Summary of Contents for Altinex DA1913GL
-
Page 1: Distribution Amplifiers
DISTRIBUTION AMPLIFIERS MANUAL PART NUMBER: 400-0038-003 PRODUCT REVISION: 0 DA1913GL 1-IN, 2-OUT RGBS DISTRIBUTION AMPLIFIER USER’S GUIDE... -
Page 2: Table Of Contents
INTRODUCTION Thank you for purchasing DA1913GL Distribution Amplifier. We are sure you will find it a reliable and useful product. Superior performance for the right price backed by solid technical and customer support is what we have to offer. The product you are holding in your hands is designed using state-of-the-art technology and is superior to anything available on the market. -
Page 3: Precautions / Safety Warnings
To prevent fire or shock, do not expose this unit to rain or moisture. Do not place the DA1913GL Distribution Amplifier in direct sunlight, near heaters or heat radiating appliances, or near any liquid. -
Page 4: About Your Distribution Amplifier 2
It may also be mounted to almost any surface using optional ”L” type mini brackets. Note: A power adapter for the DA1913GL must be ordered separately, if required. In the United States, the PS5502US Power Adapter can be used, though the connector must be cut off to allow interconnection. -
Page 5: Description Of Da1913Gl
DESCRIPTION OF DA1913GL DISTRIBUTION AMPLIFIERS -0.3V 4.1 POWER 10k Ohms The DA1913GL requires the use of a 9-12V DC 500mA power supply. The DA1913GL is provided 1.0V p-p/0.7V p-p with a hard-wired 12-inch power input cable with bare leads on the end. -
Page 6: Application Diagram
DA1913GL. projectors must be scan-rate compatible with the source signal resolution. DA1913GL does not affect the scan rate. Step 4. If the image is less than perfect, check all the connections. The unit is very reliable and seldom will this be the cause of malfunction. -
Page 7: Accessories
It is not recommended since one power supply is supplied with each unit. Please consider the PS5581SM, a rack mount power supply. The DA1913GL has two individually buffered outputs. The common mode range of the DA1913GL Distribution Amplifier is +/-2V with a video signal of 1V p-p. -
Page 8: Troubleshooting Guide
11.2 RETURN POLICY It is very important that you receive product that you have ordered and that this product fulfills your need. In the unlikely event that an Altinex product needs to be returned please follow the procedure below: Altinex will accept product returns for a period of 30 days from authorized Altinex dealers.
