Zero Clearance Direct Vent Gas Fireplace
STYLE
See Thru
P121E-NG11 Natural Gas P121E-LP11 Propane
Pier
P131E-NG11 Natural Gas P131E-LP11 Propane
WARNING
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in serious
injury, death, or property damage.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
- WHAT TO DO IF YOU SMELL GAS
•
Do not try to light any appliance.
• Do not touch any electrical switch: do not use any phone in your building.
Leave the building immediately.
• Immediately call your gas supplier from a neighbour's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency or the gas supplier.
Tested by:
Certified to/Certifié pour: CSA 2.17-2017
ANSI Z21.88-2017
CSA 2.33-2017
920-016a
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
P121E / P131E
®
MODELS
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
Owners &
Installation Manual
www.regency-fire.com
03.28.19
Advertisement
Table of Contents
Related Manuals for Regency Panorama P121E-NG11
Summary of Contents for Regency Panorama P121E-NG11
- Page 1 Panorama P121E / P131E ® Owners & Zero Clearance Direct Vent Gas Fireplace Installation Manual www.regency-fire.com STYLE MODELS See Thru P121E-NG11 Natural Gas P121E-LP11 Propane Pier P131E-NG11 Natural Gas P131E-LP11 Propane WARNING FIRE OR EXPLOSION HAZARD Failure to follow safety warnings exactly could result in serious injury, death, or property damage.
- Page 2 To the New Owner: Congratulations! You are the owner of a state-of-the-art Gas Fireplace by REGENCY . The P121E/P131E-11 is a hand crafted appliance ® and has been designed to provide you with all the warmth and charm of a wood fireplace at the flick of a switch. The model P121E/P131E-11 has been approved by Intertek for both safety and efficiency. As it also bears our own mark, it promises to provide you with economy, comfort and security for many trouble free years to follow. Please take a moment now to acquaint yourself with these instructions and the many features of your Regency Fireplace. ® IMPORTANT: If the unit is to be installed into a bathroom, optional Neo ceramic glass (Part# 360-946 Front) must be purchased and installed in place of the tempered glass supplied with the unit. Regency P121E-11/P131E-11 Zero Clearance Direct Vent Gas Fireplace ®...
- Page 3 MANUFACTURED MOBILE HOME REQUIREMENTS INFORMATION FOR MOBILE/MANUFACTURED HOMES AFTER FIRST SALE This Regency product has been tested and listed by Intertek as a Direct Vent Wall Furnace to the following standards: VENTED GAS ® FIREPLACE HEATERS CAN/CGA-2.17-2017, and ANSI Z21.88-2017 • CSA 2.33-2017 and GAS-FIRED APPLIANCES FOR USE AT HIGH ALTITUDES CAN/CGA 2.17-2017. This Direct Vent System Appliance must be installed in accordance with the manufacturer's installation instructions and the Manufactured Home Construction and Safety Standard, Title 24 CFR, Part 3280, or the current Standard of Fire Safety Criteria for Manufactured Home Installations, Sites, and Communities ANSI/NFPA 501A, and with CAN/CSA Z240-MH Mobile Home Standard in Canada. This appliance installation must comply with the manufacturer's installation instructions and local codes, if any. In the absence of local codes follow the current National Fuel Gas Code, ANSI Z223.1 and the current National Electrical Code ANSI/NFPA 70 in the U.S.A., and the current CAN/CGA B149 Gas Installation Code and the current Canadian Electrical Code CSA C22.1 in Canada. This Regency mobile/manufactured home listed appliance comes factory equipped with four 1/4" diameter holes located near each corner ® of the base. Fasten the fireplace in place using screw, inserted through the holes. This appliance comes equipped with a dedicated #8 Ground Lug for attachment of the ground wire to the steel chassis as applicable to local codes. See the "Wiring Diagram" section. The appliance, when installed, must be electrically grounded in accordance with local codes or, in the absence of local codes, with the National Electrical Code, ANSI/NFPA 70, or the Canadian Electrical Code, CSA C22.1. This appliance may only be installed in an aftermarket permanently located, manufactured (U.S.A only) or mobile home, where not prohibited by local codes. This appliance can only be used with the type of gas indicated on the rating plate. This appliance is not convertible for use with other cases, unless a certified kit is used. Ensure that structural members are not cut or weakened during installation. This appliance does not have the capability to adjust the fan speed using the supplied remote—even though the remote transmitter allows this function. The appliance fan is controlled by a fan speed controller (rheostat) or on/off switch depending on the model. Regency P121E-11/P131E-11 Zero Clearance Direct Vent Gas Fireplace ®...
