Product Dimensions

35-7/8" (91.1 cm)
26-1/4" (66.7 cm)
7/8"
(22.2 mm)
2-3/16"
(55.6 mm)
22" (55.9 cm)
side view of cooktop
backguard (shown)
or island trim (see P. 4 and 7)
26-1/4" (66.7 cm)
36" (91.4 cm) long 3-prong
ground-type power supply cord
9"
(22.9 cm)
3/8"
(9.5 mm)
7-1/8"
(18.1 cm)
gas inlet is located 1-7/8" (4.8 cm) from
back of burner box and
4-7/8" (11.7 cm) in from L.H. side of
burner box
1-3/16"
(30.1 mm)
9"
(22.9 cm)
7-1/2"
(19.1 cm)
3
