Configuring an array

In this section

Introduction ........................................................................................................................................... 13

Comparing the utilities ............................................................................................................................ 13

Using ORCA.......................................................................................................................................... 14
Using ACU ............................................................................................................................................ 15
Using CPQONLIN.................................................................................................................................. 15
Introduction
HP provides four utilities for manually configuring an array on a Smart Array controller:
ORCA—A simple ROM-based configuration utility
ACU—A versatile, browser-based utility that provides maximum control over configuration
parameters
ACU CLI—A command line version of ACU
CPQONLIN—A menu-based configuration utility specifically for servers using Novell NetWare
For more information about the features of these utilities, see "Comparing the Utilities (on page 13)."
Whichever utility you use, be aware of the following limitations:
For the most efficient use of drive space, do not mix drives of different capacities within the same
array. The configuration utility treats all physical drives in an array as if they have the same capacity
as the smallest drive in the array. The excess capacity of any larger drives is wasted because it is
unavailable for data storage.
All drives in an array must be of the same type (for example, all SAS or all SATA).
The probability that an array will experience a drive failure increases with the number of physical
drives in the array.
For conceptual information about arrays, logical drives, and fault-tolerance methods, and for information
about default array configuration settings, refer to the HP Array Configuration Utility User Guide. This
document is available on the Documentation CD that is provided in the controller kit.
Comparing the utilities
NOTE: A + in the appropriate column indicates that the feature or procedure is supported, while -- indicates
that the feature or procedure is not supported.
Supported features
Uses a graphical interface
Available in languages other than English
Executable at any time
Available on CD
ACU CPQONLIN
+ --
+ --
+ +
+ +
ORCA
--
--
Only during POST
CD not necessary;
located in ROM
Configuring an array 13
