User Manual
VX4353
Relay Switching Module
070-9121-02
This document supports firmware version 1.00
Warning
The servicing instructions are for use by qualified
personnel only. To avoid personal injury, do not
perform any servicing unless you are qualified to
do so. Refer to the Safety Summary prior to
performing service.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Tektronix VX4353
Summary of Contents for Tektronix VX4353
-
Page 1: User Manual
User Manual VX4353 Relay Switching Module 070-9121-02 This document supports firmware version 1.00 Warning The servicing instructions are for use by qualified personnel only. To avoid personal injury, do not perform any servicing unless you are qualified to do so. Refer to the Safety Summary prior to performing service. - Page 2 Commercial Computer Software – Restricted Rights clause at FAR 52.227-19, as applicable. Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication supercedes that in all previously published material. Specifications and price change privileges reserved.
-
Page 5: Contacting Tektronix
For product support outside of North America, contact your local Tektronix distributor or sales office. Service Contact your local Tektronix distributor or sales office. Or visit Support our web site for a listing of worldwide service locations. http://www.tek.com For other... - Page 7 EC Declaration of Conformity Tektronix Holland N.V. Marktweg 73A 8444 AB Heerenveen The Netherlands declare under sole responsibility that the VX4353 meets the intent of Directive 89/336/EEC for Electromagnetic Compatibility and Low Voltage Directive 73/23/ECC for Product Safety. Compliance was demonstrated to the...
- Page 11 Appendix E – Performance Verification Procedure....... A – 15...
- Page 25 To avoid electric shock, tighten the module mounting screws after installing the module into the mainframe to ensure that the front panel is properly grounded. Note. There are two labeled printed ejector handles on the card. To install the card correctly, make sure the ejector labeled “VX4353” is at the top. Note.
- Page 58 070-9121-02...
-
Page 59: Appendix E Performance Verification Procedure
Appendix E Performance Verification Procedure The performance verification procedure verifies that the module is operating within specification. Conventions Used In This Procedure All control of the VX4353 Module will be accomplished through a VXI Slot 0 device. ASCII characters will form the commands sent to control the module and ASCII charac- ters will be read from the module. -
Page 60: Equipment Required
Table 1–1: Equipment Required Required tools and equipment Part number VXI Mainframe (such as the Tektronix VX1410) VXI Slot 0 with resource Manager (Tektronix VX4521) and appropriate cables and interface cards. Digital Multi Meter (DMM) with 4-wire Ohm capability, and standard lab equipment the ability to read more then 10 Gigohms. - Page 61 Digital Multi-Meter Connection and Set Up 1. Connect the DMM signal high and input + side to the “pig tail” that is connected to the VX1780S connector pin-1. 2. Connect the DMM signal low and input – side to the “pig tail” that is connected to the VX1780S connector pin-2.
- Page 62 Testing The Delay Command 1. Send “R ” (Reset the VX4353) to the VX4353. 2. Send “D1000C0C1” (Reset, Close CH00 and CH01 on the VX4353) to the VX4353. a. Monitor the time difference between the time it takes for the CH00 LED to light, and the time for the CH01 LED to light.
