Canon PIXMA iP5200 Service Manual page 58

Part 1 MAINTENANCE
1. MAINTENANCE
1.1 Adjustment, Periodic Maintenance, Periodic Replacement Parts, and
Replacement Consumables by Service Engineer
(1) Adjustment (added to iP 5200)
Adjustment
Network setting
information print
(NIC EEPROM
information print)
2. LIST OF ERROR DISPLAY / INDICATION
2.2 Service Call Errors (added to iP5200)
Cyclic blinking in
orange (Alarm
LED) and green
(Power LED)
18 times
2.4 Troubleshooting by Symptom
Printing is not possible with
wireless LAN.
3. REPAIR
3.1 Notes on Service Part Replacement (and Disassembling/Reassembling)
Service part
NIC BOARD ASS'Y
(QK1-1973-000)
Timing
NIC BOARD
replacement
Error
NIC BOARD error
[6550]
Symptom
Notes on replacement
Purpose
To confirm operations
(Replacement of listed parts, which are likely to be faulty)
NIC BOARD ASS'Y (QK1-1973-000)
Solution
1) Perform network setting information
print.
When printing is not possible. -> Replace
the NIC BOARD.
When printing is possible. -> Proceed to
2).
2) Perform printing with the wireless
LAN I/F.
When printing is not possible. -> Replace
the NIC BOARD.
(Wireless reception component failure on
the NIC BOARD)
When printing is possible. -> Re-confirm
network setting (user's environment).
Adjustment/settings
3
Tool
None.
Solution
Remarks
Operation check
- Network setting
information print
- Printing with
wireless LAN I/F
(After printing,
EEPROM
initialization of NIC
BOARD is
necessary.)
Approx.
time
1 min.
