Oven Parts - KitchenAid KDRP407HSS0 Parts List

30" kitchenaid free standing range dual fuel
Hide thumbs

Advertisement

Illus.
Part
No.
No.
DESCRIPTION
NOTE: The screws and nuts
required to attach a part are
listed immediately following
that part.
1
Literature Parts
LIT4452762 Installation
Instructions
LIT4452761 Use & Care Guide
LIT4453057 Tech Sheet
LIT4449066 Cookbook Conv.
LIT4453152 Conversion
Instructions
LIT3191638 Safer Cooking Tips
2
4449809 Screw, 8−18 x 3/8
3
4452224 Solenoid
4
4452312 Switch, Micro
5
4451426 Switch, Micro
6
4451537 Spring, Latch
7
4453114 Top, Chassis

OVEN PARTS

For Model: KDRP407HSS0
(Stainless Steel)
Illus.
Part
No.
No.
DESCRIPTION
8
4448520 Bumper, Door
9
4452158 Tube, Vent
10
4452163 Lens, Light
11
4448972 Oven Light Assy
12
4452164 Bulb, Light
13
Hinge Receiver
4454664 Left Hand
4454665 Right Hand
14
4451740 Frame, Front
15
4449372 Gasket, Door
19
4451478 Support, Insulation
24
4451896 Latch Assy
25
Side, Chassis
4452418 Right Hand
4452419 Left Hand
26
4452234 Back, Chassis
27
Liner, Oven
(Not serviceable)
29
4451665 Sensor
30
4449154 Screw, 8−32 x .440
2
Illus.
Part
No.
No.
DESCRIPTION
31
4449040 Screw, 8−18 x 3/8
32
3196176 Screw, 8−18 x 1/2
37
4452223 Thermostat (TOD)
(Temp.) SPST
43
4452435 Base, Chassis
49
4448933 Retainer, Gasket
50
4451747 Cover, Back
56
4448982 Button, Plug
FOLLOWING PARTS
NOT ILLUSTRATED
INSULATION
4449316 Insulation, Wrap
4450365 Insulation, Back
4452337 Insulation,
Bottom Vent
8177425
