Therma-Stor FOCUS Ultra-Aire 135H Owner's Manual

Ultra-Aire 135H Air Purifying Dehumidifier
The Ultra-Aire 135H dehumidifier performs multiple functions in
a compact enclosure; high-capacity dehumidification, fresh air
ventilation, and is filtration ready.
Dehumidification
The highly efficient Ultra-Aire APD UA-135H dehumidifier
utilizes refrigeration to cool the incoming air stream below
its dew point. This cooled and drier air is used to pre-cool the
incoming air stream resulting in up to a 200 percent increase
in overall efficiency. After the pre-cooling stage the processed
air is reheated by passing through the condenser coil. The
heat removed by the evaporator coil is returned to the air
stream, resulting in an overall temperature increase from the
incoming air.
Fresh Air Ventilation (optional)
Fresh outdoor air is ducted to the unit via a 6" round duct. This
provides desired air changes to dilute pollutants and maintain
high oxygen content in the air. The amount of fresh air ventilation
can be regulated by a variety of controls.
Air Filtration
The UA-135H includes air filtration to improve the indoor air
quality of your living/working space. MERV-8 media is standard.
An optional second MERV-14 deep pleated media filter is
available for optimum air filtration to reduce airborne particles.
Dehumidification
Fresh Air Ventilation
Compact Size
Remote Filter Box
Figure 2: Features and Benefits
© Copyright Therma-Stor LLC
TM

Features and Benefits

Therma-Stor LLC announces the introduction of the Ultra-Aire Model 135H Air
Purifying Dehumidifier, a ventilating dehumidifier designed to provide ultimate
indoor air quality. The Ultra-Aire provides the three key components of healthy
indoor air: fresh air ventilation, particulate filtration and humidity control. At the
heart of the 135H is a high capacity, energy efficient dehumidifier capable of
removing over 17 gallons of water per day (at 80°F, 60% relative humidity).
while using only 12 amps of electricity (120V). This allows the unit to maintain
indoor humidity levels below 50%, the level widely recognized as critical for
controlling mold, mildew and dust mite populations.
Owners Manual
F
ILTRATION
Figure 1: Ultra-Aire 135H (Package D)
Issue 01
1
