MFJ-1278B MULTI-MODE
MFJ P/N Descrpition
Capacitor: Monolithic Ceramic
205-1210 .1 UF, Z5U, 20%
Capacitor: Electrolytic
203-0012 10 uf, 16V, Radial
IC Sockets
625-0031 14-pin Socket
625-0030 16-pin Socket
625-0291 20-pin Socket
IC's
310-3074 74HCT74, D Flip-Flop
310-4393 74HCT393, Dual Binary
Divider
310-4374 74HCT374, Octal Latch
310-0054 4053B, Triple 2-CH
CMOS SWITCH
Miscellaneous
620-6110 Right Angle "L" Brackets for Mounting add-on pcb.
Same as bracket for tuning indicator pcb.
620-6110 10-conductor Ribbon Jumper.
Same as ribbon jumper used on the tuning indicator
board except 20 conductors.
862-1278-3 PCB, GRAYSCALE BOARD, APPOX. 1" X 5.312"
APPENDIX I PARTS LIST
Component ID
C301, C304
C302, C303
U301, U302
U305, U306
U303, U304
U301
U302
U303, U304
U305, U306
