(1. 3. 4) Changing each setting in PW SR mode
Move up down
By pushing
MENU UP, DOWN
-- SHUTTER --
MODE
E.TRG
TRG.P
PART
<MODE = E.TRG E.TRG = PW SR>
(a) Changing the polarity of inputting trigger pulse setting
1 Set the " " to TRG.P by pushing [MENU UP], [MENU DOWN] buttons.
2 Select either
Note:
The longer the storage time with extended exposures, the more visible certain characteristics of CCD
cameras become: fixed pattern noise, white pixels, etc.
(1. 3. 5) Changing each setting in RR mode
Move up down
By pushing
MENU UP, DOWN
-- SHUTTER --
MODE
E.TRG
PART
<MODE = E.TRG E.TRG = RR>
(a) Changing the partial scanning setting
1 Set the " " to PART by pushing [MENU UP], [MENU DOWN] buttons.
2 Select the mode by pushing [DATA UP], [DATA DOWN] buttons.
Note:
The longer the storage time with extended exposures, the more visible certain characteristics of CCD
cameras become: fixed pattern noise, white pixels, etc.
18
Set by pushing
DATA UP, DOWN
E.TRG
PW SR
OFF
, by pushing [DATA UP], [DATA DOWN] buttons.
Set by pushing
DATA UP, DOWN
E.TRG
RR
OFF
• Sutter mode MANU, SS, E.TRG
• E.TRG mode
1P SNR, 1P SR, PW SNR, PW SR, RR
• Input trigger pulse setting at PW SNR and PW SR
Input trigger pulse : positive polarity
Input trigger pulse : negative polarity
• Partial scanning switch
OFF/25fps/30fps/35fps/40fps/45fps/50fps/
E25fps/E30fps/E35fps/E40fps/E45fps/E50fps
• Shutter mode MANU, SS, E.TRG
• E.TRG mode
1P SNR, 1P SR, PW SNR, PW SR, RR
• Partial scanning switch
OFF/25fps/30fps/35fps/40fps/45fps/50fps/
E25fps/E30fps/E35fps/E40fps/E45fps/E50fps
