Page 1: Distribution Amplifiers
DISTRIBUTION AMPLIFIERS MANUAL PART NUMBER: 400-0018-003 PRODUCT REVISION: 0 DA1406WM 1-IN, 6-OUT MAC DISTRIBUTION AMPLIFIER USER’S GUIDE... -
Page 2: Table Of Contents
INSTALLING YOUR DISTRIBUTION AMPLIFIER..6 OPERATION ..6 ACCESSORIES..7 FREQUENTLY ASKED QUESTIONS... 7 TROUBLESHOOTING GUIDE ... 8 ALTINEX POLICY ..8 LIMITED WARRANTY..8 RETURN POLICY ..8 CONTACT INFORMATION ... 8 TABLE OF CONTENTS Page... -
Page 3: Precautions / Safety Warnings
Do not place heavy objects on top of the DA1406WM. If the DA1406WM is to be mounted to a table or wall, use only Altinex made mounting accessories like brackets ( DA1293FC and DA1294FC) and cables for optimum setup. -
Page 4: About Your Distribution Amplifier
Any changes or modifications to the unit not expressly approved by Altinex, Inc. could void the user’s authority to operate the equipment. ABOUT YOUR DISTRIBUTION AMPLIFIER The DA1406WM is a 1-in 6-out MAC distribution amplifier designed to connect a single computer video source to as many as six scan rate compatible displays. -
Page 5: Description Of Da1406Wm
DA1406WM can be easily adapted to 5-BNC connectors to allow it to be used with RGsB, RGBS, or RGBHV signal types as well. This requires the use of Altinex MS8100 series adapter cables (15 pin to 5 BNC). DISTRIBUTION AMPLIFIERS PIN No. -
Page 6: Application Diagram
PIN No. Input signals on 15-pin D female connector Vertical Sync Ground Ground Horizontal Sync Table 4. The DA1406WM Input pin-out PIN No. Output signals on 15-pin D female connector Ground Composite Sync No connection Green Ground No connection No connection No connection Ground Vertical Sync... -
Page 7: Installing Your Distribution Amplifier
INSTALLING YOUR DISTRIBUTION AMPLIFIER Step 1. Make sure that the power input is set to the proper AC voltage in your country. An incorrect setting can result in equipment damage not covered by warranty. If the power input voltage needs to be changed, remove the fuse portion of the power entry module and change the location of the fuse. -
Page 8: Accessories
ACCESSORIES Model No. Description TABLE MOUNT BRACKET TM1271 1 U High, ½ rack units 1 U High, ½ rack units w/Computer TM1272 Input TM1273 1 U High, ½ rack units w / Computer + A / V Inputs 1 U High, ½ rack units w / Computer + TM1274 A / V + Power Inputs RACK MOUNTING ACCESSORIES... -
Page 9: Troubleshooting Guide
It is very important that you receive products that you have ordered and that this product fulfills DA1406WM unit; your need. In the unlikely event that an Altinex product needs to be returned please follow the policies below: Altinex will accept product returns for a period of 30 days from authorized Altinex dealers.
