Regency Plateau
Outdoor Decorative Gas Appliances
www.regency-fi re.com
WARNING:
If the information in these instructions
are not followed exactly, a fire
or explosion may result causing
property damage, personal injury or
loss of life.
WARNING:
Improper installation, adjustment,
alteration, service or maintenance
can cause injury or property damage.
Read the installation, operating and
maintenance instructions thoroughly
before installing or servicing this
equipment.
Installation and service must be
performed by a authorised installer,
service agency or the gas supplier,
in accordance with this manual.
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
919-065d
What to do if you smell gas:
•Shut off gas to the appliance.
•Do not try to light any appliance.
•Extinguish any open fl ame.
•If odor continues, keep away from the appliance and im-
•Do not touch any electrical switch: do not use any phone
•Immediately call your gas supplier from a neighbour's
•Follow the gas supplier's instructions.
•If you cannot reach your gas supplier, call the fi re
Do not store or use gasoline or other fl ammable vapours
and liquids in the vicinity of this or any other appliance.
A LP-cylinder not connected for use shall not be
stored in the vicinity of this or any other appliance.
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
Series
®
WARNING: FOR OUTDOOR USE ONLY
WARNING - FOR YOUR SAFETY
mediately call your gas supplier or fi re department.
in your building.
phone.
department.
WARNING:
Owners &
Installation Manual
MODELS: PTO30CFT
PTO30IST
PTO30CKT
LISTINGS AND CODE APPROVALS
These gas appliances have been tested
in accordance with AS4565 / AS4558
and have been certifi ed by the IAMPO
Oceana for installation and operation
as described in these Installation and
Operating Instructions.
Your unit should be serviced annually
by an authorised service person.
10/03/14
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Regency PTO30CFT
Summary of Contents for Regency PTO30CFT
- Page 1 Owners & Installation Manual Regency Plateau Series ® MODELS: PTO30CFT Outdoor Decorative Gas Appliances PTO30IST PTO30CKT LISTINGS AND CODE APPROVALS These gas appliances have been tested in accordance with AS4565 / AS4558 and have been certifi ed by the IAMPO...
- Page 2 To the New Owner: Congratulations! ® You are the owner of a state-of-the-art Outdoor Decorative Gas Appliance by REGENCY . The Plateau Series Outdoor Decorative Gas Appliance has been designed to provide you with all the ® charm of a fi re at the fl ick of a switch. The Plateau ®...
-
Page 3: Table Of Contents
Wiring Diagram ............12 Gas Connection ............13 Conversion from Ng to LPG / uLpg ......14 PTO30cft -Coffee Table leg installation ......16 LP Tank installation - PTO30cft only ......17 LP Tank Installation ............18 PTO30IST/PTO30CKT ONly ........18 LP Tank removal ............18 Switch connection............19 Battery Install ...............19... -
Page 4: Safety Label
DO NO T OPERATE WITH PANELS, COVERS OR GUARDS REMOVED FROM THIS APPLIANCE. DO NO T ENCLOSE THIS APPLIANCE. DO NO T MODIFY THIS APPLIANCE. 908-602a THIS APPLIANCE SHALL NOT BE INSTALLED OR USED INDOORS Regency Plateau™ Series Outdoor Gas Fireplace... -
Page 5: Dimensions
DIMENSIONS UNIT DIMENSIONS - COFFEE TABLE TOP VIEW 3-5/8”(91mm) 38”(965mm) 2-9/16”(64mm) 4.5KG TANK 4.5KG TANK 2-1/16”(52mm) 16-11/16”(423mm) 40-5/8”(1030mm) SIDE VIEW END VIEW Regency Plateau™ Series Outdoor Gas Fireplace... -
Page 6: Unit Dimensions - Island Table
OUTER EDGE 36" (914mm) 1-5/8” (39mm) 6-3/16 ” (156mm) 28-7/8” (733mm) 9KG TANK 9KG TANK 20lb tank 1” 20lb tank (25mm) 40-3/8” 20-11/16” Floor level (1031mm) 3-1/8” (525mm) (79mm) Floor to bottom of LP tank Regency Plateau™ Series Outdoor Gas Fireplace... -
Page 7: Unit Dimensions - Cocktail Table
UNIT DIMENSIONS - COCKTAIL TABLE 62" (1575mm) 14-1/4" (361mm) 12-3/16" (309mm) BURNER GLASS OUTER EDGE OUTER EDGE 36" 914mm TOP VIEW 16 " 16 " 963mm 325mm 8 " 4 " 1248mm 742mm SIDE VIEW END VIEW Regency Plateau™ Series Outdoor Gas Fireplace... -
Page 8: Installation
4) Inspect the burner before each use of the SOLID FUELS SHALL NOT BE BURNED California to cause cancer, birth defects or appliance for blockage and any signs of IN THIS APPLIANCE. other reproductive harm. deterioration. Regency Plateau™ Series Outdoor Gas Fireplace... -
