1
• Remove the 4 nuts holding the blower to the
Step
• Remove the blower mounting plate.
(continued)
• Remove 2 screws along the bottom of the
• Carefully, turn the unit over to access the
• Remove 4 screws along the top of the blower
• Turn unit over and remove the 4 screws
• Remove the blower box.
• Retain all screws.
2
• Determine location of the blower and
Step
Determine
Blower
• Secure mounting brackets to the top of the
Location
• Mark the installation location and cut hole
• Secure the blower to the joists.
mounting plate. One nut is hidden inside
the outlet. Remove blower.
blower box which are visible once blower
plate is removed.
back side.
box.
along the top.
motor.
– The blower will fit between floor joists, 16"
on center. Or, provide a surface to attach
the entire assembly to the underside of the
floor.
blower with screws and nuts. One bracket in
each corner, as illustrated.
– Set the bracket at the ends of the curved
slots to reach a 14-1/2" span between floor
joists, or adjust for your installation
situation.
for 6" round duct.
JXRB57 Kit
For Indoor Remote Blower Locations
Important: Save any
unused parts. If the
appliance is relocated at
a later time, parts may be
needed.
Hidden
Screws
Blower
14-1/2"
Blower Box
Blower
Mounting
Plate
