Canon PIXMA iP5200 Service Manual page 18

Platen unit: QM2-
2248
Purge unit: QM2-
2252
Waste ink tube:
QC1-6458
Waste ink tube
holder: QC1-6460
Platen unit
QM2-2248
PR lift shaft ass'y
QL2-0936
CL INPUT GEAR
QC1-6213
Timing slit strip film
QC1-6526
Timing slit disk film
QC1-6229
Print head
QY6-0061
*1: General notes:
- Make sure that the flexible cables and wires in the harness are in the proper position and
connected correctly.
[See 3-2. Special Notes on Repair Servicing, (2) Flexible cable and harness wiring, connection, for
details.]
- Protect the waste ink tube from being pinched when assembling the printer unit chassis into the
bottom case unit.
Since the tube conditions after assembly are not visible, perform the manual purging 3 or 4 times
to confirm that no strange noise is heard.
[See 3-2. Special Notes on Repair Servicing, (3) Printer unit and bottom case unit assembly, for
details.]
other red screws.)
- By attaching the tape at
the specified 2 locations,
secure the waste ink
tube to the waste ink
tube holder.
- Upon contact with the
film, wipe the film with
ethanol.
- Confirm no grease is on
the film. (Wipe off any
grease thoroughly with
ethanol.)
- Do not bend the film
[See 3-3. Adjustment /
Settings, (1) Paper feed
motor adjustment.]
At replacement:
1. To protect the waste
ink tube from being
pinched when
reassembling the
printer unit chassis into
the bottom case unit,
tape the tube (at 2
locations).
[See 3-2. Special Notes
on Repair Servicing, (3)
Printer unit and bottom
case unit assembly.]
After replacement :
1. Check the ink system
function.
[See 3-3. Adjustment /
Settings, (5) Service
mode.]
At replacement:
1. Apply grease to the
sliding portions.
[See 3.3. Adjustment /
Settings, (2) Grease
application.]
After replacement:
1. Perform the print head
alignment in the user
mode.
After replacement:
1. Perform the print head
alignment in the user
mode.
1-13
After the printer unit is
assembled in the bottom
case unit, the tube
conditions are not
visible. For confirmation
of the tube conditions,
perform the manual
purging 3 or 4 times,
and confirm that no
strange noise is heard.
- Service test print
- Service test print
- Service test print
- Service test print