-
Page 4: Table Of Contents
Vertical Flue Extension Kit (Part #946-756)..... 34 Warranty ..............58 Ceiling Firestop / Firestop Spacer (Part #946-757) . 34 Conversion from NG to LP........35 On Demand Pilot (seven day safety timer) Important information if using the appliance in CPI (continuous pilot mode) only This appliance is a ProFlame 2 system fitted with the “On Demand” Pilot, a safety feature which will shut down the gas valve completely by extinguishing the pilot light in the event of a continuous full seven days of inactivity. This only applies if the CPI (continuous pilot) switch is in the “on” position in your remote control transmitter. Each time the main burner shuts down, manually or through the call from the thermostat, the seven day timer starts again. The seven day inactivity timer is controlled within the circuit board. Therefore, if in CPI mode and when the pilot light is extinguished after seven straight days of inactivity, the CPI setting on the remote control transmitter will remain in the “CPI” (continuous pilot) position. Therefore, all that is required to relight the pilot would be to press the on/off button on the remote control transmitter from “on” to “off” and back to “on”. Once the pilot has re-established operation will resume as normal. There is no requirement to do anything with the IPI/CPI mode on the remote control transmitter. If the unit never goes as long as seven full days without a call for heat, the pilot will remain lit until it is manually shut-off. If the unit is being operated in IPI (intermittent pilot) mode, neither the above instructions nor the seven day timer will apply. See the instructions in this manual and on the Lighting Instructions plate on the appliance to light or re-light the pilot. Regency P121E-11/P131E-11 Zero Clearance Direct Vent Gas Fireplace ®... -
Page 5: Copy Of Safety Label
This is a copy of the label that accompanies each P121E-11/P131E-11 Zero Clearance Direct Vent Gas Fireplace. We have printed a copy of the contents here for your review. The safety label is located on the front inside base of the unit, visible when the bottom louver is open. NOTE: Regency units are constantly being improved. Check the label on the unit and if there is a difference, the label on the unit is the correct one. ® Copy of Safety Decal for P121E-11/P131E-11 Duplicate S/N Listed: VENTED GAS FIREPLACE HEATER/FOYER AU GAZ À ÉVACUATION DO NOT REMOVE THIS LABEL / NE PAS ENLEVER CETTE ÉTIQUETTE Certified to /Certifi : é... - Page 6 (e) A copy of all installation instructions for all Product Approved side wall horizontally vented gas fueled equipm ent, all venting instructions, all parts lists for venting instructions, and/or all venting design instructions shall remain with the appliance or equipment at the completion of the installation. Regency P121E-11/P131E-11 Zero Clearance Direct Vent Gas Fireplace ®...
-
Page 7: P121E-11 See Thru
P121E-11 See Thru Note: These units are non-load bearing. Regency P121E-11/P131E-11 Zero Clearance Direct Vent Gas Fireplace ®... -
Page 8: P131E-11 Pier
P131E-11 Pier Note: These units are non-load bearing. Regency P121E-11/P131E-11 Zero Clearance Direct Vent Gas Fireplace ®... -
Page 9: Important Message
PRIOR TO OPERATING THE APPLIANCE. WARNING: FAILURE TO INSTALL THIS APPLIANCE CORRECTLY WILL VOID IF THE BARRIER BECOMES DAMAGED, YOUR WARRANTY AND MAY CAUSE A THE BARRIER SHALL BE REPLACED SERIOUS HOUSE FIRE. WITH THE MANUFACTURER'S BARRIER FOR THIS APPLIANCE. Regency P121E-11/P131E-11 Zero Clearance Direct Vent Gas Fireplace ®... -
Page 10: Lighting / Shutdown Procedure
3. After approximately 4 seconds the spark ignition system will spark for 60 seconds to light the main burner. 4. The unit will turn on. * Not offered on all models. Continuous Pilot/Intermittent Pilot (CPI/IPI) selection See remote control instructions for details. On Demand Pilot (seven day safety timer) Important information if using the appliance in CPI (continuous pilot mode) only This appliance is a ProFlame 2 system fitted with the “On Demand” Pilot, a safety feature which will shut down the gas valve completely by extinguishing the pilot light in the event of a continuous full seven days of inactivity. This only applies if the CPI (continuous pilot) switch is in the “on” position in your remote control transmitter. Each time the main burner shuts down, manually or through the call from the thermostat, the seven day timer starts again. The seven day inactivity timer is controlled within the circuit board. Therefore, if in CPI mode and when the pilot light is extinguished after seven straight days of inactivity, the CPI setting on the remote control transmitter will remain in the “CPI” (continuous