Electric built-in ceramic cooktops 15" (38.1 cm), 30" (76.2 cm) and 36" (91.4 cm)
Hide thumbs

Advertisement

Product
dimensions
15"
(38.1 cm)
21-5/16"
(54.1 cm)
depth
2-7/8" (7.3 cm)
burner box height

Cutout dimensions/requirements

back edge
rear of cabinet or
of cutout
rear wall under
countertop
KECC051
series only
11/16"
(1.7 cm)
min.
*
Note: 24" (61 cm) min. clearance if bottom
of wood or metal cabinet is protected by
not less than 1/4" (0.6 cm) flame retardant
millboard covered with not less than No.
28 MSG sheet steel, 0.015" (0.04 cm)
stainless steel, or 0.024"(0.06 cm)
aluminum or 0.020" (0.05 cm) copper.
30" (76.2 cm) min. clearance between top
of cooking platform and bottom of
unprotected wood or metal cabinet.
Illustration dimensions
Cooktop width
15"
14-1/2"
(38.1 cm)
(36.6 cm)
30"
29-1/2"
(76.2 cm)
(75 cm)
36"
35-1/2"
(91.4 cm)
(90.2 cm)
21" (53.3 cm)
depth
3/4" (1.9 cm)
both sides
21-5/16"
(54.1 cm)
depth
See NOTE*
for minimum
clearances.
Do not seal
cooktop to
countertop.
15"
1-1/2" max
(38.1 cm)
(3.8 cm)
30"
(76.2 cm)
36"
(91.4 cm)
30" (76.2 cm) or
36" (91.4 cm) width
30" (76.2 cm) or
36" (91.4 cm) width
combustible area
above
countertop
2" min.
(5.1 cm)
Junction box, or
outlet –
12" (30.5 cm) min.
from bottom of countertop.
10" (25.4 cm) from right side
of cabinet.
1" (2.5 cm) min. distance to
nearest left and right side
combustible surface above
Important note on base cabinet construction: After making the
countertop cutout, some installations may require notching down the
base cabinet side walls to clear the burner box. To avoid this
modification, use a base cabinet having sidewalls wider than the cutout.
Note: If cabinet has a drawer, a 3" (7.5 cm) depth clearance from the
countertop to the top of the drawer (or other obstruction) in base
cabinet is required.
2-7/8" (7.3 cm)
burner box
height
3/4" (1.9 cm)
both sides
13" (33 cm)
recommended
upper cabinet
depth
cabinet to countertop
clearances to cooktop
20-1/2"
(52 cm)
cooktop.
2-7/8" (7.3 cm)
burner box
height
18" (45.7 cm) min.
clearance upper
within minimum
3
