Contents
2
Before you begin-Read these instructions completely and carefully.
IMPORTANT: Save these instructions for local inspector's use.
IMPORTANT: OBSERVE ALL GOVERNING CODES AND ORDINANCES.
NOTE TO INSTALLER: Be sure to leave these instructions with the Consumer.
NOTE TO CONSUMER: Keep these instructions with your Owners Manual
for future reference.
This appliance must be properly grounded. See "Power Supply", page 8.
Cet appareil doit être correctement mis à la terre. Voir << Alimentation électrique >> à la page 8.
If you have a question concerning the installa-
tion of this product, call the GE Answer
®
Center Consumer Information Service at
800.626.2000, 24 hours a day, 7 days a week. If
you received a damaged cooktop, you should
immediately contact your dealer or builder.
FOR YOUR SAFETY
If you smell gas:
1. Open windows.
2. Don't touch electrical switches.
3. Extinguish any open flame.
4. Immediately call your gas supplier.
FOR YOUR SAFETY
Do not store or use combustible materials,
gasoline or other flammable vapors and
liquids in the vicinity of this or any other
appliance.
• Installation of this cooktop must conform
with local codes, or in the absence of local
codes, with the National Fuel Gas Code,
ANSI Z223.1, latest edition. In Canada,
installation must conform with the current
Design Information
Models Available ........................................................... 3
Accessories ..................................................................... 3
Dimensions and Clearances ......................................... 3
Advance Planning ......................................................... 4
Ductwork Advance Planning ........................................ 4
Tools and Materials Required ...................................... 4
Cabinetry/Ductwork
Cut the Opening ........................................................... 5
Venting Options ............................................................ 6
Ductwork Fittings .......................................................... 7
Power Supply Locations ............................................... 8
Proper installation is the responsibility of the
installer. Product failure due to improper
installation is not covered under the GE
Appliance Warranty. See the Owners Manual
for warranty information.
For Monogram local service in your area,
1-800-444-1845.
For Monogram service in Canada,
1-888-880-3030.
For Monogram Parts and Accessories, call
1-800-626-2002.
Natural Gas Installation Code, CAN/CGA-
B149.1 or the current Propane Installation
Code, CAN/CGA-B149.2, and with local
codes where applicable.
• This cooktop has been design-certified by
the American Gas Association according to
ANSI Z21.1, latest edition and Canadian Gas
Association according to CAN/CGA-1.1
latest edition.
• Your cooktop must be electrically grounded
in accordance with local codes or, in the
absence of local codes, in accordance with
the National Electrical Code (ANSI/NFPA
70, latest edition). In Canada, electrical
grounding must be in accordance with the
current CSA C22.1 Canadian Electrical Code
Part 1 and/or local codes.
Installation
Step 1: Install Downdraft Vent ..................................... 9
Step 2: Install Ductwork ............................................. 10
Step 3: Install Pressure Regulator .............................. 10
Step 4: Install the Cooktop ........................................ 11
Step 5: Electrical Connections ................................... 12
Step 6: Connect Power ............................................... 12
Step 7: Assemble Burners, Check Ignition ............... 12
Step 8: Install Filters,
Check Operation of Downdraft ................................. 13
JXRB57 Kit, Indoor Remote Blower Location ........ 14
JXBC57 Kit, Outdoor Remote Blower Location ...... 17