Page 9: Installation Checklist
ARE RAPIDLY DISPERSED BY WIND AND NATURAL CONVECTION. WARNING: DO NOT BUILD FRAME FOR HOUSING CYLINDER UNLESS COMPLI- ANCE TO AS 4565 AND AS/NZS 5601.1 ARE ASSURED. Open side at least 25% of total wall area Regency Plateau™ Series Outdoor Gas Fireplace... -
Page 10: Minimum Clearances To Combustibles
When using supplied leveling legs or optional casters. 1"(25mm) Unit Base to Floor : Floor E: Alcove Width 84"(2134mm) Wall to Wall (Minimum) F: Alcove Depth 60" (1524mm) Front to Back Wall (Maximum) Notes: 0" No Hearth Required Alcove Regency Plateau™ Series Outdoor Gas Fireplace... -
Page 11: High Elevation
Properly locate lines/hoses out of pathways screw (clockwise) with a 1/8" fl at screwdriver. or arches where the hose may be subject to Note: Screw should be snug, but do not over damage. tighten. Regency Plateau™ Series Outdoor Gas Fireplace... -
Page 12: Wiring Diagram
Important: The AA batteries in the battery pack operate the burner switch. If the batteries become weak they will need to be replaced with quality alka- line batteries. This unit will not operate without AA batteries. Regency Plateau™ Series Outdoor Gas Fireplace... -
Page 13: Gas Connection
AS 4617 for manual shut off valves. WARNING: Cylinder must not be stored OR placed in an area that does not comply to AS/NZS 5601.1 The installation and use of approved mechanical isolation valves is required. Regency Plateau™ Series Outdoor Gas Fireplace... -
Page 14: Conversion From Ng To Lpg / Ulpg
3) Slide the burner to the left, away from the pilot assembly and lift out. 6) Re-install pilot cap. 7) Reinstall burner assembly. 8) Adjust aeration accordingly.- see aeration adjustment section manual for details. Burner orifi ce Pilot Cap Regency Plateau™ Series Outdoor Gas Fireplace... - Page 15 Contact local authority if gas leaks persist. HI/LO pressure regulator 12) Attach the label “This unit has been converted to ULPG” near or on top of the serial # decal. 13) Replace yellow “NG” label with red “ULPG” label. Regency Plateau™ Series Outdoor Gas Fireplace...
-
Page 16: Pto30Cft -Coffee Table Leg Installation
INSTALLATION PTO30CFT -COFFEE TABLE LEG INSTALLATION It is required the coffee table unit be used with the legs and decorative 3. Install each leg from the bottom up with supplied bolt, in the same loca- glass surround guard. This is a safety measure to ensure protection. Please tion rubber foot was removed from. -
Page 17: Lp Tank Installation - Pto30Cft Only
INSTALLATION LP TANK INSTALLATION - PTO30CFT ONLY NOTE: Max tank size 11lb or 4.5kg. 1) Remove end panel (opposite end of switch panel),. 2) Remove long side panel (left panel if facing ON/OFF switch end), to ac- cess the 3/8" fi tting to the gas control. -
Page 18: Lp Tank Installation
4) Undo butterfl y bolt to release tank. NOTE: If soap bubbles, this would indicate a gas leak. 5) Refi ll tank and reinstall by reversing steps. Gas connection @ tank Butterfl y bolt Regency Plateau™ Series Outdoor Gas Fireplace... -
Page 19: Switch Connection
1) Remove left side (with switch assembly) end panel from unit. 2) Pull down battery compartment - located below the DFC panel. Battery compartment 2) Connect 2 wires to the switch. 3) Install 4 - AA batteries and reverse steps. 3) Replace panel. Regency Plateau™ Series Outdoor Gas Fireplace... -
Page 20: Table Top Installation - Coffee Table Unit
End Caps 8) To remove - reverse steps 7-5. 3) Replace side panel. 4) Repeat Step 1 and 2 on other side. 5) Place Table Top on Unit. Final Install Regency Plateau™ Series Outdoor Gas Fireplace... -
Page 21: (For Island And Cocktail Units Only)
8) With all tiles installed - install inner frame to fi nish installation. 4) Place the 10 fi ller brackets on the table top as shown - before installing tiles. NOTE: Filler brackets are used to fi ll the gaps between each tile. Regency Plateau™ Series Outdoor Gas Fireplace... -
Page 22: Glass Crystal Installation
Optional Ceramic Spa Stones + Glass Crystals shown on burner. For Units HZ54E, HZ54EPV, HZ42ST, HZ42STE, HZ42STEPV, For Units HZ54E, HZ54EPV, HZ42ST, HZ42STE, HZ42STEPV, HZI234E, HZ42E, HZ42, HZ40E, HZ30E, HZI234E, HZ42, HZ42E, HZ40E, HZ30E only HZO42, HZO42 (AUS) PTO30, PTO60 Plateau Series only Regency Plateau™ Series Outdoor Gas Fireplace... -
