Canon PIXMA iP5200 Service Manual page 62

Wired LAN Wired LAN enabled/disabled
MAC Address MAC address for wired LAN
on NIC board
Link Status Status of wired LAN
When wired LAN is invalid,
status becomes Inactive.
Other than this case, status
becomes Active.
Transmission Current wireless LAN speed
Rate 10/100 Mbps
When inactive, left blank
Mode IP address setting method
When disabled, left blank
IP Address Current IP address
When disabled, left blank
Subnet Mask Current Subnet mask
When disabled, left blank
Default Current default Gateway
Gateway When disabled, left blank
MAC Address MAC address filtering setting
IP Address IP address filtering setting
Admin Admin password setting
Password
Device Status Printing of device status
When error occurs, error
code is displayed. Other
than this case, Available is
displayed.
Enabled/Disabled
-
-
-
Auto/Manual
0.0.0.0 - 255.255.255.255
0.0.0.0 - 255.255.255.255
0.0.0.0 - 255.255.255.255
ON/OFF
ON/OFF
ON/OFF
7
Enable
[NIC BOARD-specific
value. Fixed]
Inactive
[Blank]
Auto
192.168.2.123
255.255.255.0
0.0.0.0
OFF
OFF
OFF
Available
O
O
O
O
O
O
O
O
