14
Client systems must have a high-speed SAN connection (such as the Fibre Channel
connections to the hub and the disk arrays).
The shared volumes must be formatted using the NT File System (NTFS).
If there is a UNIX computer on the SAN, the server system must be running NFS server
software such as Intergraph's DiskShare.
For more detailed information on system requirements and software configuration rules, refer to
the SANergy documents delivered with the Shared Storage system.

Installing Host Bus Adapter Driver Software

You must install the QLogic host bus adapter (HBA) driver software on each client system with an
installed HBA. The product name for the QLogic HBA driver software is
To install the QLogic HBA driver software:
1. From the operating system Start menu, go to Settings/Control Panel/SCSI Adapters/Drivers.
2. In the Drivers tab, click Add.
3. In the Install Driver dialog, click Have Disk.
4. Insert the diskette containing the
5. In the Install From dialog, verify that A:\ displays in the field, and then click OK.
6. In the Install Driver dialog, click OK to install the QLogic driver.
7. When you are prompted to restart the system, click Yes.

Installing, Configuring, and Using SANergy Software

You must first configure the server system (also known as the meta-data controller, or MDC) and
install SANergy software on it. You can configure one system as the server system, or configure
several server systems to spread the MDC tasks among systems.
After you configure the server system(s), you must install SANergy software on each of the client
systems in your Shared Storage system. You must also copy the disk configuration from the server
system(s) to the client systems,
The SANergy documentation delivered with the Shared Storage system contains detailed software
installation and configuration instructions. See the SANergy documentation for instructions on
installing, configuring, and using SANergy software.
driver in the system's floppy disk drive.
QLOGICFCDRV
.
QLOGICFCDRV