Page 23: Optional Volcanic Stones Installation On Burner
Volcanic Stones Ivory /Tan + Glass Crystals For the PTO30 For the HZO42 & HZO42AUS & Plateau ® Series only only Volcanic Stones Slate /Grey + Glass Crystals For the HZO42 & HZO42AUS only Regency Plateau™ Series Outdoor Gas Fireplace... -
Page 24: Glass Surround Installation
Repeat process on other end. Press down fi rmly from to secure glass surround in position. Use care not to scratch surfaces. Regency Plateau™ Series Outdoor Gas Fireplace... -
Page 25: Riser Installation
On the riser, remove panels by grasping bottom and lift backwards, place 4) Remove the 4 adjustable rubber feet form the bottom of the island unit on a soft clean surface. and transfer to the bottom of the riser. Knockouts Regency Plateau™ Series Outdoor Gas Fireplace... - Page 26 5) Install 12 screws in locations shown below to secure island frame to riser base. 5) Reinstall LP tank and reconnect or reconnect NG gas line. Reinstall panels, table top and glass surround and glass crystals to com- plete installation. Regency Plateau™ Series Outdoor Gas Fireplace...
-
Page 27: Plateau ® Table Cover Installations
Never start the unit with the cover on. Let the unit cool before installing the cover. 1) Place the weather cover over the entire table - when not in use. Turn off gas supply to unit before installing cover. Regency Plateau™ Series Outdoor Gas Fireplace... -
Page 28: Operating Instructions
PROCEDURE 5) Check all connection, fi tting, hoses prior to 1) Turn ON/OFF switch. each use. 2) If service is to be performed - you must discon- nect the battery pack. Regency Plateau™ Series Outdoor Gas Fireplace... -
Page 29: Copy Of Lighting Plate Instructions
Appuyez sur le bouton ON / OFF Si le service est effectuée, vous devez débrancher l'appareil, du bloc-piles, voir le manuel d'instruction pour plus de détails. DO NOT REMOVE THIS INSTRUCTION PLATE 918-628b Regency Plateau™ Series Outdoor Gas Fireplace... -
Page 30: Maintenance Instructions
This is not covered under the terms of the warranty policy. 8) Verify operation after servicing. Regency Plateau™ Series Outdoor Gas Fireplace... -
Page 31: Switch Replacement
1) Remove the end panel (side with switch assembly mounted on it) from unit. 2) Remove 2 wire from the switch. 3) Remove 2 screws from switch cover to release switch. 4) Replace switch and reverse steps. Regency Plateau™ Series Outdoor Gas Fireplace... -
Page 32: Valve Assembly Replacement
4) Remove orange EV1 wire connected to the gas valve. 5) Remove green EV2 wire connected to the gas valve. 6) Remove HI/LO extension knob. Hi/Lo Extension ground Flame sensor 7) Remove 10 screws in locations shown below to remove valve tray. Regency Plateau™ Series Outdoor Gas Fireplace... -
Page 33: Digital Fi Replace Control Replacement
1) Remove left side (with switch assembly) end panel from unit. 2) Pull down battery compartment - located below the DFC panel. 3) Remove two screws to swing down DFC box. Battery compartment Battery pack 3) Replace 4 - AA batteries and reverse steps. Regency Plateau™ Series Outdoor Gas Fireplace... -
Page 34: Parts
377-900 Table top frame 911-012 Ignition Board 377-902 Tile set - Slate 326-930 Log Set 377-903 Tile set - Brown 376-522 Island riser 377-080 Inner frame 377-523 Coffee table top 919-065 Manual Not Shown Regency Plateau™ Series Outdoor Gas Fireplace... -
Page 35: Warranty
Reported damage after this time will be subject to rejection. It is the general practice of Regency ® to charge for larger, higher priced replacement parts and issue credit once the replaced component has been returned to Regency and evaluated fro manufacturer defect. - Page 36 Installer: Please complete the following information Dealer Name & Address: ______________________________________________ ___________________________________________________________________ Installer: ___________________________________________________________ Phone #: ___________________________________________________________ Date Installed: ______________________________________________________ Serial No.: __________________________________________________________ Regency is a registered trademarks of FPI Fireplace Products International Ltd. © Copyright 2014, FPI Fireplace Products International Ltd. All rights reserved.
