DISTRIBUTION AMPLIFIERS MANUAL PART NUMBER: 400-0066-003 PRODUCT REVISION: 2 DA1322AT 1-IN, 2-OUT RGBHV DISTRIBUTION AMPLIFIER (W/EQ & GAIN) USER’S GUIDE... -
Page 2: Table Of Contents
APPLICATION DIAGRAM ..5 INSTALLATION ..6 OPERATION ..6 ACCESSORIES..6 FREQUENTLY ASKED QUESTIONS...7 TROUBLESHOOTING GUIDE ...7 ALTINEX POLICY ..8 LIMITED WARRANTY..8 RETURN POLICY ..8 CONTACT INFORMATION ... 8 TABLE OF CONTENTS Page... -
Page 3: Precautions / Safety Warnings
Do not place heavy objects on top of the DA1322AT. If the DA1322AT is to be mounted, DISTRBUTION AMPLIFIERS to a table or wall, use only Altinex made mounting DA1293FC, Rack Mount Ears DA1294FC) and cables for optimum setup. -
Page 4: About Your Distribution Amplifier 2
Any changes or modifications to the unit not expressly approved by Altinex, Inc. could void the user’s authority to operate the equipment. ABOUT YOUR DISTRIBUTION AMPLIFIER 2 The DA1322AT is a 1-in 2-out RGBHV high- resolution video distribution amplifier designed to... -
Page 5: Description Of Da1322At
Coupling Cross-talk Power Internal Power Adapter Power Consumption Table 3. DA1322AT Electrical DESCRIPTION OF DA1322AT DISTRBUTION AMPLIFIERS @ 100MHz (on) -40dB @10MHz 95-240 V Continuous 10 watts max. -
Page 6: Input/Outputs
4.1 INPUT/OUTPUTS The outputs of the DA1322AT allow signals to be driven through 100 feet or more of cable depending on cable quality and the source signal resolution. DA1322AT connectors for each input and output representing red, green, blue, and separate horizontal and vertical sync. -
Page 7: Installation
DA1322AT using a high quality coaxial-type cable. If the source offers a VGA-type 15-pin HD connector, for instance, Altinex part # MS8102CA (6' – 15-pin HD male to 5 BNC male) may be used. The active signal indicator on the back panel will light. -
Page 8: Frequently Asked Questions
NOTE: The sync pulse voltage must be at least 1.4 volts for proper operation of the distribution amplifier. If lower voltage is used, contact Altinex for additional information. instead coaxial cable, because you will loose the quality of the receiving signal. -
Page 9: Altinex Policy
11.2 RETURN POLICY It is very important that you receive products that you have ordered and that this product fulfills your need. In the unlikely event that an Altinex product needs to be returned please follow the policies below: Altinex will accept product returns for a period of 30 days from authorized Altinex dealers.