pilot) position. Therefore, all that is required to relight the pilot would be to press the on/off button on the remote control transmitter from “on” to “off” and back to “on”. Once the pilot has re-established operation will resume as normal. There is no requirement to do anything with the IPI/CPI mode on the remote control transmitter. If the unit never goes as long as seven full days without a call for heat, the pilot will remain lit until it is manually shut-off. If the unit is being operated in IPI (intermittent pilot) mode, neither the above instructions nor the seven day timer will apply. See the instructions in this manual and on the Lighting Instructions plate on the appliance to light or re-light the pilot. Regency P121E-11/P131E-11 Zero Clearance Direct Vent Gas Fireplace ®... -
Page 11: Copy Of The Lighting Plate Instructions
919-649 Part #: 919-649 Colours: Black on Grey, except for parts indicated as being Red. Punch out .25" hole top right corner where indicated. Size: 100% w- 6.52" Regency P121E-11/P131E-11 Zero Clearance Direct Vent Gas Fireplace ® h- 11.13" Apr 05/16: Created decal Apr. 26/16: Added Fr. Headers/warnings... -
Page 12: Proflame Ii Remote Control Operating Instructions
(*) The receiver may be independent or integral to the IFC hearth ap- pliance control module. The receiver instruction may not be indepen- dent when part of the IFC. Figure 2: Transmitter LCD Display Fig3: Battery Figure 3: Battery Compartment compartment. Regency P121E-11/P131E-11 Zero Clearance Direct Vent Gas Fireplace ® 919-829 09.29.17... - Page 13 Transmitter LCD display will only show the room temperature (Fig. 6). At the same time the Receiver will turn off the appliance. A single “beep” from the Receiver confi rms reception of the command. Figure 9 Figure 10 Regency P121E-11/P131E-11 Zero Clearance Direct Vent Gas Fireplace ® 919-829 09.29.17...
- Page 14 (fi g.1) to index to the fan control icon (Fig. 13). Use the Up/Down Arrow Keys (fi g.1) to turn on, off or adjust the fan speed (fi g. 14). A single “beep” will confi rm reception of the command. Figure 17 Figure 18 Figure 13 Figure 14 Regency P121E-11/P131E-11 Zero Clearance Direct Vent Gas Fireplace ® 09.29.17 919-829...
- Page 15 3. Reinstall the 3rd battery while still holding both buttons (keep holding buttons once 3rd battery is installed, then release the mode button only. 4. The screen will show either "Clr" or "Set" with the 1st mode being your option to disable or enable. Regency P121E-11/P131E-11 Zero Clearance Direct Vent Gas Fireplace ® 919-829...
-
Page 16: General Safety Information
State of California to cause cancer, birth defects or CAUTION: Any alteration to the product that other reproductive harm. causes sooting or carboning that results in damage is not the responsibility of the manufacturer. Regency P121E-11/P131E-11 Zero Clearance Direct Vent Gas Fireplace ®... -
Page 17: Installation
Model # Position P121E-11: See Thru P131E-11: Pier 5) This appliance is Listed for bedroom installations when used with a Listed Millivolt Thermostat. Some areas may have further requirements, check local codes before installation. 6) The P121E-11/P131E-11 Direct Vent Gas Fireplace is approved for alcove installations, which meet the clearances listed on this page. 7) We recommend that you plan your installation on paper using exact measurements for clearances and floor protection before actually installing this appliance. Have a qualified inspector, dealer, or installer review your plans before installation. Note: For Exterior Vent Termination Locations see section "Exterior Vent Termination Locations." Regency P121E-11/P131E-11 Zero Clearance Direct Vent Gas Fireplace ®... -
Page 18: Clearances
This drawing is to scale at 1:6 (one inch = 6 inches) Mantel can be installed anywhere in shaded area or higher using this scale. Caution: Ensure the paint that is used on the mantel and the facing is "heat resistant" or the paint may discolour. * If the 3" (76mm) metal extension trim is removed it must be replaced with a 8" (203mm) non- combustible material. Regency P121E-11/P131E-11 Zero Clearance Direct Vent Gas Fireplace ®... -
Page 19: Framing And Finishing
B 42-1/2"(1080mm) B 42-1/2"(1080mm) C 46-3/4"(1187mm) C 45" (1143mm) m inus 1X the finishing material thickness* * Finish material thickness includes: drywall, ceramic tile, slate, etc. P121 only: The appliance extends 2-3/4" inches further on the vent side. If trying to center the appliance in a room add 2-3/4" to the non vent side when framing. Do not however change dimension (C) as the opening remains the same. P131E-11 - Pier Note: These units are non-load bearing. Regency P121E-11/P131E-11 Zero Clearance Direct Vent Gas Fireplace ®... -
Page 20: Facing & Finishing Requirements
