i!lllIi!!!:!!ilii!!!i]i!
i i ii!il!!!!i!Ii!i iiiii!t!iiii !!!! iii 11i!i!i!ii!l!iiilll
t
NOTE: This unit can use a Speed Start
TM
Accessory!
Please refer to the Speed Start
TM
accessory operator's manual
for the proper use of this feature. (Items Sold Separately! Refer
to the Speed Start
TM
Accessory section of this manual for more
information about these Speed Start
TM
accessories.)
STARTING iNSTRUCTiONS
1. Mix gasoline with oil. Refer to Off and Fuel Mixing instructions.
2. Fill the fuel tank. Refer to Fueling the Unit.
NOTE: There is no need to turn the unit on. The On/Off switch is in
the ON (I) position at all times (Fig. 9).
3. Slowly press and release the primer bulb 10 times (Fig. 10). If
fuel cannot be seen in the primer bulb, press and release the
primer bulb until fuel is visible.
4. Flip the choke lever clockwise until it clicks (Fig. 11).
5. Crouch in the starting position (Fig. 12).
6. DO NOT squeeze the throttle control (Fig. 9). Insert the Speed
Start
TM
accessory into the Speed Start
TM
port (Fig. 22). Refer to
the Operation section of the Speed Start
TM
accessory operator's
manual.
7. DO NOT squeeze the throttle control. Run the Speed Start
TM
accessory in intervals no longer than 2 seconds each until the
unit starts.
8. Idle the engine for 5 to 10 seconds. If the unit stops during this
time, squeeze and hold the throttle control and throttle lock-out.
Then run the Speed Start
TM
accessory in intervals no longer than
2 seconds each until the unit starts.
9. Remove the Speed Start
TM
accessory from the unit.
10. Squeeze and hold the throttle control and throttle lock-out. Allow
the engine to warm up for 30 to 60 seconds.
NOTE: The engine is properly warmed up when it accelerates
without hesitation.
IF... the engine does not start, begin the starting procedure with
step 3.
IF... the unit is hot and fails to start within 3 pulls of the starter rope,
squeeze and hold the throttle control and throttle lock-out. Then
run the Speed Start
TM
accessory in intervals no longer than 2
seconds each until the unit starts.
STOPPING
iNSTRUCTiONS
1. Release the throttle control and allow the engine to idle.
2. Press and hold the On/Off switch in the OFF (O) position until
the engine comes to a complete stop (Fig. 9).
11
