MFJ-1278B MULTI-MODE
FARNSWOR ON/OFF
Parameters:
ON Enables the FARNSWORTH special spacing.
OFF Disables the FARNSWORTH special spacing.
Many find training for CW tests with a FARNSWORTH method of code generation more
valuable because it teaches letter recognition at a speed fast enough to avoid the common
learning "plateau". Some people have trouble passing this plateau as they increase their code
speed.
When FARNSWOR is ON the MFJ-1278B transmits CW characters from keyboard or the
Memory Keyer using 15 WPM equivalent letters and elements. Setting FARNSWOR to
OFF causes CW text to be sent at normal timing at the selected speed.
FAXEOP ON/OFF
When FAXEOP is ON, the MFJ-1278B detects the end-of-picture for received FAX by
looking for a long period of idle tone. Setting it OFF disables all FAX end-of-picture detect,
and the user must manually terminate reception by returning to command mode.
FAXMODE n
n= 1 thru 7; specifying a particular FAX format.
The FAXMODE command of the MFJ-1278B specifies the FAX format, in terms of speed.
FAXMODE (n) and speed are shown in the Table below.
FAXMODE(n)
1 60 lines/min. or 1 line/sec.
2 90 "
3 120 "
4 240 "
5 360 "
6 480 "
7 180 "
OPERATIONAL COMMANDS
Mode: CW
Mode: FAX
Mode: FAX
Horizontal Dot
Speed
Density
600
or 1.5 " 600
or 2 " 900/600
or 4 " 480
or 6 " 720
or 8 " 480
or 3 " 400
Default: ON
Default: ON
Default: 3