2) Take each standoff and bend into the correct shape. Bend up at the bend lines until the screw holes in the standoff and the pre-punched The gas appliance and vent system must be screw holes on the fireplace top line up. vented directly to the outside of the building, and never be attached to a chimney serving a 3) Attach the standoff securely to the top with separate solid fuel or gas burning appliance. 4 screws per standoff (on opposite corners). Each direct vent gas appliance must use it's own separate vent system. Common vent systems are prohibited. (See "Rigid Pipe Venting Systems" for more details and exceptions). Regency P121E-11/P131E-11 Zero Clearance Direct Vent Gas Fireplace ®... -
Page 21: Exterior Vent Terminal Locations
Clearance to each side of center line extended above meter/regulator assembly 36"(90cm) Clearance to service regulator vent outlet 36"(90cm) Clearance to non-mechanical air supply inlet to building or the combustion air inlet to any other appliance 12"(30cm) 9" (23cm) Clearance to a mechanical air supply inlet 72"(1.8m) 36"(90cm) #3' (91cm) above if within 10' (3m) horizontally. ┼ Clearance above paved sidewalk or a paved driveway located on public property 84"(2.1m) Clearance under veranda, porch, deck, or balcony 12"(30cm) ‡ In accordance with current CSA B149.1, Natural Gas and Propane Installation Code In accordance with the current ANSI Z223.1/NFPA 54, National Fuel Gas Code A vent shall not terminate directly above a sidewalk or paved driveway which is located between two single family dwellings and serves both dwellings ┼ ‡ Permitted only if veranda, porch, deck, or balcony is fully open on a minimum of two sides beneath the floor * Clearance in accordance with local installation codes and the requirements of the gas supplier 3 feet (91cm) within a height of 15 feet (4.5m) above the meter / regulator assembly 3 feet (91cm) above - if within 10 feet (3m) horizontally Regency P121E-11/P131E-11 Zero Clearance Direct Vent Gas Fireplace ®... -
Page 22: 4" X 6-5/8" Rigid Pipe Cross Reference Chart
” RIGID PIPE CROSS REFERENCE CHART Components from different Manufacturers may not be mixed. Not All Rigid Pipe components are available directly from FPI. Components from different Manufacturers may not be mixed. Not all rigid pipe components are available directly from Regency. Note: The listed manufacturers may have other lengths not shown on this chart, which would also be approved. - Page 23 Note: Horizontal runs of vent must be level, or have a 1/4” rise for every 1 foot of run towards the termination. Never allow the vent to run downward - this could cause high temperatures and may present a possible fi re hazard. Regency P121E-11/P131E-11 Zero Clearance Direct Vent Gas Fireplace...
-
Page 24: Venting Arrangement - Horizontal Terminations
Flue pipe Notes: 1) Liner sections should be continuous without any joints or seams. 2) Only Flex pipe purchased from Regency may be used for Flex installations. ® Regency Direct Vent System (Flex) is only approved for horizontal terminations. -
Page 25: Rigid Pipe Venting Systems Horizontal Or Vertical Terminations
Vent systems. Use of these systems with the Rigid Pipe adaptor is deemed acceptable and does not affect the Intertek WHI listing of components. When using Rigid Vent other than Simpson Dura-Vent, 3 screws must be used to secure rigid pipe to adaptor. The FPI AstroCap and FPI Riser Vent terminal are certified for installations using FPI venting systems as well as Simpson Dura-Vent Direct Vent, Ameri- ® can Metal Products Ameri Vent Direct Vent, Security Secure Vent , Selkirk Direct-Temp. AstroCap is a proprietary trademark of FPI Fireplace Products ® International Ltd. Dura-Vent® and Direct Vent are registered and/or proprietary trademarks of Simpson Dura-Vent Co. Inc. Regency P121E-11/P131E-11 Zero Clearance Direct Vent Gas Fireplace ®... -
Page 26: Rigid Pipe Venting Arrangements Horizontal Terminations
Rigid Pipe Venting Arrangements Horizontal Terminations REGENCY DIRECT VENT SYSTEM (FLEX) (Propane & Natural Gas) The diagram below shows examples of horizontal termination arrangements using one, two, or three 90 elbows (two 45 elbows equal one 90 elbow). Note: 1) A maximum of three 90 elbows are permitted. 2) Minimum distance between elbows is 1 ft. (305mm). All Rigid Pipe Systems 4"... - Page 27 C) 3' (914mm) Min. 5' (1.52m) Max. 9' (2.74m) Max. D) 5' (1.52m) Min. 8' (2.44m) Max. 12' (3.66m) Max. With the above options, maximum total pipe length if 37 feet with minimum of 5 feet total vertical and maximum 12 feet total horizontal. Please note minimum 1 foot between 90 elbows is required. Diagram 4 Diagram 6 Regency P121E-11/P131E-11 Zero Clearance Direct Vent Gas Fireplace ®...
