Introduction

ImageStation Z is a softcopy production system that allows the user to view and process color imagery.
It features a D-sized digitizing surface and (using specially-designed glasses) stereoscopic viewing.
ImageStation Z is based on an Intergraph TDZ workstation, and includes furniture and other equipment
to comprise the complete system. It also includes separate documentation to guide you in setting up the
Intergraph TDZ workstation and assembling the KI workstation furniture.
This document describes how to install the hardware and software for an Intergraph ImageStation Z
system, and how to adjust and troubleshoot an ImageStation Z installation. It also contains a brief
description of image compression and decompression operations.
WARNING Only Intergraph field service personnel may perform the installation procedures in this
document.
CAUTION To successfully install the equipment, read all of the instructions carefully before proceeding with the
installation.
The following figure shows the components of an ImageStation Z system.
PEM Bracket
D-sized
Digitizer
Table
Top
Two-Handed
Controller
NOTE Cyborg chair, Interface PEM, AC Adapter, handle grommet, and stereoscopic glasses are not shown.
Keyboard
Height
Adjustment
Handle and
Grommet
Digitizer
Stand
Infrared
Transmitter
Monitor
Monitor Table
TDZ
Workstation
Base Unit
1
