MFJ Multi-mode Data Controller -1278B User Manual page 381

MFJ-1278B MULTI-MODE
MFJ P/N Descrpition
806-0210-1278 CABINET COVER.
NOTE
: MASK OUT PAINT ON THE INSIDE OF THE TOP CHASSIS PIECE.
THIS IS TO INSURE GOOD CONTACT WITH CHASSIS REDUCE EMI.
770-1162 STICK-ON RUBBER FEET
781-2110 FCC STICKER, INSTALL UNDER CHASSIS
781-1118 SERIAL NO. STICKER. INSTALL ONE UNDER
CHASSIC AND ONE ON OUTSIDE OF GIFT BOX.
852-1027 SMALL FORM PACKING INSERT
852-1028 LARGE FORM PACKING INSERT
850-1108 1278B PRINTED GIFT BOX, WITH REVISED
ARTWORK FOR REV. 10 PCB.
ADDITION PARTS FOR MFJ-1278BT ONLY
50-2400B-1 2400 BAUD MODEM PCB ASSEMBLY
10-22008 MODEM CONNECTING CABLE ASSEMBLY:
3", 5 PIN CONNECTOR JUMPER CABLE WITH
5 POS. IDC SOCKET ON EACH END.
716-2050 .5" NYLON MOUNTING SPACER
700-3063 6-32 X .25", MACHING SCREW FOR
MOUNTING MODEM PCB.
NOTE
: FOR MFJ-1278T, BEFORE INSTALLING 50-2400B-1 MODEM PCB
ASSEMBLY, REMOVE ALL SHORING JUMPERS ON J4.
BOM for Display PC Assembly: P/N: 50-1274-2
100-0009 470 ohm, 1/4 W, 5%
APPENDIX I PARTS LIST
Component ID
R209, R210
