3
Step
Connect
Ductwork
• The downdraft plenum can discharge from
.
4
• Use electrical cable and connectors that
Step
Connect
• Attach the wire box removed from the
Electrical
• Use wire nuts to secure the wire to the 3"
• Insert the plug into the mating plug on the
• Reinstall wire box with original screws.
• Install a junction box withing reach of the
• Use a conduit fitting to secure conduit to
• Use wire nuts to connect wires.
16
Duct Adapter
Outlet Cover
either the right or left side. Select the side
that provides the best alignment to ductwork
extending to the blower assembly below.
– For a left side discharge, install the outlet
plate to the bottom of the plenum on the
left side. Install the cover plate to the
bottom of the right side. Reverse plates for
a right side discharge.
conform to local codes (14 gauge min. is
recommended). Use a length to reach
between the vent and the blower/motor
location.
blower conduit to the end of new wiring.
remaining wires with plug.
vent.
blower conduit.
junction box. The red plastic anti-short
bushing should be secured to the end of the
conduit.
JXRB57 Kit
Downdraft
• Connect the plenum to the ductwork.
A transition is required to connect the
3-1/4" x 10" duct to the 6" round inlet on
the blower.
• Tape to seal all joints.
Blower
Wire
Box
For Indoor Remote Blower Locations
Plenum
Provided
Mounting
Screws
Wire Nuts
Wiring to Blower Junction Box
3-Wire
Connectors
