MFJ Multi-mode Data Controller -1278B User Manual page 379

MFJ-1278B MULTI-MODE
MFJ P/N Descrpition
601-6021 2.0 MM PIN, COAXIAL JACK,
PC MOUNT, MALE
601-5003 3.5 MM, MINIATURE PC
MOUNT JACK, STEREO
600-0011 RCA PHONO JACK, RIGHT
ANGLE PCB MOUNT
612-4001 2-POSITIONS, PUSH-ON JUMPER
MOLEX 15-38-1024 OR EQUAL
PUSH-ON JUMPER TO BE :
INSTALLED ON
MISCELLANEOUS
402-1100 10 UH, 20%, MOLDED INDUCTOR
NYTRONICS: RFS-10 OR EQUAL
401-0102 10 UH, 20%, MOLDED INDUCTOR
DALE IM-4 OR EQUAL
405-0090 4.9152 MHZ, HC-18/U CRYSTAL
504-0022 DPDT, ON/OFF SWITCH
ITT SHADOW F-2UEE OR EQUAL
760-2140 RED CAP FOR SW1, ROUND
760-0030 KNOB FOR R131
730-1305 3-VOLTS, LITHIUM BATTERY,
COIN TYPE CR2430 OR EQUAL
730-2293 COIN BATTERY HOLDER
752-1268 BAR GRAPH DISPLAY FILTER, RED
APPENDIX I PARTS LIST
Component ID
P1
P2, P3, P11#
J11
JMP5, JMP8, JMP 9 (2)
JMP13, JMP14 (1)
JMP 16 (2), JMP18 (1)
JMP19 (32K), JMP22
JMP24, JMP26, JMP A
JMP E, JMP F, JMP G
JMP H, JMP J, J4 (4)
L1
L2, L4
Y1
SW1
BATT 1
BATT 1
