The PIXTONES values are in Hexidecmal format. If the picture transmitted does not seem
to have the right contrast, try reseting the PIXTONES values.
The HEX values that represent the PIXTONES for the pictures to be transmitted are listed in
Table below:
PIXTONES Values
(In HEX)
$86
$8E
$92
$AC
$9D
$AD
$B0
$B2
$B6
$B5
$B3
$B8
$BC
$BA
$BE
$B9
$BD
$BB
$BF
OPERATIONAL COMMANDS
FAX/SSTV
TransmitTones (Hz)
1100 sync
1200 "
1300 "
1500 "
1550 White
1600 "
1650 "
1700 "
1750 "
1800 Light Gray
1850 "
1900 "
1950 "
2000 "
2050 Dark Gray
2100 "
2150 "
2200 "
2250 Black
