MFJ-1278B MULTI-MODE
MFJ P/N Descrpition
TRIMPOTS, BOURNS OR EQUAL
108-6014 10 K, BOURNS 3299W-1-103
108-7005 20 K, BOURNS 3299W-1-203
108-7006 50 K, BOURNS 3299W-1-503
108-7008 25 K, BOURS 3299W-1-253
108-7001 1 K, BOURNS 3299W-1-102
TRIM POT: SINGLE TURN, MINIATURE
104-1103 10 K, Single-turn Trimmer
POT: 17MM SINGLE TURN, PCB MOUNT
104-3104 100 K LINEAR TAPER,
RIGHT ANGLE
CAPACITORS: MULTI-LAYER, MONOLITHIC CERAMIC
205-0010 10 PF, NPO, 10%, 50V
205-0100 100 PF, "
205-0220 220 PF, "
205-0470 470 PF, "
205-1010 .001 UF, "
205-1015 .0015 UF, "
1205-1022 .0022 UF, "
205-1047 .0047 UF, NPO, 10%
205-1147 .047 UF, X7R, 10%
APPENDIX I PARTS LIST
Component ID
R79, R113, R114
R77, R78, R106, R105,
R115, R138, R139, R122
R119
R212
R157, R158, R160
R131
C51
C61
C60, C72
C59
C5
C67
C54
C53, C71
C76, C80, C81, C82, C83
