9.
Turn on the Expansion Box power using the power switch next to the
Expansion Cable, then power on the PC system.
10.
Once the Expansion Box has successfully been connected to the
host computer, proceed to the section titled Software Installation.
Using the ExpressCard Host Adapter Card
The following diagram is a visual depiction of the instructions on the
following page, which account for installation of the PEX2PCI4 using the
(accessory) EC2PCI ExpressCard Adapter (must be purchased sepa-
rately).
1.
Turn OFF the computer power before installation. Since both the PC
system and the Expansion Box are self-powered, you need to follow
Instruction Manual
6
2
4
4
3