-
Page 28: Rigid Pipe Venting Arrangements - Vertical Terminations
Please note minimum 1 foot between 90 elbows is required. 45° Elbow Rigid Pipe Adapter Part # 510-994 Diagram 7 Diagram 8 IMPORTANT When installing this unit vertically, the 45 elbow when installed in conjunction with the Rigid Pipe Adaptor will protrude past the unit 1-1/2" (38mm) when measured from the rear standoffs. Note: A 1-1/4" (32mm) clearance from the elbow must also be maintained. Regency P121E-11/P131E-11 Zero Clearance Direct Vent Gas Fireplace ®... - Page 29 2' (610mm) Min. 1' (305mm) Max. 2' (610mm) Max. 3' (914mm) Min. 4' (1.22m) Max. 5' (1.5m) Max. 4' (1.22mm) Min. 6' (1.86m) Max. 8' (2.4m) Max. 5' (1.5m) Min. 8' (2.4m) Max. 12' (3.6m) Max. With the above options, maximum total pipe length if 37 feet with minimum of 5 feet total vertical and maximum 12 feet total horizontal. Please note minimum 1 foot between 90 elbows is required. Diagram 11 Regency P121E-11/P131E-11 Zero Clearance Direct Vent Gas Fireplace ®...
-
Page 30: Horizontal Terminations
8) Slide the appliance and vent assembly towards one-quarter turn, until the two sections are the wall carefully inserting the vent pipe into the fully locked. The female locking lugs will not vent cap assembly. It is important that the vent be visible from the outside, on the Black pipe extends into the vent cap sufficient distance Pipe or fittings. They may be located by so as to result in a minimum pipe overlap of examining the inside of the female ends. 1-1/4 inches. Secure the connection between Regency P121E-11/P131E-11 Zero Clearance Direct Vent Gas Fireplace ®... -
Page 31: Vertical Terminations
Diagram 4 over 8/12 to 9/12 0.61 relié à l’attache over 9/12 to 10/12 0.76 murale Attache over 10/12 to 11/12 3.25 0.99 murale walstrpf.eps over 11/12 to 12/12 1.22 Coudes de 45 french over 12/12 to 14/12 1.52 over 14/12 to 16/12 1.83 over 16/12 to 18/12 2.13 Diagram 3 Espaceur over 18/12 to 20/12 2.29 coupe-feu Diagram 5 over 20/12 to 21/12 2.44 Regency P121E-11/P131E-11 Zero Clearance Direct Vent Gas Fireplace ®... -
Page 32: Installation Procedures
When using snow blowers, make sure snow is not directed towards vent 4) Separate the 2 halves of the wall thimble and termination area. securely fasten the one with the tabs to the outside wall making sure that the tabs are on top and bottom. Fasten the other thimble Installation Procedures for Regency AstroCap Direct ® 2” x 4” or 2” x 6” Vent System (Flex) Termination 1) Locate the unit in the framing, rough in the 4" (102mm) dia. flue pipe gas. Locate the centerline of the termination... -
Page 33: Vertical Termination - 4"X6-7/8" Venting (Part#946-755)
10. Attach the rigid pipe section to the adaptor by using Mill-Pac on the inner/ Note: Any closets or storage spaces which the vent passes through must outer pipe. Use 3 screws to secure outer pipe. be enclosed. Regency P121E-11/P131E-11 Zero Clearance Direct Vent Gas Fireplace ® 919-695... -
Page 34: Vertical Flue Extension Kit (Part #946-756)
