10
Typical Hardware Connections
The following figure shows a typical connection of a client system to a Fibre Channel disk array
via the Fibre Channel hub.
Copper Cable
(HSSDC to DB-9)
I/O Module on Fibre
Channel Disk Array
Fiber Optic HBA Installed
in Client System
Fiber Optic Cable
Fiber Optic GBIC Port Installed
in Fibre Channel Hub
Copper GBIC Port
Installed in Hub
