approx. 0.4W
*1
)
