Design Information; Models Available; Accessories; Dimensions And Clearances - GE Monogram ZGU365 Installation Instructions Manual

ZGU365
Models
36" gas downdraft cooktops
Available
These models are shipped for natural gas
operation. They can be converted to liquid
propane. (Order JXLP56 conversion kit.)
These gas downdraft cooktops are equipped

Accessories

with an vent system which can be retracted
when not in use.
• JXBA56WW, white or JXBA56BB, black
Dimensions
and Clearances
motor and blower assembly is required for
both models. Be sure to order the color that
matches the cooktop.
2"
19-3/4"
36"
8-3/4"
15"
2"
7-1/2"
2-1/4"
3-1/4"
6-3/8"
7"
12-3/8"
5-3/8"

Design Information

• JXRB57 optional accessory for indoor
remote location of the blower/motor
assembly. Use this kit when the blower and
motor assembly will be located outside of or
below the cabinet floor.
• JXBC57 optional outdoor cover accessory
may be ordered for installation of blower
and motor assembly on the outside wall.
2"
3-7/8" Min.
From Cooktop
to Rear Vertical
Combustible
When Installed
8-1/2" Lift
3-1/4"
G a s Downdraf t Cooktop
13"
Max.
Installed Both Sides
1-1/2" Min.
When Installed
36"
33-3/4"
14-3/4"
26"
30"
Min.
18"
Min.
8" Min. to
Wall When
27"
