ExtremeZ SAN
In Intergraph Computer Systems' ExtremeZ SAN system, user systems (clients) connect to
Fibre Channel disk arrays by way of a Fibre Channel hub and gigabit interconnect (GBIC)
ports. This hardware configuration provides a higher performance level than is possible on a
standard LAN. Client systems communicate with the shared storage devices at Fibre Channel
speeds. The following figure shows a typical ExtremeZ SAN configuration.
Local Area Network
Clients and Server
Optical GBIC Connections
Fibre Channel Hub
Copper GBIC Connections
Fibre Channel Disk Arrays