Note: The ceiling firestop/firestop spacer may be cut down to size if this shield Ceiling firestop is too high for the application. Firestop spacer to prevent debris from falling into the ceiling Diagram 1 Roof support firestop Ceiling firestop Enclosure Ceiling firestop Diagram 1a Regency P121E-11/P131E-11 Zero Clearance Direct Vent Gas Fireplace 919-696 ® 08.10.16 919-698 06.12.18... -
Page 35: Conversion From Ng To Lp
Diagram 1 and 2: Remove the left and right screws and then slide the burner assembly 16. Check for gas leaks. away from the orifice and lift out. 17. Check inlet and outlet pressures. 18. Check operation of flame control. Aeration should be set to a minimum of 3/8" propane. 19. Check for proper flame appearance and Burner Orifice Diagram 5 glow on logs. Regency P121E-11/P131E-11 Zero Clearance Direct Vent Gas Fireplace ® 03/07/19 920-079... -
Page 36: System Data
Supply Pressure min.5.0" w.c. tighten the screw (clockwise) with a 1/8" flat screwdriver. Note: Screw should be snug, Manifold Pressure but do not over tighten. (High) 3.5" w.c. Log Set: Ceramic fibre, 8 per set. Vent System: Regency Astrocap , Regency ® ® Direct Vent System (Flex) and Simpson Dura- Vent Direct Vent System 885 S.I.T. Valve Description P121E/P131E-LP11 System Data ote: If you have an incorrect flame pattern,... -
Page 37: Wall Mount On/Off Switch And Battery Holder Installation
Battery Holder Installation 1. Install the low voltage junction box to the framing, at desired location within 15 ft. from fireplace. 2. F eed the 6 pin connector through the opening at back of junction box. 3. Connect the 6 pin connector to the back of the Battery Holder. 4. Install the Battery Holder in the Low Voltage Junction box. 5. I nstall batteries only if 120 volt power will not be used. Batteries are only used if power is lost within the home and serve as a secondary power source. Insert the 4 AA type batteries in the battery compartment with the correct polarity. 6. Place the slider into the cover plate. 7. Put the Battery Holder switch in the “OFF” position, to allow correct lineup for slider switch. 8. Make sure the Battery Holder and cover plate words “ON” and “UP” are on the same side. 9. Align the slider with the switch on the Battery Holder and couple the switch into the slider. 10. Align the screw holes. 11. Using the two (2) screws provided secure the cover plate to the Battery Holder. 12. For coding instructions, see full details in this manual. Low Voltage Junction Box Proflame Battery Holder J-Box Battery Holder Slider Switch Wall Plate Diagram 1 Regency P121E-11/P131E-11 Zero Clearance Direct Vent Gas Fireplace ®... -
Page 38: Log Set Installation
Avoid stacking platinum embers. IMPORTANT When placing Embers, do not block burner ports as this can cause an incorrect fl ame pattern, Tab on Burner Grate Post carbon deposits and delayed ignition. Page 1 of 2 01/03/08 918-111c Regency P121E-11/P131E-11 Zero Clearance Direct Vent Gas Fireplace ®... - Page 39 Ensure that the log fi ts into a pin that is Repeat step 6 on the opposite side of the burner. on Log 326. Grate Post Completed Log Set Installation: Repeat step 5 on the opposite side of the burner. 01/03/08 918-111c Page 2 of 2 Regency P121E-11/P131E-11 Zero Clearance Direct Vent Gas Fireplace ®...
