Owner's Manual
SHOP FOX
Product Dimensions
Weight........................................................................................................... 89 lbs.
Width (side-to-side) x Depth (front-to-back) x Height.................................... 34 x 8-3/4 x 15 in.
Footprint (Length x Width).......................................................................... 33 x 8-3/4 in.
Shipping Dimensions
Type.................................................................................................... Cardboard Box
Content........................................................................................................ Machine
Weight.......................................................................................................... 103 lbs.
Length x Width x Height........................................................................... 38 x 12 x 16 in.
Electrical
Power Requirement.................................................................... 110V, Single-Phase, 60 Hz
Prewired Voltage................................................................................................. 110V
Full-Load Current Rating........................................................................................... 6A
Minimum Circuit Size............................................................................................. 15A
Connection Type......................................................................................... Cord & Plug
Power Cord Included.............................................................................................. Yes
Power Cord Length............................................................................................... 8 ft.
Power Cord Gauge............................................................................................ 18 AWG
Plug Included....................................................................................................... Yes
Included Plug Type............................................................................................... 5-15
Switch Type............................................................ Paddle Safety Switch w/Removable Key
Motors
Main
Type......................................................................... TEFC Capacitor-Start Induction
Horsepower.............................................................................................. 1/2 HP
Phase.............................................................................................. Single-Phase
Amps........................................................................................................... 6A
Speed.................................................................................................. 1725 RPM
Power Transfer ..................................................................................... Belt Drive
Bearings............................................................... Shielded & Permanently Lubricated
Main Specifications
Operation Information
Swing Over Bed........................................................................................... 10 in.
Dist Between Centers.................................................................................... 15 in.
Swing Over Tool Rest................................................................................ 7-1/2 in.
No of Spindle Speeds.......................................................................................... 6
Spindle Speed Range......................................................................... 480 – 4023 RPM
Floor to Center Height............................................................................ 13-5/32 in.
MODEL W1752
SHOP FOX MINI WOOD LATHE
®
Model W1752 Machine Specifications, Page 1 of 2
Advertisement
Table of Contents
Related Manuals for Woodstock SHOP FOX W1752
Summary of Contents for Woodstock SHOP FOX W1752
- Page 1 MODEL W1752 SHOP FOX SHOP FOX MINI WOOD LATHE ® Product Dimensions Weight......................89 lbs. Width (side-to-side) x Depth (front-to-back) x Height........34 x 8-3/4 x 15 in. Footprint (Length x Width)................33 x 8-3/4 in. Shipping Dimensions Type....................Cardboard Box Content......................
- Page 2 Spindle Information Spindle Taper....................MT#2 Spindle Thread Size.................. 1-7/8 in. Spindle TPI....................8 TPI Spindle Thread Direction................. Right Hand Spindle Bore..................2-3/64 in. Type of Included Spindle Center................ Spur Tailstock Information Tailstock Taper................... MT#2 Type of Included Tailstock Center..............Live Construction Bed................
