Oven Parts - KitchenAid KDRP407HBU10 Parts List

30" free standing range dual fuel
Hide thumbs

Advertisement

Illus.
Part
No.
No.
DESCRIPTION
1
Literature Parts
4455927 Installation
Instructions
4456611 Use & Care Guide
4457148 Tech Sheet
9759441 Conversion
Instructions
9759133 Safer Cooking Tips
2
4449809 Screw, 8−18 x 3/8
3
4452224 Solenoid
4
4452312 Switch, Micro
5
4456568 Switch, Micro
6
4451537 Spring, Latch
7
4455866 Top, Chassis
8
4448520 Bumper, Door
9
4452158 Tube, Vent
10
4452163 Lens, Light
11
4448972 Oven Light Assy
4449748 Screw

OVEN PARTS

For Model: KDRP407HSS10, KDRP407HBU10
(Stainless Steel) (Cobalt Blue)
Illus.
Part
No.
No.
DESCRIPTION
12
4452164 Bulb, Light
13
Hinge Receiver
4455605 Left Hand
4455606 Right Hand
14
4455612 Frame, Front
15
4455382 Gasket, Door
16
4452152 Bracket, Mounting
4449809 Screw
17
4452260 Spacer, Foam
19
4451478 Support, Insulation
21
4455510 Bracket, Support
24
4451896 Latch Assy
25
4455641 Side, Chassis
26
4452234 Back, Chassis
27
Liner, Oven
(Not serviceable)
29
4455636 Sensor
2
Illus.
Part
No.
No.
DESCRIPTION
30
4449154 Screw, 8−32 x .440
31
4449040 Screw, 8−18 x 3/8
32
3196176 Screw, 8−18 x 1/2
37
9759243 Thermostat (TOD)
(Temp.) SPST
43
4455649 Base, Chassis
49
4448933 Retainer, Gasket
50
4451747 Cover, Back
56
4448982 Button, Plug
FOLLOWING PARTS
NOT ILLUSTRATED
INSULATION
4449316 Insulation, Wrap
4450365 Insulation, Back
4452337 Insulation,
Bottom Vent
8186271