-
Page 40: Safety Screen Removal
Safety Screen Removal 1. Remove upper and lower louvers if installed. 5. Loosen the 2 screws as shown in locations shown in Diagram 4. 2. Loosen 2 screws in locations shown in Diagram 1. Diagram 4 Diagram 1 6. Pull the bottom bracket down and outward to remove. 3. Lift top bracket up and outward to remove as shown in Diagram 2. Diagram 5 Diagram 2 4. Remove safety screen by lifting up and out. 7. To install–reverse steps. Diagram 3 Regency P121E-11/P131E-11 Zero Clearance Direct Vent Gas Fireplace ®... -
Page 41: Glass Door Removal
4) Attach the screws provided to the top and Slide Trim into bottom, left and right corners similar to slot. step 1. 5) Hang the top and bottom louver or grill onto the screws in the top and bottom, left and right sides of the fireplace opening. Push trim tight The Top and Bottom Side Louver or Grill is against magnet. installed the same way. Regency P121E-11/P131E-11 Zero Clearance Direct Vent Gas Fireplace ®... -
Page 42: Wall Thermostat (Optional)
Use the table below to determine the maximum wire length. Note:120 volt power must be brought to this recep- tacle by a qualified electrician. Note: Preferable if the thermostat is installed on an interior wall. Regency offers an optional programmable thermostat but any 250-750 millivolt rated non- anticipator type thermostat that is CSA, ULC or UL approved may be used. CAUTION Do not connect millivolt wall thermostat wires Metal receptacle to 120V wire. -
Page 43: Wiring Diagram Without Thermostat
Do not cut or remove the grounding prong from this plug. White FAN 1 FAN 2 Black EXTERNAL ANTENNA Regency P121E-11/P131E-11 Zero Clearance Direct Vent Gas Fireplace ®... -
Page 44: Optional Wall Thermostat
Connect the wires as per the wiring diagrams. to the 120V wires. Note: Preferable if the thermostat is installed on an interior wall. Regency ® offers an optional programmable thermostat but any 250-750 millivolt rated non- anticipator type thermostat that is CSA, ULC or UL approved may be used. -
Page 45: Operating Instructions
This appliance ships with a full function remote control as standard equipment. This allows for basic on/off function as well as the ability to operate as a thermostat. With the addition of an optional wall cradle (820-477-AWT) available from an autho- rized dealer, the remote can reside on a wall and carry out all the functions of a typical millivolt wall thermostat as well as being able to control the fan speed, accent light and the flame height. This is the recommended procedure for operating the unit with a thermostatic set point. If a millivolt wall thermostat is required for bedroom installation or as preferred method of controlling the stove. See noted option. Wall thermostat and remote. Set the wall thermo- stat to the desired set point, then place the remote transmitter in either SMART or thermostatic mode with a set point 5 degrees above the set point on the wall thermostat. The burner will fire until the set point on the wall thermostat is satisfied. The remote will remain connected and allow full control of all accessories. Regency P121E-11/P131E-11 Zero Clearance Direct Vent Gas Fireplace ®... -
Page 46: Battery Backup
Battery Backup To operate the stove during a power outage or when power is not available see the following steps. 2 Phillips head screws Diagram 1 Battery door removed 1. Remove 2 Phillips head screws to remove cover plate. Place screws to the side. Cover plate not exactly as shown. Diagram 3 See diagram 1. Battery compartment tabs Battery compartment door Diagram 4 Diagram 2 3. Install 4 AA batteries ensuring they are polarity correct. See diagram 4. 2. Press down on both tabs to remove battery compartment door. See diagrams 2 and 3. 4. Reverse steps 3-1. Regency P121E-11/P131E-11 Zero Clearance Direct Vent Gas Fireplace ®... -
Page 47: Maintenance
Gas Control Valve: TEMPERATURE AND SHOULD STAY As the gas control valve turns ON and OFF, a dull clicking sound may be audible, this is normal opera- AWAY TO AVOID BURNS OR CLOTH- ote: If you have an incorrect flame pattern, tion of a gas regulator or valve. contact your Regency dealer for further ® ING IGNITION. YOUNG CHILDREN instructions. SHOULD BE CAREFULLY SUPER- Unit Body/Firebox:... -
Page 48: Aeration Adjustment
Adjustment Wire - Push to close or pull to open aeration cap. Closed - Tall yellow Open - Short Blue Note: Aeration Adjustment should only be performed by an authorized Regency Installer at the time of ® installation or service. Regency P121E-11/P131E-11 Zero Clearance Direct Vent Gas Fireplace... -
Page 49: Maintenance Instructions
Note: Never operate the appliance without tadpole glass gasket (Part # 936-155). the glass properly secured in place. Door Glass 6) Do not use this appliance if any part has been under water. Immediately call a qualified service Your Regency ® fireplace is supplied with high technician to inspect the appliance and to replace temperature 5mm tempered glass & 5mm any part of the control system and any gas control ceramic glass. If your glass requires cleaning, which has been under water. -
Page 50: Removal Of Valve Assembly
The brick panels are fragile, handle with care. 4. Once the trim pieces have been removed the glass door will still be held in place by two (2) Phillips head screws once on each side of the door. 920-081 03.07.19 Regency P121E-11/P131E-11 Zero Clearance Direct Vent Gas Fireplace ®... - Page 51 X6 and the spark electrode wire from X2 as well as the flame sensor wire from terminal X 3. 9. To remove the valve assembly from the unit, remove 16 Phillips head screws securing the valve tray to the unit. 03.07.19 920-081 Regency P121E-11/P131E-11 Zero Clearance Direct Vent Gas Fireplace ®...
