The following figure shows a typical connection of a client system to a Fibre Channel RAID array
via the Fibre Channel hub.
Copper Cable
(HSSDC to HSSDC)
Fiber Optic HBA Installed
in Client System
Fiber Optic Cable
Fiber Optic GBIC Port Installed
in Fibre Channel Hub
Copper GBIC Port
Installed in Hub
HSSDC Ports on
Fibre Channel RAID Array
11
