Page 1: Distribution Amplifiers
DISTRIBUTION AMPLIFIERS MANUAL PART NUMBER: 400-0001-003 PRODUCT REVISION: 1 DA1902SX 1 RGBHV - IN, 2 VGA - OUT DISTRIBUTION AMPLIFIER USER’S GUIDE... -
Page 2: Table Of Contents
We appreciate your selection of our products and are confident that you will join the ranks of our many satisfied customers throughout the world. This manual covers: DA1902SX – 1 RGBHV – in, 2 VGA - out Distribution Amplifier DISTRIBUTION AMPLIFIERS purchase PRECAUTIONS / SAFETY WARNINGS ...2... -
Page 3: Precautions / Safety Warnings
Distribution Amplifier on a flat, level surface in a dry area away from dust and moisture. To prevent fire or shock, do not expose this unit to rain or moisture. Do not place the DA1902SX Distribution Amplifier in direct sunlight, near heaters or heat radiating appliances, or near any liquid. -
Page 4: About Your Distribution Amplifier 2
Though primarily designed for RGBHV format signals, the DA1902SX is capable of passing RGBS and RGsB signals as well. With its compact design and very low cost, the DA1902SX makes for an ideal distribution amplifier in either a small or a large system. -
Page 5: Description Of Da1902Sx
External Power Adapter Table 3. DA1902SX Electrical DESCRIPTION OF DA1902SX INPUT AND OUTPUTS The outputs of the DA1902SX allow signals to be driven through up to 100 feet of cable or more depending on the cable quality and the signal source resolution. -
Page 6: Application Diagram
In the Serial Distribution System, the DA1904SX acts as an output module. Ordinarily, the source signal is connected to the input of a DA1902SX and this becomes the starting point for the bus. The outputs are then connected to the output modules, DA1904SX, which are usually located at each display site. -
Page 7: Installing Your Distribution Amplifier
DA1904SX by using VGA type cables (Altinex CB3700 Series Cables). Step 4. If the DA1902SX is being used in the Serial Distribution System, make sure that the end of the video bus is properly terminated with a monitor or with a termination plug. -
Page 8: Operation
OPERATION The DA1902SX will operate successfully as long as the cables are attached properly and other technical specifications are followed. There are no other adjustments necessary to operate the unit. ACCESSORIES Model No. Description RACK MOUNTING ACCESSORIES Mount mini-brackets (2 – “L” shape) -
Page 9: Troubleshooting Guide
DISTRIBUTION AMPLIFIERS 11.2 RETURN POLICY It is very important to Altinex that you receive the products that you have ordered and that this product fulfills your need. In the unlikely event, that an Altinex product needs to be returned...