- Page 52 5. Lastly, remove supply tube from valve with 19mm (3/4”) wrench. 2. Once the valve has been removed from the mounting bracket, discon- nect the pilot nut with 11mm (7/16”) wrench. 6. Reverse the steps to assemble the valve. 920-081 03.07.19 Regency P121E-11/P131E-11 Zero Clearance Direct Vent Gas Fireplace ®...
-
Page 53: Installing Valve
Fan Replacement 1) Shut off power by disconnecting 3 prong plug at receptacle inside of the appliance. 2) Remove top louvers. 3) Unplug power wires. 4) Remove 4 screws securing fan to mounting bracket. 5) Remove 2 connector wires. Connector wires 6) Replace fan. 7) Repeat for opposite side/corner. 8) Reverse steps 1 - 5 for installation. Regency P121E-11/P131E-11 Zero Clearance Direct Vent Gas Fireplace ®... -
Page 54: P121E-11 (See Thru) Main Assembly
360-069 Heat Shield - Side (Optional) 146. 360-033 Left Side Door Trim 204. 360-940 Dec. Grill Front - Black (set) 360-529 Door Assy Side - Tempered 360-034 Right Side Door Trim 363-000 Safety Screen (Each) 150. 360-123 Magnet Bracket - Front 205. 948-223 Regency Logo Plate ® 6. 363-002 Horizontal bracket (Each) 151. 904-258 Magnet 206. 910-171 Fan Axial 115V 363-004 Vertical Bracket (Each) 360-148F Blower Screen 360-046 Nailing Strip - Top - Front 168. 360-068... -
Page 55: P131E-11 (Pier) Main Assembly
206. 910-171 Fan Axial 115V 148. 360-035 Finishing Trim 363-001 Safety Screen 360-148F Blower Screen 149. 360-122 Magnet Bracket - Corner 363-003 Horizontal Bracket (Each) 150. 360-123 Magnet Bracket - Front 948-223 Regency Logo Plate ® 151. 904-258 Magnet 360-046 Nailing Strip - Top - Front 360-047 Nailing Strip - Top - Side 920-016 Manual 430-001 Standoff - Top *Not available as a replacement part. **Not Shown 5 5 5 Regency P121E-11/P131E-11 Zero Clearance Direct Vent Gas Fireplace... -
Page 56: Burner Assembly & Log Set
911-039 2 way pilot hood 911-037 Flame Sensor 911-038 Spark Electrode 911-187 Remote Battery Box 911-127 Remote battery compartment door 911-175 GTMF Remote control Hand held W840470 Pilot assembly gasket 911-192 120 Volt Power Cord 911-266/P IFC Proflame Control Module 911-257 Fan 2 Pin Wire Harness 911-287 Fan Wire - Black 911-288 Fan Wire - White 911-173 Valve Wiring Harness 911-181 Battery Box Wiring Harness 911-193 Connector with Jumper Wire 363-154 IFC Metal Cover - Base 363-155 IFC Metal Cover - Top 911-210 External Antenna IFC *Not available as a replacement part. Regency P121E-11/P131E-11 Zero Clearance Direct Vent Gas Fireplace ®... - Page 57 Regency P121E-11/P131E-11 Zero Clearance Direct Vent Gas Fireplace ®...
-
Page 58: Warranty Warranty
FPI is not responsible for results or costs of workmanship of unauthorized FPI dealers or agents in the negligence of their service work. Revision Date: February 2019 Regency Gas Products Warranty Regency P121E-11/P131E-11 Zero Clearance Direct Vent Gas Fireplace... - Page 59 Freight damages for products or parts are not covered under the terms of the warranty. Products made or provided by other manufacturers and used in conjunction with the FPI appliance without prior authorization from FPI may void this warranty. Revision Date: February 2019 Regency Gas Products Warranty Regency P121E-11/P131E-11 Zero Clearance Direct Vent Gas Fireplace ®...
- Page 60 Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form at http://www.regency-fire.com/Customer-Care/Warranty-Registration.aspx...
- Page 61 Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form found on our Web Site under Customer Care within ninety (90) days of purchase.
